Stand & Footrest 2 replacement parts for 2022 Yamaha YZF-R7 WGP 60th

OEM Parts Yamaha 2022 Yamaha YZF R7 WGP 60th Stand & Footrest 2

STAND & FOOTREST 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BRACKET, ADAPTER, 2 Part #: BEB-274A4-00-00 Required per assembly: 1 ~~$180.99~~ $132.83 - + Add to cart
2	BOLT, HEX, SOCKET, BUTTON Part #: 90111-10006-00 Required per assembly: 2 ~~$5.99~~ $4.54 - + Add to cart
3	FOOTREST 4 Part #: B7N-27461-00-00 Required per assembly: 1 ~~$19.48~~ $15.27 - + Add to cart
4	PIN, CLEVIS Part #: 91702-08040-00 Required per assembly: 1 ~~$4.84~~ $3.99 - + Add to cart
5	PIN, COTTER Part #: 91490-25020-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$3.45~~ $2.87 - + Add to cart
6	SPRING, TORSION Part #: 90508-18135-00 Required per assembly: 1 ~~$11.49~~ $7.26 - + Add to cart
7	BOLT Part #: 90109-08269-00 Required per assembly: 1 ~~$6.49~~ $4.75 - + Add to cart
8	BRACKET 3 Part #: BEB-27443-00-00 Required per assembly: 1 ~~$135.99~~ $116.26 - + Add to cart
9	BOLT, BUTTON, HEAD Part #: 92012-06025-00 Required per assembly: 2 ~~$3.39~~ $2.83 - + Add to cart
10	PLATE 2 Part #: BEB-27446-00-00 Required per assembly: 1 ~~$45.99~~ $37.36 - + Add to cart
11	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-08038-00 Required per assembly: 2 ~~$11.49~~ $9.18 - + Add to cart
12	PEDAL, BRAKE Part #: BEB-27211-00-00 Required per assembly: 1 ~~$60.99~~ $48.91 - + Add to cart
13	WASHER, WAVE Part #: 90206-12074-00 Required per assembly: 1 ~~$10.49~~ $6.86 - + Add to cart
14	BOLT Part #: 4BP-27434-11-00 Required per assembly: 1 ~~$4.65~~ $2.51 - + Add to cart
15	WASHER, PLATE Part #: 90201-12051-00 Required per assembly: 1 ~~$8.49~~ $6.17 - + Add to cart
16	WASHER, PLATE Part #: 90201-08053-00 Required per assembly: 1 Not Available
17	SPRING, TENSION Part #: 90506-18022-00 Required per assembly: 1 ~~$8.49~~ $4.87 - + Add to cart
18	HOSE Part #: 90446-15386-00 Required per assembly: 1 ~~$8.49~~ $5.50 - + Add to cart
19	STOP SWITCH ASSEMBLY Part #: BEB-82530-00-00 Required per assembly: 1 ~~$54.99~~ $45.65 - + Add to cart
20	STAY, STOP, SWITCH Part #: BEB-2144G-00-00 Required per assembly: 1 ~~$10.49~~ $8.89 - + Add to cart
21	BOLT Part #: 90109-084F7-00 Required per assembly: 2 ~~$10.49~~ $5.79 - + Add to cart
22	BAND Part #: 1UA-82591-00-00 Required per assembly: 1 ~~$5.49~~ $4.05 - + Add to cart
23	COVER 2 Part #: BEB-27463-00-00 Required per assembly: 1 ~~$152.99~~ $131.80 - + Add to cart
24	BOLT, HEX., SOCKET, BUTTON Part #: 90111-08020-00 Required per assembly: 3 ~~$5.49~~ $3.64 - + Add to cart
25	WASHER PLATE 141181390000 Part #: 90201-08085-00 Required per assembly: 3 ~~$10.49~~ $6.27 - + Add to cart
26	FOOTREST, REAR, 2 Part #: B3L-27441-00-00 Required per assembly: 1 ~~$16.48~~ $11.36 - + Add to cart
27	COLLAR Part #: 90387-06697-00 Required per assembly: 1 ~~$18.48~~ $13.09 - + Add to cart
28	BRACKET 5 Part #: 2CR-2742L-01-00 Required per assembly: 1 ~~$65.98~~ $55.13 - + Add to cart
29	SPRING, COMPRESSION Part #: 90501-12743-00 Required per assembly: 1 ~~$5.49~~ $3.14 - + Add to cart
30	BALL 1/4 Part #: 93501-04011-00 Required per assembly: 1 ~~$9.49~~ $6.15 - + Add to cart
31	WASHER, SPECIAL Part #: 5JJ-27437-01-00 Required per assembly: 1 ~~$7.49~~ $5.79 - + Add to cart
32	BOLT, FLANGE Part #: 95817-06055-00 Required per assembly: 1 ~~$2.35~~ $1.97 - + Add to cart
33	NUT, U, FLANGE Part #: 95604-06200-00 Required per assembly: 1 ~~$2.95~~ $2.31 - + Add to cart
34	COLLAR Part #: 90387-06358-00 Required per assembly: 2 ~~$3.89~~ $2.74 - + Add to cart
35	STOPPER Part #: BEB-27314-00-00 Required per assembly: 1 ~~$44.99~~ $34.34 - + Add to cart
36	BOLT, FLANGE Part #: 95817-08035-00 Required per assembly: 2 ~~$10.49~~ $6.55 - + Add to cart
37	CLAMP Part #: 90464-14010-00 Required per assembly: 1 ~~$3.64~~ $3.05 - + Add to cart
