OEM Parts Honda 2023 Honda GL1800 Reverse Shift Actuator

2023 Honda GL1800 Gold Wing - Reverse Shift Actuator

REVERSE SHIFT ACTUATOR Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
E 13
001

COLLAR

Part #: 19052-MB4-880 Required per assembly: 1
$5.06
$4.60
-
+
Add to cart
002

CABLE, REVERSE

Part #: 24810-MKC-A20 Required per assembly: 1
$47.59
$38.53
-
+
Add to cart
003

CABLE, NEUTRAL

Part #: 24820-MKC-A20 Required per assembly: 1
$47.59
$38.53
-
+
Add to cart
004

ACTR, REVERSE, SHIFT

Part #: 36800-MCA-671 Required per assembly: 1
$226.60
$185.24
-
+
Add to cart
005

RUBBER, RR.

Part #: 80101-310-000 Required per assembly: 1
$3.01
$2.80
-
+
Add to cart
006

CLAMP, REVERSE, CABLE

Part #: 90655-MKC-A20 Required per assembly: 1
$4.31
-
+
Add to cart
007

NUT, FLANGE, (6MM)

Part #: 94050-06080 Required per assembly: 4 Note: Sold in multiples of 5 only
$1.73
$1.59
-
+
Add to cart
008

WASHER, PLAIN, (6MM)

Part #: 94101-06800 Required per assembly: 4
Not Available
009

BOLT, FLANGE, (6X25)

Part #: 95701-06025-08 Required per assembly: 1
$2.79
$2.60
-
+
Add to cart
010

BOLT, FLANGE, (6X50)

Part #: 95701-06050-08 Required per assembly: 3
$3.14
$2.91
-
+
Add to cart
