2023 Yamaha Zuma 125 GQX125PB BJC3 - Water Pump

WATER PUMP Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

WATER PUMP ASSEMBLY

Part #: B6H-E2420-00-00 Required per assembly: 1
$63.99
$58.00
-
+
Add to cart
2

COVER, HOUSING

Part #: B6H-E2422-00-00 Required per assembly: 1
$10.49
$8.88
-
+
Add to cart
3

SEAL

Part #: B6H-E2223-00-00 Required per assembly: 1
$36.99
$27.88
-
+
Add to cart
4

O-RING

Part #: B6H-E2439-00-00 Required per assembly: 1
$8.49
$5.26
-
+
Add to cart
5

COVER, CYLINDER, HEAD, SIDE, 3

Part #: B6H-E1185-00-00 Required per assembly: 1
$19.98
$16.54
-
+
Add to cart
6

IMPELLER SHAFT ASSEMBLY

Part #: B6H-E2450-00-00 Required per assembly: 1
$19.48
$14.06
-
+
Add to cart
7

CIRCLIP

Part #: 99009-08400-00 Required per assembly: 1
$1.75
$1.44
-
+
Add to cart
8

BEARING

Part #: 93300-608X0-00 Required per assembly: 2
$4.00
$3.33
-
+
Add to cart
9

BOLT, FLANGE(6U1)

Part #: 95027-06020-00 Required per assembly: 3
$1.20
$0.98
-
+
Add to cart
10

GASKET

Part #: 90430-06803-00 Required per assembly: 1
$1.85
$1.36
-
+
Add to cart
11

PIN, DOWEL(6G8)

Part #: 99530-08012-00 Required per assembly: 2
$6.99
$6.49
-
+
Add to cart
12

O-RING

Part #: 93210-39803-00 Required per assembly: 1
$2.35
$1.86
-
+
Add to cart
13

BOLT, FLANGE, DEEP, RECESS

Part #: 95E32-06025-00 Required per assembly: 1
$0.28
$0.25
-
+
Add to cart
14

BOLT, FLANGE, DEEP, RECESS

Part #: 95E32-06045-00 Required per assembly: 2
$1.70
$1.36
-
+
Add to cart
15

O-RING (646)

Part #: 93210-19123-00 Required per assembly: 1 Note: Sold in multiples of 5 only
$8.99
$6.79
-
+
Add to cart
