Bimini Top / Carpet replacement parts for 2022 Yamaha SX210

OEM Parts Yamaha 2022 Yamaha SX210 Bimini Top / Carpet

BIMINI TOP / CARPET Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	AWNING, CANVAS, SET Part #: F2J-U3104-11-00 Required per assembly: 1 $2,228.51 - + Add to cart
1	AWNING, CANVAS, SET Part #: F3S-U3104-30-00 Required per assembly: 1 $2,166.67 - + Add to cart
2	CANVAS SET Part #: F3S-U3108-30-00 Required per assembly: 1 ~~$842.49~~ $776.90 - + Add to cart
2	CANVAS SET Part #: F2J-U3108-10-00 Required per assembly: 1 ~~$1,017.86~~ $934.33 - + Add to cart
3	COVER Part #: F3S-U3119-30-00 Required per assembly: 1 ~~$370.25~~ $356.21 - + Add to cart
3	COVER Part #: F2J-U3119-11-00 Required per assembly: 1 ~~$394.73~~ $357.23 - + Add to cart
4	COVER, SIDE, 1 Part #: F2D-U377B-00-00 Required per assembly: 2 ~~$202.97~~ $174.75 - + Add to cart
5	PIPE, AWNING, 1 Part #: F2J-U3111-10-00 Required per assembly: 1 $1,408.49 - + Add to cart
6	PIVOT, SLIDE Part #: F1C-U3152-00-00 Required per assembly: 4 ~~$96.89~~ $75.58 - + Add to cart
7	SCREW Part #: 90149-08SE1-00 Required per assembly: 2 ~~$7.12~~ $3.24 - + Add to cart
8	SCREW Part #: 90149-14SD9-00 Required per assembly: 2 ~~$8.15~~ $4.97 - + Add to cart
9	STOPPER, ROOF, 1 Part #: F0R-U3196-00-00 Required per assembly: 2 ~~$19.37~~ $15.10 - + Add to cart
10	PIPE, AWNING, 2 Part #: F2J-U3112-10-00 Required per assembly: 1 $820.32 - + Add to cart
11	BELT, AWNING, 1, 48" Part #: F2A-U3121-00-00 Required per assembly: 2 ~~$145.84~~ $113.37 - + Add to cart
12	PIVOT, SLIDE Part #: F1C-U3152-00-00 Required per assembly: 2 ~~$96.89~~ $75.58 - + Add to cart
13	SCREW Part #: 90149-08SE1-00 Required per assembly: 2 ~~$7.12~~ $3.24 - + Add to cart
14	SCREW Part #: 90149-14SD0-00 Required per assembly: 2 Not Available
15	PIPE, AWNING, 3 Part #: F2J-U3113-10-00 Required per assembly: 2 ~~$646.97~~ $622.15 - + Add to cart
16	PIPE, AWNING, 4 Part #: F2J-U3114-10-00 Required per assembly: 2 ~~$262.13~~ $223.76 - + Add to cart
17	HOLDER, PIPE, 1 Part #: F0R-U781B-01-00 Required per assembly: 1 ~~$20.39~~ $15.10 - + Add to cart
18	RIVET Part #: F0R-U2698-00-00 Required per assembly: 2 ~~$5.99~~ $1.46 - + Add to cart
19	PULL, PIN, BIMINI, TOP Part #: F0R-U316A-10-00 Required per assembly: 1 Note: (FL66314600) ~~$33.64~~ $24.92 - + Add to cart
20	BRACKET, AWNING, 2 Part #: F0R-U3142-00-00 Required per assembly: 2 ~~$35.68~~ $27.94 - + Add to cart
21	SCREW, COUNTERSUNK Part #: 90152-10S40-00 Required per assembly: 4 ~~$5.08~~ $0.91 - + Add to cart
22	WASHER Part #: 90209-10SB1-00 Required per assembly: 4 ~~$6.11~~ $1.29 - + Add to cart
23	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 4 ~~$5.08~~ $1.06 - + Add to cart
24	CARPET SET Part #: F3S-U3908-40-00 Required per assembly: 1 ~~$821.60~~ $761.91 - + Add to cart
25	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 37 ~~$0.71~~ $0.60 - + Add to cart
26	WASHER, PLASTIC, CARPET, SNAP Part #: 90202-06SA1-00 Required per assembly: 37 ~~$6.11~~ $1.97 - + Add to cart
27	FITTING BRACKET ASSEMBLY 1 Part #: F2J-U5920-00-00 Required per assembly: 2 ~~$48.95~~ $37.77 - + Add to cart
28	PIN (FL66314600) (FL66314600) Part #: F2J-U316A-00-00 Required per assembly: 1 ~~$29.57~~ $22.66 - + Add to cart
29	SCREW, COUNTERSUNK Part #: 90152-10S24-00 Required per assembly: 4 ~~$0.45~~ $0.42 - + Add to cart
30	PLATE Part #: F2J-U757B-00-00 Required per assembly: 2 ~~$12.23~~ $6.05 - + Add to cart
31	WASHER Part #: 90209-10SB1-00 Required per assembly: 4 ~~$6.11~~ $1.29 - + Add to cart
32	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 4 ~~$5.08~~ $1.06 - + Add to cart
33	EYE STRAP Part #: F0R-U6319-01-00 Required per assembly: 2 ~~$17.32~~ $11.32 - + Add to cart
34	SCREW Part #: 90149-08SD4-00 Required per assembly: 4 ~~$0.36~~ $0.30 - + Add to cart
35	WASHER Part #: 90209-10SB1-00 Required per assembly: 4 ~~$6.11~~ $1.29 - + Add to cart
36	NUT, SELF-LOCKING Part #: 90185-08S00-00 Required per assembly: 4 ~~$7.12~~ $1.59 - + Add to cart
