Engine Hatch 1 replacement parts for 2023 Yamaha FX Cruiser SVHO with Audio

OEM Parts Yamaha 2023 Yamaha FX Cruiser SVHO with Audio Engine Hatch 1

ENGINE HATCH 1 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PACKING 4 Part #: F1K-U266C-10-00 Required per assembly: 2 $5.08 $2.27 - + Add to cart
2	HOOK, LID, LOCK Part #: F5G-U517F-02-00 Required per assembly: 1 $21.41 $16.62 - + Add to cart
3	NUT Part #: F3X-U517E-00-00 Required per assembly: 2 $6.11 $1.36 - + Add to cart
4	BOLT, WITH, WASHER Part #: 90119-06803-00 Required per assembly: 2 $9.16 $3.84 - + Add to cart
5	BRACKET Part #: F2C-U826C-00-00 Required per assembly: 4 $9.16 $4.22 - + Add to cart
6	RIVET 1 Part #: F4P-U516R-01-00 Required per assembly: 8 $11.21 $5.35 - + Add to cart
7	GLOVE BOX HATCH ASSEMBLY Part #: F5G-U1708-01-00 Required per assembly: 1 $356.99 $344.60 - + Add to cart
8	SEAL Part #: F3X-U2723-00-00 Required per assembly: 1 $7.12 $2.42 - + Add to cart
9	NUT Part #: F3X-U517E-00-00 Required per assembly: 8 $6.11 $1.36 - + Add to cart
10	INNER, CASE Part #: F5G-U591L-00-00 Required per assembly: 1 $87.70 $69.54 - + Add to cart
11	TERMINAL COMP. Part #: F5G-H254B-00-00 Required per assembly: 1 $47.99 $37.77 - + Add to cart
12	PLUG, USB Part #: F5G-H21E1-00-00 Required per assembly: 1 $98.93 $81.63 - + Add to cart
13	HING, HATCH, 1 Part #: F5G-U2811-01-00 Required per assembly: 1 $31.60 $24.92 - + Add to cart
14	GEAR ASSY Part #: F5G-U0210-00-00 Required per assembly: 2 $9.99 $6.86 - + Add to cart
15	SPRING, TORSION Part #: F5G-U1395-01-00 Required per assembly: 2 Not Available
16	PIN, HINGE Part #: F5G-U517R-00-00 Required per assembly: 2 $5.08 $2.48 - + Add to cart
17	E-RING Part #: F5G-U515C-00-00 Required per assembly: 2 $5.08 $1.66 - + Add to cart
18	PACKING CASE Part #: F5G-U519D-01-00 Required per assembly: 1 $50.99 $39.28 - + Add to cart
19	BOLT, WITH, WASHER Part #: 90119-08828-00 Required per assembly: 4 $7.12 $2.57 - + Add to cart
20	GLOVE BOX COVER ASSEMBLY Part #: F5G-U4705-01-00 Required per assembly: 1 $61.18 $51.39 - + Add to cart
21	LABEL, WARNING, UNIFORM, 1 Part #: F5G-U41B1-00-00 Required per assembly: 1 Not Available
22	LOCK Part #: F4N-U2875-00-00 Required per assembly: 1 $7.12 $4.37 - + Add to cart
23	NUT Part #: F3X-U517E-00-00 Required per assembly: 2 $6.11 $1.36 - + Add to cart
24	BOLT, HEX., SOCKET, BUTTON Part #: 90111-06873-00 Required per assembly: 2 $11.21 $5.50 - + Add to cart
25	COVER, CENTER Part #: F5G-U5554-02-00 Required per assembly: 1 $137.68 - + Add to cart
26	PLATE, FIX Part #: F2X-U5175-00-00 Required per assembly: 2 $6.11 $1.97 - + Add to cart
27	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 6 Note: Sold in multiples of 5 only $5.49 $4.97 - + Add to cart
28	BOLT, WITH, WASHER Part #: 90119-06820-00 Required per assembly: 2 $9.16 $3.84 - + Add to cart
29	DAMPER 1 Part #: F5G-U828E-00-00 Required per assembly: 2 $6.11 $1.97 - + Add to cart
30	COLLAR Part #: F5G-U2119-00-00 Required per assembly: 2 $10.18 $5.67 - + Add to cart
31	MAT Part #: F5G-U3844-00-00 Required per assembly: 2 $7.12 $2.95 - + Add to cart
32	SCREW Part #: F3X-U7823-12-00 Required per assembly: 2 $5.99 $1.32 - + Add to cart
33	WASHER, PLATE Part #: 90201-06805-00 Required per assembly: 2 $0.30 $0.28 - + Add to cart
34	GROMMET Part #: F3X-U1338-00-00 Required per assembly: 2 $6.11 $1.66 - + Add to cart
35	COLLAR Part #: F3X-U151R-00-00 Required per assembly: 4 $6.11 $1.13 - + Add to cart
36	BOLT Part #: F3X-U1355-00-00 Required per assembly: 4 $5.08 $0.83 - + Add to cart
37	COVER METER Part #: F5G-U8262-01-00 Required per assembly: 1 $24.46 $18.88 - + Add to cart
38	ORNAMENT, METER Part #: F5G-U826F-01-00 Required per assembly: 1 $53.03 $45.33 - + Add to cart
39	SCREW Part #: F2S-U13C1-00-00 Required per assembly: 4 $7.12 $2.65 - + Add to cart
40	PACKING Part #: F2C-U1743-00-00 Required per assembly: 2 $7.12 $2.10 - + Add to cart
41	COVER, SIDE, 1, (RM9) Part #: F5G-U377B-01-P1 Required per assembly: 1 $228.47 $181.29 - + Add to cart
41	COVER, SIDE, 1, (SSA) Part #: F5G-U377B-01-P5 Required per assembly: 1 $220.31 $214.57 - + Add to cart
42	CUSHION, RUBBER Part #: F1W-U3768-01-00 Required per assembly: 1 $6.11 $1.59 - + Add to cart
43	NUT Part #: F3X-U517E-00-00 Required per assembly: 1 $6.11 $1.36 - + Add to cart
44	SCREW Part #: F3X-U7823-12-00 Required per assembly: 4 $5.99 $1.32 - + Add to cart
45	WASHER, PLATE Part #: 90201-06805-00 Required per assembly: 2 $0.30 $0.28 - + Add to cart
46	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 1 $6.11 $1.51 - + Add to cart
47	COVER, SIDE, 2, (RM9) Part #: F5G-U377C-01-P1 Required per assembly: 1 $228.47 $181.29 - + Add to cart
47	COVER, SIDE, 2, (SSA) Part #: F5G-U377C-01-P5 Required per assembly: 1 $220.31 $214.57 - + Add to cart
48	CUSHION, RUBBER Part #: F1W-U3768-01-00 Required per assembly: 1 $6.11 $1.59 - + Add to cart
49	NUT Part #: F3X-U517E-00-00 Required per assembly: 1 $6.11 $1.36 - + Add to cart
50	SCREW Part #: F3X-U7823-12-00 Required per assembly: 4 $5.99 $1.32 - + Add to cart
51	WASHER, PLATE Part #: 90201-06805-00 Required per assembly: 2 $0.30 $0.28 - + Add to cart
52	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 1 $6.11 $1.51 - + Add to cart
53	SIDE ORNAMENT ASSEMBLY 1 Part #: F3X-U370J-20-00 Required per assembly: 1 $73.43 $69.44 - + Add to cart
53	SIDE ORNAMENT ASSY 1 Part #: F3X-U370J-G0-00 Required per assembly: 1 $118.31 $96.75 - + Add to cart
54	SCREW Part #: F3X-U7823-02-00 Required per assembly: 2 $6.11 $1.51 - + Add to cart
55	PLATE, FIX Part #: F2X-U5175-00-00 Required per assembly: 2 $6.11 $1.97 - + Add to cart
56	SCREW Part #: F3X-U7823-12-00 Required per assembly: 1 $5.99 $1.32 - + Add to cart
57	WASHER, PLATE Part #: 90201-06805-00 Required per assembly: 1 $0.30 $0.28 - + Add to cart
58	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 1 $6.11 $1.51 - + Add to cart
59	SIDE ORNAMENT ASSEMBLY 2 Part #: F3X-U370K-20-00 Required per assembly: 1 $73.43 $69.44 - + Add to cart
59	SIDE ORNAMENT ASSY 2 Part #: F3X-U370K-G0-00 Required per assembly: 1 $124.43 $101.27 - + Add to cart
60	SCREW Part #: F3X-U7823-02-00 Required per assembly: 2 $6.11 $1.51 - + Add to cart
61	PLATE, FIX Part #: F2X-U5175-00-00 Required per assembly: 2 $6.11 $1.97 - + Add to cart
62	SCREW Part #: F3X-U7823-12-00 Required per assembly: 1 $5.99 $1.32 - + Add to cart
63	WASHER, PLATE Part #: 90201-06805-00 Required per assembly: 1 $0.30 $0.28 - + Add to cart
64	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 1 $6.11 $1.51 - + Add to cart
65	MAT 2 Part #: F1K-U759C-00-00 Required per assembly: 2 $6.11 $1.89 - + Add to cart
66	BOX, FIRE, EXTINGUISHER Part #: F1K-U5983-01-00 Required per assembly: 1 $26.51 $19.64 - + Add to cart
67	BAND, 1 Part #: F2P-U828K-00-00 Required per assembly: 1 $13.25 $6.49 - + Add to cart
68	HOOK A Part #: F1K-U5772-04-00 Required per assembly: 2 $12.23 $6.27 - + Add to cart
69	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 2 Note: Sold in multiples of 5 only $5.49 $4.97 - + Add to cart
70	RFM., DASH, BOARD, 1 Part #: F5G-U974A-00-00 Required per assembly: 1 $12.23 $6.86 - + Add to cart
71	RIVET 1 Part #: F4P-U516R-01-00 Required per assembly: 4 $11.21 $5.35 - + Add to cart
72	RFM., DASH, BOARD, 2 Part #: F5G-U974B-00-00 Required per assembly: 1 $12.23 $6.86 - + Add to cart
73	RIVET 1 Part #: F4P-U516R-01-00 Required per assembly: 4 $11.21 $5.35 - + Add to cart
