Transaxle replacement parts for 2022 Yamaha UMAX Two AC

OEM Parts Yamaha 2022 Yamaha UMAX Two AC Transaxle

TRANSAXLE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	TRANS AXLE ASSEMBLY Part #: J0H-G6300-12-00 Required per assembly: 1 $2,180.81 - + Add to cart
2	CIRCLIP Part #: 93420-52806-00 Required per assembly: 6 $11.63 $10.57 - + Add to cart
3	BEARING(JH8) Part #: 93306-303Y6-00 Required per assembly: 2 $53.99 $51.39 - + Add to cart
4	BEARING ASSEMBLY Part #: J0G-G6106-00-00 Required per assembly: 2 $50.99 $40.79 - + Add to cart
5	STOPPER Part #: JN3-G6432-00-00 Required per assembly: 1 $5.57 $5.07 - + Add to cart
6	CASE, TRANSMISSION, 2 Part #: JW9-G6312-00-00 Required per assembly: 1 $65.93 - + Add to cart
7	DIFFERENTIAL ASSY Part #: J0G-G6410-01-00 Required per assembly: 1 Not Available
8	GEAR, RING Part #: JW9-G6421-00-00 Required per assembly: 1 $312.99 $308.34 - + Add to cart
9	SHAFT, INPUT Part #: J0H-G6321-00-00 Required per assembly: 1 $75.98 $66.51 - + Add to cart
10	COUNTER GEAR ASSEMBLY Part #: J0H-G6350-00-00 Required per assembly: 1 $334.99 $303.90 - + Add to cart
11	BEARING Part #: 93306-203X1-00 Required per assembly: 1 $29.98 $29.45 - + Add to cart
12	HSG., BRG. Part #: J0H-G5233-00-00 Required per assembly: 2 $37.99 $30.21 - + Add to cart
13	BEARING (J17) Part #: 93306-00511-00 Required per assembly: 1 Note: SEAL TYPE $32.99 $27.23 - + Add to cart
14	GSKT., CASE Part #: JW9-G631A-00-00 Required per assembly: 1 $25.98 $24.18 - + Add to cart
15	PLUG, BLIND Part #: J0H-G3396-00-00 Required per assembly: 2 $5.49 $4.22 - + Add to cart
16	SEAL, OIL Part #: 93101-31836-00 Required per assembly: 2 $33.99 $33.23 - + Add to cart
17	O-RING Part #: 93210-478B8-00 Required per assembly: 1 $6.99 $6.56 - + Add to cart
18	O-RING Part #: J0H-G2416-00-00 Required per assembly: 2 $4.40 $3.84 - + Add to cart
19	O-RING Part #: J0H-G2414-00-00 Required per assembly: 2 $3.95 $3.18 - + Add to cart
20	SEAL 1 Part #: J0H-G6136-00-00 Required per assembly: 1 $19.48 $15.86 - + Add to cart
21	BOLT Part #: JC1-G2544-00-00 Required per assembly: 4 $9.99 $7.54 - + Add to cart
22	HUB, REAR, AXLE Part #: J0G-G6514-00-00 Required per assembly: 2 $106.98 $101.27 - + Add to cart
23	BOLT, STUD Part #: JW8-G4178-00-00 Required per assembly: 8 $5.49 $4.91 - + Add to cart
24	NUT Part #: J0G-G5244-00-00 Required per assembly: 2 $5.49 $4.31 - + Add to cart
25	WASHER, THRUST Part #: J0G-G2535-00-00 Required per assembly: 8 $4.29 $3.46 - + Add to cart
26	NUT, HEXAGON Part #: 90170-10840-00 Required per assembly: 4 $4.25 $3.70 - + Add to cart
27	WASHER, THRUST, 2 Part #: J0G-G2536-00-00 Required per assembly: 2 $4.34 $4.16 - + Add to cart
28	NIPPLE, HOSE Part #: J0G-G5378-00-00 Required per assembly: 1 $8.49 $6.05 - + Add to cart
29	CIRCLIP Part #: 93420-50804-00 Required per assembly: 1 $5.99 $5.50 - + Add to cart
30	SHAFT, REAR, AXLE, 1, (LH) Part #: J0H-G6511-00-00 Required per assembly: 1 $192.90 - + Add to cart
31	SHAFT, REAR, AXLE, 2, (RH) Part #: J0H-G6512-00-00 Required per assembly: 1 $211.99 $207.08 - + Add to cart
32	STAY, CLAMP Part #: JW8-G2756-00-00 Required per assembly: 1 $3.99 $2.80 - + Add to cart
33	DRUM Part #: JW3-G6521-10-00 Required per assembly: 2 $94.66 - + Add to cart
34	BOLT Part #: J0G-G3886-00-00 Required per assembly: 8 $5.49 $4.16 - + Add to cart
35	NUT, LOCK Part #: J0G-G5721-00-00 Required per assembly: 8 $4.25 $3.33 - + Add to cart
36	CASE ASSY Part #: J0H-G6290-01-00 Required per assembly: 1 Not Available
37	BOLT, FLANGE Part #: 90105-10840-00 Required per assembly: 4 $3.60 $2.78 - + Add to cart
38	BOLT, HEXAGON Part #: 90101-08856-00 Required per assembly: 10 $6.40 $5.82 - + Add to cart
39	PIN, COTTER Part #: 91490-30030-00 Required per assembly: 2 Note: Sold in multiples of 5 only $8.49 $7.24 - + Add to cart
40	COVER, HUB, DUST Part #: JW8-F5118-00-00 Required per assembly: 2 $3.25 $3.08 - + Add to cart
41	PIPE 1 Part #: JW8-G2541-00-00 Required per assembly: 1 $4.95 $3.99 - + Add to cart
