Front Final Gear replacement parts for 2023 Honda SXS1000S4X

OEM Parts Honda 2023 Honda SXS1000S4X Front Final Gear

FRONT FINAL GEAR Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 18
001	BEARING, SET, NEEDLE Part #: 06910-HR6-B00 Required per assembly: 1 ~~$34.36~~ $30.83 - + Add to cart
002	CAP, VALVE, ADJ. Part #: 12361-300-000 Required per assembly: 1 Not Available
003	STAY, HARNESS, CLIP Part #: 30535-HL6-A00 Required per assembly: 1 ~~$1.94~~ $1.78 - + Add to cart
004	SUB-HARNESS, FR., DIFFERENTIAL Part #: 32106-HL6-A00 Required per assembly: 1 ~~$9.07~~ $7.74 - + Add to cart
005	SENSOR, ASSEMBLY, SPEED Part #: 37700-KZR-601 Required per assembly: 2 ~~$53.38~~ $42.57 - + Add to cart
006	SENSOR, R., FR., WHEEL, SPEED Part #: 38520-HL6-A01 Required per assembly: 1 ~~$133.36~~ $109.58 - + Add to cart
007	SENSOR, L., FR., WHEEL, SPEED Part #: 38525-HL6-A01 Required per assembly: 1 ~~$135.36~~ $112.87 - + Add to cart
008	DIFFERENTIAL, ASSEMBLY, FR. Part #: 41200-HL6-A01 Required per assembly: 1 Note: Area: 3A 3AC 4A 4AC ~~$389.49~~ $339.25 - + Add to cart
008	DIFFERENTIAL ASSEMBLY, FR. Part #: 41200-HL6-AF1 Required per assembly: 1 Note: Area: 5A 5AC A AC ~~$415.69~~ $346.51 - + Add to cart
009	CASE, FR. DIFFERENTIAL Part #: 41211-HL6-AF1 Required per assembly: 1 Note: Area: 5A 5AC A AC ~~$123.42~~ $98.43 - + Add to cart
009	CASE, FR., DIFFERENTIAL Part #: 41211-HL6-A01 Required per assembly: 1 Note: Area: 3A 3AC 4A 4AC ~~$117.95~~ $94.06 - + Add to cart
010	CAP, FR. DIFFERENTIAL CASE Part #: 41212-HL6-AF1 Required per assembly: 1 Note: Area: 5A 5AC A AC ~~$77.07~~ $61.47 - + Add to cart
010	CAP, FR., DIFFERENTIAL, CASE Part #: 41212-HL6-A01 Required per assembly: 1 Note: Area: 3A 3AC 4A 4AC ~~$63.53~~ $52.71 - + Add to cart
011	CAM, FACE, (66), (A) Part #: 41231-HL6-A01 Required per assembly: 2 ~~$32.42~~ $25.85 - + Add to cart
012	FOLLOWER, SET, CAM Part #: 41240-HL4-A01 Required per assembly: 1 ~~$51.36~~ $43.80 - + Add to cart
013	SHIM A (1.3) Part #: 41251-HL4-A01 Required per assembly: 1 $3.97 - + Add to cart
013	SHIM B (1.4) Part #: 41252-HL4-A01 Required per assembly: 1 $3.97 - + Add to cart
013	SHIM C (1.5) Part #: 41253-HL4-A01 Required per assembly: 1 $3.97 - + Add to cart
013	SHIM D (1.6) Part #: 41254-HL4-A01 Required per assembly: 1 $3.97 - + Add to cart
013	SHIM E (1.7) Part #: 41255-HL4-A01 Required per assembly: 1 $3.97 - + Add to cart
013	SHIM A (1.1) Part #: 41251-HL6-A01 Required per assembly: 1 $4.44 - + Add to cart
013	SHIM B (1.2) Part #: 41252-HL6-A01 Required per assembly: 1 $4.44 - + Add to cart
014	SPRING, DIFFERENTIAL, SIDE, CONED Part #: 41261-HL6-A01 Required per assembly: 1 ~~$9.53~~ $8.42 - + Add to cart
015	GEAR, FR., FINAL Part #: 41400-HL6-AA3 Required per assembly: 1 Note: Area: 3A 3AC 4A 4AC ~~$1,567.78~~ $1,250.31 - + Add to cart
015	GEAR, FR., FINAL Part #: 41400-HL6-AF2 Required per assembly: 1 Note: Area: 5A 5AC A AC ~~$1,567.78~~ $1,250.31 - + Add to cart
016	RING, STOPPER Part #: 41405-HA7-670 Required per assembly: 1 ~~$4.28~~ $3.89 - + Add to cart
017	CASE, SUB-ASSY., FR. Part #: 41411-HL6-AF1 Required per assembly: 1 Note: Area: 5A 5AC A AC ~~$129.78~~ $103.50 - + Add to cart
017	CASE SUB-ASSEMBLY, FR. FINAL GEAR Part #: 41411-HL6-A03 Required per assembly: 1 Note: Area: 3A 3AC 4A 4AC ~~$133.53~~ $106.49 - + Add to cart
018	COVER SUB-ASSEMBLY, FR. FINAL GEAR Part #: 41412-HL6-AF0 Required per assembly: 1 Note: Area: 5A 5AC A AC ~~$144.96~~ $115.61 - + Add to cart
018	COVER, SUB-ASSEMBLY, FR., FINAL, GEAR Part #: 41412-HL4-F43 Required per assembly: 1 Note: Area: 3A 3AC 4A 4AC ~~$136.96~~ $116.13 - + Add to cart
019	SHIM G (2.00) Part #: 41454-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM F (1.94) Part #: 41453-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM B (1.70) Part #: 41448-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM E (1.88) Part #: 41452-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM C (1.76) Part #: 41449-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM H (2.06) Part #: 41455-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM I (2.12) Part #: 41456-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM J (2.18) Part #: 41457-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM A (1.64) Part #: 41447-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
019	SHIM D (1.82) Part #: 41451-HM8-000 Required per assembly: 1 ~~$9.60~~ $8.27 - + Add to cart
020	CLUTCH, ASSEMBLY, FR., FINAL Part #: 41500-HL6-AA1 Required per assembly: 1 ~~$1,227.76~~ $1,068.13 - + Add to cart
021	JOINT, FR., FINAL, CLUTCH Part #: 41515-HL6-AA1 Required per assembly: 1 ~~$152.00~~ $125.57 - + Add to cart
022	GEAR, FR., PINION, (13T) Part #: 41521-HL6-A00 Required per assembly: 1 ~~$255.87~~ $207.12 - + Add to cart
023	GEAR, FR., RING, (44T) Part #: 41531-HL4-A00 Required per assembly: 1 ~~$119.27~~ $96.54 - + Add to cart
024	SPACER X (1.14) Part #: 41561-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER Y (1.20) Part #: 41562-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER Z (1.76) Part #: 41563-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER J (1.80) Part #: 41564-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER K (1.86) Part #: 41565-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER L (1.92) Part #: 41566-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER M (1.98) Part #: 41567-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER N (2.04) Part #: 41568-HL4-A00 Required per assembly: 2 $3.49 - + Add to cart
024	SPACER C (1.94) Part #: 41542-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.44 - + Add to cart
024	SPACER D (2.00) Part #: 41543-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.44 - + Add to cart
024	SPACER E (2.06) Part #: 41544-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.11 - + Add to cart
024	SPACER B (1.88) Part #: 41541-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.11 - + Add to cart
024	SPACER A (1.82) Part #: 41540-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.44 - + Add to cart
024	SPACER F (2.12) Part #: 41545-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.44 - + Add to cart
024	SPACER G (2.18) Part #: 41546-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.44 - + Add to cart
024	SPACER H (2.24) Part #: 41547-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.44 - + Add to cart
024	SPACER I (2.30) Part #: 41548-HA0-000 Required per assembly: 2 ~~$12.98~~ $11.44 - + Add to cart
025	STAY, CLUTCH, COVER Part #: 41711-HL6-A00 Required per assembly: 1 ~~$10.71~~ $9.39 - + Add to cart
026	COVER, FR., FINAL, CLUTCH Part #: 41713-HL6-A00 Required per assembly: 1 ~~$169.31~~ $138.40 - + Add to cart
027	BOLT, FLG, (10X213) Part #: 90102-HP6-A00 Required per assembly: 1 ~~$7.40~~ $6.49 - + Add to cart
028	BOLT, FLANGE, (10X165) Part #: 90103-GFZ-000 Required per assembly: 2 ~~$6.20~~ $5.52 - + Add to cart
029	BOLT, FLANGE, (10X23) Part #: 90104-HL4-A00 Required per assembly: 10 ~~$26.38~~ $23.98 - + Add to cart
030	BOLT, SEALING, (8MM) Part #: 90109-371-000 Required per assembly: 1 ~~$3.73~~ $3.39 - + Add to cart
031	BOLT, FLANGE, (8X27) Part #: 90133-HP5-600 Required per assembly: 6 ~~$3.70~~ $3.36 - + Add to cart
032	BOLT, FLANGE, (10X35) Part #: 90134-HP5-600 Required per assembly: 2 ~~$4.85~~ $4.41 - + Add to cart
033	NUT, LOCK, (64MM) Part #: 90242-MB0-000 Required per assembly: 1 ~~$37.68~~ $31.42 - + Add to cart
034	NUT (10MM) Part #: 90305-HC0-770 Required per assembly: 3 ~~$4.30~~ $3.91 - + Add to cart
035	GASKET (8MM) Part #: 90471-580-000 Required per assembly: 1 $3.96 - + Add to cart
036	JOINT, BREATHER, TUBE Part #: 90652-HF7-003 Required per assembly: 1 ~~$11.04~~ $9.43 - + Add to cart
037	CLIP, SPLASH, GUARD, (EACH) Part #: 90653-HC4-900 Required per assembly: 2 ~~$1.67~~ $1.52 - + Add to cart
038	CIRCLIP, SPECIAL, (41.7) Part #: 90660-HL6-A00 Required per assembly: 1 $4.25 - + Add to cart
039	CLIP, CABLE Part #: 90682-MGS-D41 Required per assembly: 3 $3.96 - + Add to cart
040	BEARING (6206) Part #: 91051-HL4-A01 Required per assembly: 1 ~~$9.68~~ $9.10 - + Add to cart
041	BEARING (35X68X16) Part #: 91052-HL6-AF1 Required per assembly: 1 ~~$17.09~~ $13.98 - + Add to cart
042	BEARING, RADIAL, BALL, (35X55X13) Part #: 91053-HL6-A01 Required per assembly: 1 ~~$81.44~~ $66.57 - + Add to cart
043	BEARING (35X60X14) Part #: 91053-HR3-W51 Required per assembly: 1 Note: Area: 3A 3AC 4A 4AC ~~$6.22~~ $5.59 - + Add to cart
043	BEARING, RADIAL BALL (35X60X14) (NTN) Part #: 91062-HL6-AF1 Required per assembly: 1 Note: Area: 5A 5AC A AC ~~$13.14~~ $10.48 - + Add to cart
044	OIL SEAL (53X70X7) Part #: 91254-HL4-F43 Required per assembly: 2 ~~$8.40~~ $7.37 - + Add to cart
045	O-RING (30.8MM) Part #: 91302-001-020 Required per assembly: 1 ~~$4.74~~ $4.31 - + Add to cart
046	O-RING (14.8X2.4) Part #: 91356-MA6-005 Required per assembly: 2 ~~$2.86~~ $2.65 - + Add to cart
047	O-RING (1.5X9.5) Part #: 91306-MG3-000 Required per assembly: 2 ~~$3.29~~ $3.06 - + Add to cart
048	O-RING (69.5X3) Part #: 91314-MG7-003 Required per assembly: 1 ~~$10.70~~ $9.17 - + Add to cart
049	CLIP, CONNECTOR Part #: 91535-STK-003 Required per assembly: 1 ~~$7.36~~ $7.01 - + Add to cart
050	CLIP, CONNECTOR, (DARK, BROWN) Part #: 91535-TA0-003 Required per assembly: 1 ~~$4.99~~ $4.89 - + Add to cart
051	NUT, FLANGE, (6MM) Part #: 94050-06000 Required per assembly: 1 ~~$1.73~~ $1.59 - + Add to cart
052	CLIP, TUBE, (B6.5) Part #: 95002-02650 Required per assembly: 1 ~~$2.49~~ $2.31 - + Add to cart
053	BULK HOSE (3.5X8000) Part #: 95005-35008-10M Required per assembly: 1 ~~$148.30~~ $140.69 - + Add to cart
054	BOLT, FLANGE, (6X16) Part #: 95701-06016-00 Required per assembly: 2 Note: 95701-06016-08* ~~$2.63~~ $2.44 - + Add to cart
055	BOLT, FLANGE, (8X25) Part #: 95701-08025-00 Required per assembly: 3 ~~$2.78~~ $2.58 - + Add to cart
056	BOLT, FLANGE, (6X14) Part #: 96001-06014-00 Required per assembly: 5 ~~$2.79~~ $2.60 - + Add to cart
