OEM Parts Yamaha 2022 Yamaha YDX Moro 7 Electrical 2

2022 Yamaha YDX Moro 7 YMORO7LDBL X2U71 - Electrical 2

ELECTRICAL 2 Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

REFLECTOR

Part #: X0N-H4323-00-00 Required per assembly: 2
$9.49
$5.73
-
+
Add to cart
2

FRONT REFLECTOR ASSEMBLY

Part #: X1V-H5110-00-00 Required per assembly: 1
$17.98
$13.55
-
+
Add to cart
3

REAR REFLECTOR ASSEMBLY

Part #: X0N-H5140-10-00 Required per assembly: 1
$24.98
$18.90
-
+
Add to cart
