Electrical 3 replacement parts for 2022 Yamaha FX HO with Audio

OEM Parts Yamaha 2022 Yamaha FX HO with Audio Electrical 3

ELECTRICAL 3 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL PUMP COMP. Part #: 6S5-13907-05-00 Required per assembly: 1 ~~$1,176.99~~ $1,158.18 - + Add to cart
2	FUEL SENDER ASSY SET Part #: 99999-04571-00 Required per assembly: 1 ~~$326.99~~ $322.04 - + Add to cart
3	DAMPER, STOPPER Part #: 60E-82556-00-00 Required per assembly: 1 ~~$15.52~~ $14.11 - + Add to cart
4	BATTERY ASSEMBLY (YUASA YTX20L-BS) Part #: YTX-20LBS-00-00 Required per assembly: 1 Note: UR $181.60 - + Add to cart
5	PLATE, BASE, 2 Part #: F2S-U8592-00-00 Required per assembly: 1 ~~$10.18~~ $5.82 - + Add to cart
6	PLATE, BASE, 3 Part #: F2S-U8593-00-00 Required per assembly: 1 ~~$10.18~~ $5.44 - + Add to cart
7	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 4 Note: Sold in multiples of 5 only ~~$5.49~~ $4.97 - + Add to cart
8	CASE, BATTERY Part #: F2S-U8211-00-00 Required per assembly: 1 ~~$13.25~~ $11.32 - + Add to cart
9	BOLT, WITH, WASHER Part #: 90119-06820-00 Required per assembly: 2 ~~$9.16~~ $3.84 - + Add to cart
10	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 2 ~~$6.11~~ $1.51 - + Add to cart
11	PAD, BATTERY Part #: F1S-U8221-00-00 Required per assembly: 1 ~~$8.15~~ $3.18 - + Add to cart
12	PAD, BATTERY Part #: EU0-U8221-31-00 Required per assembly: 2 ~~$3.04~~ $1.89 - + Add to cart
13	MAT 2 Part #: F1W-U759C-01-00 Required per assembly: 1 ~~$7.12~~ $2.48 - + Add to cart
14	PACKING Part #: F2C-U1743-00-00 Required per assembly: 1 ~~$7.12~~ $2.10 - + Add to cart
15	BAND, BATTERY, 1 Part #: F4P-U821D-00-00 Required per assembly: 2 ~~$19.37~~ $13.59 - + Add to cart
16	METER ASSY Part #: F3V-U820A-02-00 Required per assembly: 1 ~~$1,540.11~~ $1,400.10 - + Add to cart
17	CONVERTING UNIT Part #: F5G-HA260-00-00 Required per assembly: 1 ~~$560.48~~ $509.53 - + Add to cart
18	BRACKET Part #: F5G-U826C-00-00 Required per assembly: 1 ~~$17.32~~ $13.59 - + Add to cart
19	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$5.49~~ $4.97 - + Add to cart
20	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 3 ~~$6.11~~ $1.51 - + Add to cart
21	SWITCH ASSEMBLY Part #: F5G-U8090-01-00 Required per assembly: 1 ~~$92.81~~ $74.07 - + Add to cart
22	WIRE, HARNESS, 1 Part #: F3V-U0891-00-00 Required per assembly: 1 ~~$348.82~~ $294.82 - + Add to cart
23	PACKING, HOSE, 2 Part #: GJ1-U7578-21-00 Required per assembly: 1 ~~$1.99~~ $0.98 - + Add to cart
24	CLAMP Part #: 90464-32801-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$6.11~~ $1.36 - + Add to cart
25	MIC ASSEMBLY Part #: F5G-U827A-00-00 Required per assembly: 1 ~~$612.04~~ $556.40 - + Add to cart
26	CLAMP Part #: 90464-32801-00 Required per assembly: 4 Note: Sold in multiples of 5 only ~~$6.11~~ $1.36 - + Add to cart
27	BASE, CLAMP Part #: F1W-U828M-00-00 Required per assembly: 9 ~~$6.11~~ $1.36 - + Add to cart
28	CLAMP Part #: 90464-32801-00 Required per assembly: 6 Note: Sold in multiples of 5 only ~~$6.11~~ $1.36 - + Add to cart
29	RIVET, BLIND Part #: 90267-48806-00 Required per assembly: 6 Note: Sold in multiples of 10 only ~~$7.12~~ $2.27 - + Add to cart
30	PACKING, HOSE, 2 Part #: GJ1-U7578-21-00 Required per assembly: 2 ~~$1.99~~ $0.98 - + Add to cart
31	CLAMP Part #: F5G-U4256-00-00 Required per assembly: 3 ~~$11.21~~ $5.88 - + Add to cart
32	RIVET, BLIND Part #: 90267-48806-00 Required per assembly: 3 Note: Sold in multiples of 10 only ~~$7.12~~ $2.27 - + Add to cart
33	WIRE, MINUS, LEAD Part #: 6JP-82116-00-00 Required per assembly: 1 ~~$65.98~~ $65.00 - + Add to cart
