Windshield replacement parts for 2022 Yamaha Tracer 9 GT

OEM Parts Yamaha 2022 Yamaha Tracer 9 GT Windshield

WINDSHIELD Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WINDSHIELD Part #: B5U-28381-00-00 Required per assembly: 1 $385.99 $383.20 - + Add to cart
2	SCREW, ROUND, HEAD Part #: 90150-05024-00 Required per assembly: 4 $3.35 $2.80 - + Add to cart
3	NUT Part #: 90179-05003-00 Required per assembly: 4 $6.49 $4.81 - + Add to cart
4	STAY, MAIN, 1 Part #: B5U-2831R-00-00 Required per assembly: 1 $92.98 $79.33 - + Add to cart
5	STAY, SUPPORT, 1 Part #: B5U-2831T-00-00 Required per assembly: 1 $51.99 $43.52 - + Add to cart
6	WASHER Part #: B5C-28319-00-00 Required per assembly: 3 $5.49 $3.18 - + Add to cart
7	BOLT, BUTTON, HEAD Part #: 92017-05016-00 Required per assembly: 3 $8.49 $5.10 - + Add to cart
8	O-RING Part #: 93210-14MF4-00 Required per assembly: 3 $8.49 $5.76 - + Add to cart
9	KNOB, 1 Part #: B5C-2836X-00-00 Required per assembly: 1 $25.98 $19.93 - + Add to cart
10	PLUG Part #: 90338-07010-00 Required per assembly: 1 $5.49 $4.45 - + Add to cart
11	SHAFT, 1 Part #: B5C-2835B-00-00 Required per assembly: 1 $36.99 $28.49 - + Add to cart
12	CIRCLIP Part #: 99009-09800-00 Required per assembly: 2 $1.20 $0.48 - + Add to cart
13	SPRING Part #: B5C-28388-00-00 Required per assembly: 1 $5.49 $4.31 - + Add to cart
14	DAMPER, LOCATING, 1 Part #: B5C-2836T-00-00 Required per assembly: 1 $6.49 $4.81 - + Add to cart
15	COLLAR Part #: B5C-28373-00-00 Required per assembly: 3 $17.48 $13.47 - + Add to cart
16	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05061-00 Required per assembly: 3 $1.70 $1.03 - + Add to cart
17	STAY 1 Part #: B5U-28356-01-00 Required per assembly: 1 $233.99 $224.84 - + Add to cart
18	PLUG Part #: 90338-06007-00 Required per assembly: 2 $10.49 $8.18 - + Add to cart
19	BOLT, WITH, WASHER Part #: 90119-08179-00 Required per assembly: 2 $1.35 $1.18 - + Add to cart
20	PANEL, INNER, 3 Part #: B5U-2836M-01-00 Required per assembly: 1 $12.49 $9.47 - + Add to cart
21	RIVET Part #: 90269-06001-00 Required per assembly: 4 $6.49 $5.32 - + Add to cart
22	LABEL, NOTICE, WINDSHIELD, 1 Part #: 4B5-2815K-00-00 Required per assembly: 1 $8.49 $7.12 - + Add to cart
