Engine Hatch 2 replacement parts for 2022 Yamaha VX-C

OEM Parts Yamaha 2022 Yamaha VX C Engine Hatch 2

ENGINE HATCH 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BOLT, WITH, WASHER Part #: 90119-06803-00 Required per assembly: 2 ~~$9.16~~ $5.43 - + Add to cart
2	NUT Part #: F3X-U517E-00-00 Required per assembly: 2 ~~$6.11~~ $1.98 - + Add to cart
3	HOOK, LID, LOCK Part #: F4P-U517F-00-00 Required per assembly: 1 ~~$28.55~~ $23.36 - + Add to cart
4	CAP Part #: F4P-U5568-00-00 Required per assembly: 2 ~~$7.12~~ $4.00 - + Add to cart
5	COVER, CENTER Part #: F4N-U5554-00-00 Required per assembly: 1 $163.37 - + Add to cart
6	PACKING 3 Part #: F1K-U266B-00-00 Required per assembly: 4 ~~$6.11~~ $1.87 - + Add to cart
7	NUT Part #: F3X-U517E-00-00 Required per assembly: 2 ~~$6.11~~ $1.98 - + Add to cart
8	PLATE, FIX Part #: F2X-U5175-00-00 Required per assembly: 2 ~~$6.11~~ $2.84 - + Add to cart
9	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 2 Note: Sold in multiples of 5 only $6.93 - + Add to cart
10	BOLT, WITH, WASHER Part #: 90119-06878-00 Required per assembly: 2 ~~$9.16~~ $5.35 - + Add to cart
11	BOLT Part #: F4P-U1355-00-00 Required per assembly: 4 ~~$5.08~~ $1.44 - + Add to cart
12	COVER METER Part #: F6G-U8262-00-00 Required per assembly: 1 ~~$25.48~~ $21.62 - + Add to cart
13	SCREW Part #: F2S-U13C1-00-00 Required per assembly: 2 ~~$7.12~~ $3.80 - + Add to cart
14	COVER, FRONT Part #: F4N-U513M-00-00 Required per assembly: 1 ~~$23.44~~ $19.01 - + Add to cart
15	GLOVE BOX HATCH ASSEMBLY Part #: F4N-U1708-01-00 Required per assembly: 1 ~~$159.11~~ $123.95 - + Add to cart
16	SEAL Part #: F3X-U2723-00-00 Required per assembly: 1 ~~$7.12~~ $3.48 - + Add to cart
17	NUT Part #: F3X-U517E-00-00 Required per assembly: 8 ~~$6.11~~ $1.98 - + Add to cart
18	INNER, CASE Part #: F4N-U591L-00-00 Required per assembly: 1 ~~$53.03~~ $42.31 - + Add to cart
19	BRACKET Part #: F2C-U826C-00-00 Required per assembly: 4 ~~$9.16~~ $5.93 - + Add to cart
20	RIVET 1 Part #: F4P-U516R-01-00 Required per assembly: 8 ~~$11.21~~ $7.42 - + Add to cart
21	BOLT, WITH, WASHER Part #: 90119-08828-00 Required per assembly: 4 ~~$7.12~~ $3.69 - + Add to cart
22	PACKING CASE Part #: F4N-U519D-02-00 Required per assembly: 1 ~~$59.14~~ $46.84 - + Add to cart
23	GLOVE BOX COVER ASSEMBLY Part #: F4N-U4705-01-00 Required per assembly: 1 ~~$59.14~~ $46.84 - + Add to cart
24	LOCK Part #: F4N-U2875-00-00 Required per assembly: 1 ~~$7.12~~ $6.13 - + Add to cart
25	HOOK A Part #: F1K-U5772-04-00 Required per assembly: 2 ~~$12.23~~ $8.59 - + Add to cart
26	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 2 Note: Sold in multiples of 5 only $6.93 - + Add to cart
27	MAT 2 Part #: F1K-U759C-00-00 Required per assembly: 2 ~~$6.11~~ $2.74 - + Add to cart
28	BOX, FIRE, EXTINGUISHER Part #: F2X-U5983-00-00 Required per assembly: 1 $14.13 - + Add to cart
29	RIVET, BLIND Part #: 90267-48802-00 Required per assembly: 2 ~~$6.99~~ $2.08 - + Add to cart
30	BAND, 1 Part #: F2P-U828K-00-00 Required per assembly: 1 ~~$13.25~~ $8.86 - + Add to cart
31	RFM., DASH, BOARD, 1 Part #: F4N-U974A-00-00 Required per assembly: 1 ~~$18.35~~ $16.08 - + Add to cart
