Front Knuckle - Driveshaft replacement parts for 2023 Honda SXS1000M3P

OEM Parts Honda 2023 Honda SXS1000M3P Front Knuckle - Driveshaft

FRONT KNUCKLE - DRIVESHAFT Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 16
001	BAND, SHAFT, BOOT Part #: 44327-TZ4-A01 Required per assembly: 2 $6.01 - + Add to cart
002	BAND, DYNAMIC, DAMPER Part #: 44329-T7J-H01 Required per assembly: 2 $12.88 $11.89 - + Add to cart
003	BAND, A, OUTBOARD Part #: 42231-HL4-AK1 Required per assembly: 2 $10.36 $9.11 - + Add to cart
004	BAND, A, INBOARD Part #: 42234-HL4-AK1 Required per assembly: 2 $15.40 $13.04 - + Add to cart
005	RING, SNAP Part #: 42228-HL4-A01 Required per assembly: 2 $3.54 - + Add to cart
006	JOINT, FR., INBOARD Part #: 44220-HL4-A01 Required per assembly: 2 $181.33 $150.63 - + Add to cart
008	BOOT, SET, FR., INBOARD Part #: 44260-HL4-AK1 Required per assembly: 2 $71.15 $59.07 - + Add to cart
009	BOOT, SET, FR. Part #: 44240-HL4-AK1 Required per assembly: 2 $106.82 $89.15 - + Add to cart
010	SHAFT, SET, FR., DRIVE Part #: 44250-HL4-AK1 Required per assembly: 1 $311.49 $254.63 - + Add to cart
011	SHAFT, SET, FR., DRIVE Part #: 44250-HL4-AK1 Required per assembly: 1 $311.49 $254.63 - + Add to cart
012	SET-RING (26X1.8) Part #: 44319-SR1-003 Required per assembly: 2 $4.64 $4.22 - + Add to cart
013	CIRCLIP Part #: 44338-S0X-A01 Required per assembly: 2 $5.92 - + Add to cart
014	COVER, R., FR., DISK Part #: 45255-HL4-AK0 Required per assembly: 1 $6.05 $5.33 - + Add to cart
015	COVER, L., FR., DISK Part #: 45256-HL4-AK0 Required per assembly: 1 $6.05 $5.33 - + Add to cart
016	KNUCKLE, ASSEMBLY, R., FR. Part #: 51200-HL4-AK0 Required per assembly: 1 $133.82 $106.72 - + Add to cart
017	KNUCKLE, ASSEMBLY, L., FR. Part #: 51250-HL4-AK0 Required per assembly: 1 $133.82 $109.39 - + Add to cart
018	GUARD, R., FR. Part #: 51325-HL4-A00 Required per assembly: 1 $3.32 - + Add to cart
019	GUARD, L., FR. Part #: 51326-HL4-A00 Required per assembly: 1 $3.32 - + Add to cart
020	BOLT, SHOULDER, (6X20), (5.0) Part #: 90109-HL6-A00 Required per assembly: 2 $3.17 $3.00 - + Add to cart
021	BOLT, FLANGE, (6MM) Part #: 90111-KT1-780 Required per assembly: 4 $15.46 $14.05 - + Add to cart
022	CIRCLIP (INNER) (75) Part #: 90651-HL3-A40 Required per assembly: 2 $11.52 $11.31 - + Add to cart
024	BEARING (40X74X36) Part #: 91054-HL3-A41 Required per assembly: 2 $38.56 $33.68 - + Add to cart
