Windshield replacement parts for 2023 Yamaha XMAX

OEM Parts Yamaha 2023 Yamaha XMAX Windshield

WINDSHIELD Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	GRILL, AIR, INTAKE, 1 Part #: BKA-F837N-00-00 Required per assembly: 1 $34.50 - + Add to cart
2	BOLT, WITH, WASHER Part #: 90119-06051-00 Required per assembly: 3 $9.49 $6.18 - + Add to cart
3	SCREW, ROUND, TAPPING, (50C1) Part #: 90160-05808-00 Required per assembly: 2 $0.55 $0.41 - + Add to cart
4	RIVET Part #: 90269-06813-00 Required per assembly: 4 $0.40 $0.33 - + Add to cart
5	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 $5.59 $4.65 - + Add to cart
6	STAY 1 Part #: BKA-F8321-00-00 Required per assembly: 1 $149.63 - + Add to cart
7	GROMMET Part #: 90480-14229-00 Required per assembly: 5 $9.49 $6.05 - + Add to cart
8	GROMMET Part #: 90480-13567-00 Required per assembly: 1 $5.49 $3.81 - + Add to cart
9	COLLAR Part #: 90387-068N8-00 Required per assembly: 5 $1.89 $1.84 - + Add to cart
10	BOLT, WITH, WASHER Part #: 90119-06268-00 Required per assembly: 3 $2.45 $2.03 - + Add to cart
11	BOLT, FLANGE Part #: 95817-08055-00 Required per assembly: 2 $4.21 $2.77 - + Add to cart
12	REINFORCEMENT 1 Part #: BKA-F8427-00-00 Required per assembly: 1 $5.49 $4.28 - + Add to cart
13	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 $5.49 $3.84 - + Add to cart
14	BOX, BATTERY, 1 Part #: BKA-H212B-00-00 Required per assembly: 1 $15.49 $12.59 - + Add to cart
15	BOLT Part #: 90109-068B5-00 Required per assembly: 3 $0.50 $0.38 - + Add to cart
16	WINDOW, FR. Part #: BKA-F8381-00-00 Required per assembly: 1 $29.98 $21.74 - + Add to cart
17	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06245-00 Required per assembly: 4 $9.49 $6.15 - + Add to cart
18	NUT Part #: 90179-05003-00 Required per assembly: 4 $6.49 $4.81 - + Add to cart
19	COVER, FRONT, 2 Part #: BKA-F286F-00-00 Required per assembly: 1 $32.68 - + Add to cart
20	SCREW, ROUND, TAPPING, (50C1) Part #: 90160-05808-00 Required per assembly: 2 $0.55 $0.41 - + Add to cart
21	GROMMET Part #: 90480-01559-00 Required per assembly: 2 $6.49 $4.72 - + Add to cart
22	GROMMET Part #: 90480-13014-00 Required per assembly: 1 $9.49 $6.73 - + Add to cart
23	RIVET Part #: 90269-06813-00 Required per assembly: 3 $0.40 $0.33 - + Add to cart
24	BODY, COWLING Part #: BKA-F8351-00-P1 Required per assembly: 1 $51.00 - + Add to cart
25	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 1 $5.59 $4.65 - + Add to cart
26	BODY, FRONT, UNDER, 1 Part #: BKA-F835J-00-P1 Required per assembly: 1 $29.98 $27.61 - + Add to cart
27	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 $5.59 $4.65 - + Add to cart
28	CLAMP Part #: 90464-04004-00 Required per assembly: 4 $0.54 $0.46 - + Add to cart
29	BODY, COWLING, 2 Part #: BKA-F8377-00-P1 Required per assembly: 1 $51.00 - + Add to cart
30	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 1 $5.59 $4.65 - + Add to cart
31	BODY, FRONT, UNDER, 2 Part #: BKA-F835K-00-P1 Required per assembly: 1 $52.53 - + Add to cart
32	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 $5.59 $4.65 - + Add to cart
33	CLAMP Part #: 90464-04004-00 Required per assembly: 4 $0.54 $0.46 - + Add to cart
34	COVER, FLASHER, 1 Part #: BKA-F83D3-00-00 Required per assembly: 1 $31.89 - + Add to cart
35	DAMPER, PLATE Part #: 90520-06827-00 Required per assembly: 2 $0.30 - + Add to cart
36	SCREW, ROUND, TAPPING, (50C1) Part #: 90160-05808-00 Required per assembly: 2 $0.55 $0.41 - + Add to cart
37	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 6 $5.59 $4.65 - + Add to cart
38	RIVET Part #: 90269-06813-00 Required per assembly: 4 $0.40 $0.33 - + Add to cart
39	COVER, FRONT Part #: BKA-F2865-00-P1 Required per assembly: 1 $57.99 $48.25 - + Add to cart
40	COVER, BATTERY Part #: BKA-H2129-00-00 Required per assembly: 1 $5.49 $4.48 - + Add to cart
41	CLAMP Part #: 90464-04004-00 Required per assembly: 3 $0.54 $0.46 - + Add to cart
42	SCREW, ROUND, TAPPING, (50C1) Part #: 90160-05808-00 Required per assembly: 2 $0.55 $0.41 - + Add to cart
43	SCREEN Part #: BKA-F837U-00-00 Required per assembly: 1 $142.60 - + Add to cart
44	SCREW, BINDING Part #: 90154-05011-00 Required per assembly: 4 $4.95 $3.67 - + Add to cart
45	COVER 5 Part #: BKA-F842A-00-00 Required per assembly: 1 $3.60 $2.42 - + Add to cart
46	COVER 6 Part #: BKA-F843C-00-00 Required per assembly: 1 $3.60 $2.42 - + Add to cart
47	RIVET Part #: 90269-08007-00 Required per assembly: 2 $5.49 $3.67 - + Add to cart
48	LABEL, NOTICE, WIND Part #: B74-F815K-01-00 Required per assembly: 1 $1.00 $0.91 - + Add to cart
49	EMBLEM Part #: B74-F414B-10-00 Required per assembly: 1 $4.84 $4.40 - + Add to cart
50	EMBLEM Part #: B74-F414B-10-00 Required per assembly: 1 $4.84 $4.40 - + Add to cart
51	EMBLEM Part #: 2PH-F1737-00-00 Required per assembly: 1 Not Available
