Cylinder replacement parts for 2022 Yamaha YXZ1000R SS XTR

OEM Parts Yamaha 2022 Yamaha YXZ1000R SS XTR Cylinder

CYLINDER Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CYLINDER HEAD ASSEMBLY Part #: 2HC-11101-08-00 Required per assembly: 1 ~~$1,509.90~~ $1,387.64 - + Add to cart
2	BOLT, FLANGE Part #: 95022-08012-00 Required per assembly: 1 ~~$13.49~~ $9.33 - + Add to cart
3	WASHER, PLATE Part #: 90201-08087-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$3.95~~ $3.34 - + Add to cart
4	BOLT, STUD Part #: 90116-08087-00 Required per assembly: 6 ~~$9.49~~ $8.60 - + Add to cart
5	GUIDE, VALVE, 1 Part #: 2C0-11133-11-00 Required per assembly: 6 ~~$69.98~~ $61.33 - + Add to cart
6	GUIDE, VALVE, 2 Part #: 8HF-11134-10-00 Required per assembly: 6 ~~$107.98~~ $92.07 - + Add to cart
7	PLUG, STRAIGHT, SCREW Part #: 90340-27129-00 Required per assembly: 2 ~~$5.99~~ $5.07 - + Add to cart
8	PIN, DOWEL, (3XW) Part #: 91808-16023-00 Required per assembly: 2 ~~$8.49~~ $5.54 - + Add to cart
9	PIN, DOWEL, (3XW) Part #: 91808-16023-00 Required per assembly: 4 ~~$8.49~~ $5.54 - + Add to cart
10	BOLT, FLANGE Part #: 90105-06027-00 Required per assembly: 16 ~~$8.49~~ $6.11 - + Add to cart
11	JOINT Part #: 8HF-13595-00-00 Required per assembly: 1 ~~$64.98~~ $45.16 - + Add to cart
12	HOSE CLAMP ASSEMBLY Part #: 90450-60004-00 Required per assembly: 2 ~~$18.48~~ $14.73 - + Add to cart
13	JOINT Part #: 8HF-13595-00-00 Required per assembly: 2 ~~$64.98~~ $45.16 - + Add to cart
14	HOSE CLAMP ASSEMBLY Part #: 90450-60004-00 Required per assembly: 4 ~~$18.48~~ $14.73 - + Add to cart
15	PLUG, SPARK, (NGK, CR9EB) Part #: CR9-EB000-00-00 Required per assembly: 3 Note: (NGK CR9EB) Sold in multiples of 4 only ~~$11.99~~ $11.08 - + Add to cart
16	BOLT, WITH, WASHER Part #: 90119-10004-00 Required per assembly: 8 ~~$9.99~~ $8.30 - + Add to cart
17	COVER, CYLINDER, HEAD, 1 Part #: 2HC-11191-00-00 Required per assembly: 1 ~~$145.99~~ $139.60 - + Add to cart
18	GUIDE, STOPPER, 2 Part #: 5BE-12241-01-00 Required per assembly: 1 ~~$32.99~~ $25.10 - + Add to cart
19	GASKET, HEAD, COVER, 1 Part #: 2HC-11193-00-00 Required per assembly: 1 ~~$28.98~~ $20.55 - + Add to cart
20	PLATE Part #: 5VY-1482K-00-00 Required per assembly: 2 ~~$5.49~~ $3.84 - + Add to cart
21	REED VALVE ASSEMBLY Part #: 5SL-14890-00-00 Required per assembly: 1 ~~$97.98~~ $82.28 - + Add to cart
22	CAP, CASE Part #: 5VY-14899-01-00 Required per assembly: 1 ~~$38.99~~ $30.75 - + Add to cart
23	PLATE Part #: 5JW-1482K-01-00 Required per assembly: 1 ~~$5.99~~ $3.67 - + Add to cart
24	REED VALVE ASSEMBLY Part #: 5JW-14890-00-00 Required per assembly: 1 ~~$71.98~~ $59.27 - + Add to cart
25	CAP, CASE Part #: 2HC-14889-00-00 Required per assembly: 1 ~~$18.98~~ $14.52 - + Add to cart
26	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-06020-00 Required per assembly: 4 ~~$2.64~~ $2.01 - + Add to cart
27	PLUG, OIL Part #: 3Y1-15363-10-00 Required per assembly: 1 ~~$19.98~~ $16.78 - + Add to cart
28	O-RING (646) Part #: 93210-19123-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$8.99~~ $6.79 - + Add to cart
29	PIPE, BREATHER, 1 Part #: 2HC-11166-00-00 Required per assembly: 1 ~~$24.98~~ $20.61 - + Add to cart
30	CLIP Part #: 90467-100A1-00 Required per assembly: 1 ~~$8.49~~ $6.27 - + Add to cart
31	BOLT Part #: 90109-066F0-00 Required per assembly: 4 ~~$9.49~~ $6.27 - + Add to cart
32	RUBBER, MOUNT, 1 Part #: 5VY-1111G-00-00 Required per assembly: 4 ~~$13.49~~ $11.14 - + Add to cart
33	GASKET, CYLINDER, HEAD, 1 Part #: 2HC-11181-00-00 Required per assembly: 1 ~~$42.99~~ $35.34 - + Add to cart
34	BOLT, SOCKET Part #: 91317-06065-00 Required per assembly: 2 ~~$4.04~~ $3.21 - + Add to cart
35	BOLT Part #: 90109-06293-00 Required per assembly: 1 ~~$15.49~~ $12.17 - + Add to cart
36	RUBBER, MOUNT, 1 Part #: 5VY-1111G-00-00 Required per assembly: 1 ~~$13.49~~ $11.14 - + Add to cart
