2023 Yamaha Zuma 125 GQX125PL BJC30 - Fender

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

FENDER, FRONT

Part #: BBJ-F1511-00-00 Required per assembly: 1
$38.85
-
+
Add to cart
2

BOLT

Part #: 90109-06172-00 Required per assembly: 3
$3.50
$2.66
-
+
Add to cart
3

FENDER, INNER

Part #: BBJ-F1552-00-00 Required per assembly: 1
$71.07
-
+
Add to cart
4

NUT, SPRING

Part #: 90183-05827-00 Required per assembly: 4
$0.28
$0.25
-
+
Add to cart
5

COLLAR

Part #: 90387-06868-00 Required per assembly: 2
$1.14
$0.73
-
+
Add to cart
6

NUT, FLANGE, (7NB)

Part #: 95780-06500-00 Required per assembly: 2
$2.95
$1.87
-
+
Add to cart
7

RIVET

Part #: 90269-06803-00 Required per assembly: 4 Note: Sold in multiples of 5 only
$0.35
$0.28
-
+
Add to cart
8

SCREW, TRUSS, HEAD, TAPPING

Part #: 97707-50016-00 Required per assembly: 4
$1.85
$1.41
-
+
Add to cart
9

FENDER, INNER, 2

Part #: BBJ-F1553-00-00 Required per assembly: 1
$24.69
-
+
Add to cart
10

SCREW, TRUSS, HEAD, TAPPING

Part #: 97707-50016-00 Required per assembly: 2
$1.85
$1.41
-
+
Add to cart
11

RIVET

Part #: 90269-06803-00 Required per assembly: 2 Note: Sold in multiples of 5 only
$0.35
$0.28
-
+
Add to cart
12

RIVET

Part #: 90269-06806-00 Required per assembly: 2
$2.20
$1.68
-
+
Add to cart
13

FENDER, REAR

Part #: B8R-F1611-00-00 Required per assembly: 1
$40.54
-
+
Add to cart
14

BOLT, FLANGE, DEEP, RECESS

Part #: 95D07-06016-00 Required per assembly: 2
$1.25
$0.68
-
+
Add to cart
15

COLLAR

Part #: 90387-06868-00 Required per assembly: 3
$1.14
$0.73
-
+
Add to cart
16

STAY, FENDER, 1

Part #: B8R-F1613-00-00 Required per assembly: 1
$3.50
$2.09
-
+
Add to cart
17

BOLT, FLANGE, DEEP, RECESS

Part #: 95D07-06016-00 Required per assembly: 2
$1.25
$0.68
-
+
Add to cart
