OEM Parts Honda 2023 Honda SXS1000M6D Wheel

2023 Honda SXS1000M6D Pioneer 1000-6 Deluxe - Wheel

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 20
001

HUB, SUB-ASSEMBLY, WHEEL

Part #: 42615-HL4-AK0 Required per assembly: 4
$338.91
$270.28
-
+
Add to cart
002

WHEEL, SUB-ASSEMBLY, RR.

Part #: 42650-HL4-AK0 Required per assembly: 2
$275.15
$244.43
-
+
Add to cart
003

TIRE (27X11.00R14 NHS) (OTR)

Part #: 42711-HL4-A91 Required per assembly: 2
$205.81
-
+
Add to cart
004

VALVE, RIM, (TR412)

Part #: 42753-HL3-A00 Required per assembly: 4
$5.74
$5.22
-
+
Add to cart
005

DISK, BRAKE

Part #: 43251-HL8-A11 Required per assembly: 4
$148.58
$118.49
-
+
Add to cart
006

WHEEL, SUB-ASSEMBLY, FR.

Part #: 44650-HL4-AK0 Required per assembly: 2
$279.15
$247.62
-
+
Add to cart
007

TIRE (27X9.00R14 NHS) (OTR)

Part #: 44711-HL4-A91 Required per assembly: 2
$211.78
-
+
Add to cart
008

CAP, WHEEL, CENTER

Part #: 44732-HR6-A60 Required per assembly: 4
$8.51
$7.85
-
+
Add to cart
009

BOLT, WHEEL

Part #: 90113-SM1-005 Required per assembly: 16
$3.27
$2.81
-
+
Add to cart
010

BOLT, DISK, (8X24)

Part #: 90116-HP6-A00 Required per assembly: 16
$4.11
$3.74
-
+
Add to cart
011

NUT, AXLE, (22MM)

Part #: 90306-HL4-AK0 Required per assembly: 4
$11.28
$9.62
-
+
Add to cart
012

NUT, WHEEL

Part #: 90307-MCA-000 Required per assembly: 16
$6.72
$5.94
-
+
Add to cart
013

WASHER, PLAIN, (43MM)

Part #: 90506-HL4-AK0 Required per assembly: 4
$2.55
$2.36
-
+
Add to cart
014

PIN, SPLIT, (4.0X40)

Part #: 94201-40400 Required per assembly: 4
$1.73
$1.59
-
+
Add to cart
