Rear Shock Absorber (1) replacement parts for 2023 Honda SXS1000S4X

OEM Parts Honda 2023 Honda SXS1000S4X Rear Shock Absorber (1)

REAR SHOCK ABSORBER (1) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 39
001	KNOB, DAMPING, ADJUST Part #: 51426-HL4-F41 Required per assembly: 2 Note: Area: 3A 3AC $7.04 $6.52 - + Add to cart
002	DECAL, BAND Part #: 51427-HL6-A41 Required per assembly: 2 Note: Area: 3A 3AC $6.25 $5.75 - + Add to cart
003	DECAL, RESERVOIR Part #: 51428-HL6-A51 Required per assembly: 2 Note: Area: 3A 3AC $13.82 $11.02 - + Add to cart
004	DECAL, BASE, VALVE Part #: 51429-HL4-F41 Required per assembly: 2 Note: Area: 3A 3AC $11.60 $9.98 - + Add to cart
005	REDUCER, EYELET Part #: 51431-HL6-A11 Required per assembly: 4 Note: Area: 3A 3AC $7.95 $7.11 - + Add to cart
005	COLLAR, BEARING Part #: 51431-HL6-AG2 Required per assembly: 4 Note: Area: A AC $6.47 $5.16 - + Add to cart
006	CUSHION ASSEMBLY, R. RR. (TYPE1) (SHOWA) Part #: 52400-HL7-AF5ZB Required per assembly: 1 Note: Area: A AC $925.33 $762.95 - + Add to cart
006	CUSHION, ASSEMBLY, R., RR., (TYPE2), (FOX) Part #: 52400-HL7-A41ZA Required per assembly: 1 Note: Color: NHC59-(MAT ABYSS BLACK), Area: 3A 3AC $1,218.03 $1,038.96 - + Add to cart
006	CUSHION, ASSEMBLY, R., RR., (TYPE4), (FOX) Part #: 52400-HL7-A41ZC Required per assembly: 1 Note: Color: YR339-(PEARL TANGELO ORANGE), Area: 3A 3AC $1,406.89 $1,281.64 - + Add to cart
007	CUSHION, ASSEMBLY, L., RR., (TYPE2), (FOX) Part #: 52500-HL7-A41ZA Required per assembly: 1 Note: Color: NHC59-(MAT ABYSS BLACK), Area: 3A 3AC $1,272.95 $1,086.79 - + Add to cart
007	CUSHION, ASSEMBLY, L., RR., (TYPE4), (FOX) Part #: 52500-HL7-A41ZC Required per assembly: 1 Note: Color: YR339-(PEARL TANGELO ORANGE), Area: 3A 3AC $845.45 $728.21 - + Add to cart
007	CUSHION ASSEMBLY, L. RR. (TYPE1) (SHOWA) Part #: 52500-HL7-AF5ZB Required per assembly: 1 Note: Area: A AC $968.56 $797.43 - + Add to cart
008	PROTECTOR, CUSHION Part #: 52610-HL6-A11 Required per assembly: 2 Note: Area: 3A 3AC $19.42 $15.49 - + Add to cart
008	PROTECTOR, LARGE Part #: 52610-HL6-AG2 Required per assembly: 2 Note: Area: A AC $35.07 $27.97 - + Add to cart
009	BOLT, FLANGE, (12X57) Part #: 90101-HL6-A00 Required per assembly: 4 $2.15 $1.99 - + Add to cart
010	BOLT, PROTECTOR Part #: 90101-HL6-AF2 Required per assembly: 6 Note: Area: A AC $2.09 $1.67 - + Add to cart
010	SCREW, SPECIAL, PAN, (6X12) Part #: 90102-HL6-A01 Required per assembly: 6 Note: Area: 3A 3AC $63.58 $5.29 - + Add to cart
011	BOLT, TORX Part #: 90110-HL4-F41 Required per assembly: 2 Note: Area: 3A 3AC $2.41 $2.23 - + Add to cart
012	NUT (12MM) Part #: 90305-HC4-000 Required per assembly: 4 $5.60 $5.09 - + Add to cart
013	RING, RETAINING, (1.290X0.050) Part #: 90651-HL6-A11 Required per assembly: 8 Note: Area: 3A 3AC $5.81 - + Add to cart
013	RING, STOPPER Part #: 90651-HL6-AG2 Required per assembly: 8 Note: Area: A AC $16.07 $12.82 - + Add to cart
014	BEARING, SPHERICAL Part #: 91075-HL6-AG2 Required per assembly: 2 Note: Area: A AC $21.20 $16.91 - + Add to cart
014	BEARING, SPHERICAL, (UPPER) Part #: 91075-HL6-A11 Required per assembly: 2 Note: Area: 3A 3AC $55.07 $45.02 - + Add to cart
015	BEARING, SPHERICAL, (LOWER) Part #: 91077-HL6-A01 Required per assembly: 2 Note: Area: 3A 3AC $29.31 $23.97 - + Add to cart
015	BEARING, SEALED SPHERICAL Part #: 91076-HL6-AF2 Required per assembly: 2 Note: Area: A AC $20.67 $16.49 - + Add to cart
016	O-RING (20X5) Part #: 91351-HL6-AG2 Required per assembly: 4 Note: Area: A AC $7.55 $6.02 - + Add to cart
016	O-RING (0.787X0.210) Part #: 91351-HL6-A11 Required per assembly: 4 Note: Area: 3A 3AC $3.03 $2.81 - + Add to cart
017	DECAL, RESERVOIR Part #: 51428-HL6-AG2 Required per assembly: 2 Note: Area: A AC $20.11 $16.04 - + Add to cart
018	LABEL, RR. Part #: 87516-KZ1-600 Required per assembly: 2 Note: Area: A AC $6.74 $6.13 - + Add to cart
