OEM Parts Honda 2023 Honda CRF450RL Steering Stem

2023 Honda CRF450RL - Steering Stem

STEERING STEM Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 09
001

REFLECTOR, FR., REFLEX

Part #: 33741-KTG-U01 Required per assembly: 2
$9.61
$8.74
-
+
Add to cart
002

STAY, REFLECTOR

Part #: 33745-MKE-A50 Required per assembly: 2
$17.85
$14.89
-
+
Add to cart
003

COLLAR, REFLECTOR

Part #: 33747-MKE-A50 Required per assembly: 4
$3.41
-
+
Add to cart
004

GUIDE, FR.

Part #: 45468-KRN-A90 Required per assembly: 1
$15.80
$13.17
-
+
Add to cart
005

DUST SEAL

Part #: 53214-KZ3-861 Required per assembly: 1
$5.91
$5.29
-
+
Add to cart
006

DUST SEAL

Part #: 53214-KZ4-701 Required per assembly: 1
$8.56
$7.43
-
+
Add to cart
007

STEM, SUB-ASSEMBLY, STEERING

Part #: 53219-MKE-A00 Required per assembly: 1
$652.20
$527.93
-
+
Add to cart
008

THREAD

Part #: 53229-KZ4-J30 Required per assembly: 1
$21.59
$18.01
-
+
Add to cart
009

BOLT, FLANGE, (6X16)

Part #: 90104-KRN-A90 Required per assembly: 1
$3.29
$3.06
-
+
Add to cart
010

BOLT, FLANGE, (8X45)

Part #: 90107-KZ4-J40 Required per assembly: 4
$3.10
$2.89
-
+
Add to cart
011

NUT, U, (6MM)

Part #: 90301-473-003 Required per assembly: 2
$5.46
$4.96
-
+
Add to cart
012

BEARING, HEAD, PIPE

Part #: 91015-KZ4-701 Required per assembly: 2
$44.42
$37.05
-
+
Add to cart
