Steering Gate replacement parts for 2022 Yamaha Mountain Max 800 LE 154 SL

OEM Parts Yamaha 2022 Yamaha Mountain Max 800 LE 154 SL Steering Gate

STEERING GATE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	NUT, FLANGE, M6-1.0 Part #: 8JM-RA322-00-00 Required per assembly: 1 ~~$0.28~~ $0.25 - + Add to cart
2	SERVO MOTOR ASSEMBLY Part #: 8NV-H5820-00-00 Required per assembly: 1 ~~$526.99~~ $474.50 - + Add to cart
3	RIVET, 9 Part #: 8JP-RA518-00-00 Required per assembly: 6 ~~$0.40~~ $0.30 - + Add to cart
4	BRACKET 1 Part #: 8NV-F3881-00-00 Required per assembly: 1 ~~$247.99~~ $182.83 - + Add to cart
5	INSERT Part #: 8JP-F3775-00-00 Required per assembly: 2 ~~$2.79~~ $2.07 - + Add to cart
6	SUPPORT, MEMBER Part #: 8NS-F2527-00-00 Required per assembly: 1 ~~$33.99~~ $22.62 - + Add to cart
7	BOLT, FLANGE Part #: 8NS-RA104-00-00 Required per assembly: 10 ~~$2.45~~ $1.81 - + Add to cart
8	PIPE, CROSS, 7 Part #: 8KC-F119E-00-00 Required per assembly: 1 ~~$41.99~~ $36.39 - + Add to cart
9	PIPE CROSS 8 Part #: 8KC-F119F-00-00 Required per assembly: 1 ~~$49.99~~ $36.39 - + Add to cart
10	NUT, HEX, FLG-NYL, LOCK Part #: 8JM-RA301-00-00 Required per assembly: 3 ~~$1.14~~ $0.82 - + Add to cart
11	NUT, HEX., LOCKING Part #: 8JP-RA372-00-00 Required per assembly: 10 ~~$0.45~~ $0.32 - + Add to cart
12	CAP, MAIN, PIPE Part #: 8JP-F111A-10-00 Required per assembly: 2 ~~$4.90~~ $3.76 - + Add to cart
13	PIPE, CROSS Part #: 8NS-F2162-00-00 Required per assembly: 2 ~~$98.98~~ $70.96 - + Add to cart
14	CLAMP, 2 Part #: 8ND-RAB01-00-00 Required per assembly: 1 ~~$4.54~~ $3.78 - + Add to cart
15	BRACKET 1 Part #: 8JP-E244E-00-00 Required per assembly: 1 ~~$39.99~~ $28.67 - + Add to cart
16	BOLT, FLG., M6X1.0X Part #: 8JP-RA183-00-00 Required per assembly: 5 ~~$1.50~~ $1.10 - + Add to cart
17	SUPPORT 2 Part #: 8ND-F2568-00-00 Required per assembly: 1 ~~$80.98~~ $73.36 - + Add to cart
18	SUPPORT 1 Part #: 8ND-F2567-00-00 Required per assembly: 1 ~~$99.98~~ $90.18 - + Add to cart
19	BOLT, FLANGE Part #: 8ND-RA177-00-00 Required per assembly: 1 ~~$4.70~~ $3.90 - + Add to cart
20	BOLT Part #: 8ND-RA122-00-00 Required per assembly: 2 ~~$1.75~~ $1.47 - + Add to cart
21	BOLT, FLG., M8X1.25 Part #: 8JP-RA185-00-00 Required per assembly: 2 ~~$0.90~~ $0.76 - + Add to cart
22	MEMBER, SIDE, 1 Part #: 8ND-F111J-00-00 Required per assembly: 1 Not Available
23	MEMBER, SIDE, 2 Part #: 8ND-F111K-10-00 Required per assembly: 1 ~~$61.99~~ $53.56 - + Add to cart
24	BOLT, FLG., M6X1.0X25 Part #: 8JP-RA182-00-00 Required per assembly: 2 ~~$0.70~~ $0.59 - + Add to cart
25	WASHER, LOCK-1/4, EXT Part #: 8JM-RA407-00-00 Required per assembly: 1 ~~$0.28~~ $0.25 - + Add to cart
26	NUT, SELF-LOCKING Part #: 8JP-RA379-00-00 Required per assembly: 5 ~~$0.45~~ $0.32 - + Add to cart
27	SCREW, M6X1.0X16 Part #: 8JP-RA256-00-00 Required per assembly: 2 Not Available
28	CAP, MAIN, PIPE Part #: 8JP-F111A-20-00 Required per assembly: 6 ~~$7.49~~ $5.94 - + Add to cart
29	BRACKET Part #: 8ML-E4744-00-00 Required per assembly: 1 ~~$3.75~~ $3.11 - + Add to cart
30	CLAMP, 21 Part #: 8JP-RAB23-00-00 Required per assembly: 1 Not Available
31	SCREW, M6X1.0X25 Part #: 8JP-RA263-00-00 Required per assembly: 1 ~~$2.70~~ $1.97 - + Add to cart
32	GATE, STEERING Part #: 8NS-F3871-00-00 Required per assembly: 1 ~~$264.99~~ $196.56 - + Add to cart
33	DUCT 1 Part #: 8NV-F286A-00-00 Required per assembly: 1 ~~$39.99~~ $34.85 - + Add to cart
34	NUT, SPRING Part #: 8JP-RA349-00-00 Required per assembly: 2 ~~$1.50~~ $1.10 - + Add to cart
35	BOLT, FLANGE Part #: 8NW-RA191-00-00 Required per assembly: 1 ~~$2.35~~ $1.97 - + Add to cart
36	WASHER, 6.87X25.4X Part #: 8JP-RA450-00-00 Required per assembly: 1 ~~$0.95~~ $0.68 - + Add to cart
