Seat Cushion replacement parts for 2023 Yamaha 222 SE

OEM Parts Yamaha 2023 Yamaha 222 SE Seat Cushion

SEAT CUSHION Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CUSHION, FORE, 5, (WHITE, COAT, 5) Part #: F6D-U35A5-20-00 Required per assembly: 1 ~~$567.11~~ $539.65 - + Add to cart
1	CUSHION, FORE, 5, (BLACK, COAT, 2) Part #: F6D-U35A5-30-00 Required per assembly: 1 ~~$534.47~~ $509.41 - + Add to cart
2	CUSHION, FORE, 6, (WHITE, COAT, 5) Part #: F6D-U35A6-20-00 Required per assembly: 1 ~~$567.11~~ $539.65 - + Add to cart
2	CUSHION, FORE, 6, (BLACK, COAT, 2) Part #: F6D-U35A6-30-00 Required per assembly: 1 ~~$534.47~~ $509.41 - + Add to cart
3	PAD 3 (WHITE COAT 5) Part #: F6D-U36A3-20-00 Required per assembly: 1 ~~$208.06~~ $176.75 - + Add to cart
3	PAD 3 (BLACK COAT 2) Part #: F6D-U36A3-30-00 Required per assembly: 1 ~~$208.06~~ $176.75 - + Add to cart
4	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 3 ~~$8.15~~ $3.84 - + Add to cart
5	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 8 ~~$6.11~~ $1.13 - + Add to cart
6	PAD 4 (WHITE COAT 5) Part #: F6D-U36A4-20-00 Required per assembly: 1 ~~$206.03~~ $175.24 - + Add to cart
6	PAD 4 (BLACK COAT 2) Part #: F6D-U36A4-30-00 Required per assembly: 1 Not Available
7	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 3 ~~$8.15~~ $3.84 - + Add to cart
8	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 8 ~~$6.11~~ $1.13 - + Add to cart
9	CUSHION, FORE, 1, (WHITE, COAT, 5) Part #: F6D-U35A1-20-00 Required per assembly: 1 ~~$553.85~~ $514.06 - + Add to cart
9	CUSHION, FORE, 1 Part #: F6D-U35A1-30-00 Required per assembly: 1 $691.49 - + Add to cart
10	CUSHION, SEAT, FRONT, RIGHT, (WHITE, COAT, 5) Part #: F6D-U35A2-20-00 Required per assembly: 1 ~~$553.85~~ $514.06 - + Add to cart
10	CUSHION, SEAT, FRONT, RIGHT, (BLACK, COAT, 2) Part #: F6D-U35A2-30-00 Required per assembly: 1 $691.49 - + Add to cart
11	PAD 10 (WHITE COAT 5) Part #: F6D-U36B1-20-00 Required per assembly: 1 Not Available
11	PAD 10 (BLACK COAT 2) Part #: F6D-U36B1-30-00 Required per assembly: 1 Not Available
12	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 2 ~~$8.15~~ $3.84 - + Add to cart
13	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 5 ~~$6.11~~ $1.13 - + Add to cart
14	PAD 11 (WHITE COAT 5) Part #: F6D-U36B2-20-00 Required per assembly: 1 Not Available
14	PAD 11 (BLACK COAT 2) Part #: F6D-U36B2-30-00 Required per assembly: 1 Not Available
15	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 2 ~~$8.15~~ $3.84 - + Add to cart
16	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 5 ~~$6.11~~ $1.13 - + Add to cart
17	BACK REST 3 (WHITE COAT 5) Part #: F6D-U3796-20-00 Required per assembly: 1 $370.53 - + Add to cart
17	BACK REST 3 (BLACK COAT 2) Part #: F6D-U3796-30-00 Required per assembly: 1 ~~$345.76~~ $335.53 - + Add to cart
18	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 4 ~~$8.15~~ $3.84 - + Add to cart
19	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.13 - + Add to cart
20	BACK REST 4 (WHITE COAT 5) Part #: F6D-U3798-20-00 Required per assembly: 1 $370.53 - + Add to cart
20	BACK REST 4 (BLACK COAT 2) Part #: F6D-U3798-30-00 Required per assembly: 1 ~~$345.76~~ $335.53 - + Add to cart
21	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 4 ~~$8.15~~ $3.84 - + Add to cart
22	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.13 - + Add to cart
23	CUSHION 5 Part #: F6D-U372F-00-00 Required per assembly: 2 $446.13 - + Add to cart
24	CUSHION 1 (WHITE COAT 5) Part #: F6D-U371D-20-00 Required per assembly: 1 ~~$437.56~~ $421.71 - + Add to cart
24	CUSHION 1 (BLACK COAT 2) Part #: F6D-U371D-30-00 Required per assembly: 1 ~~$1,368.80~~ $1,259.36 - + Add to cart
25	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 1 ~~$0.71~~ $0.60 - + Add to cart
26	WASHER, PLATE Part #: 90202-06SA3-00 Required per assembly: 1 ~~$0.10~~ $0.08 - + Add to cart
27	CUSHION, SEAT, (DARK, PURPLISH, BLUE, COAT, 8) Part #: F6D-U3713-20-00 Required per assembly: 1 ~~$368.20~~ $356.70 - + Add to cart
27	CUSHION, SEAT, (WHITE, COAT, 5) Part #: F6D-U3713-30-00 Required per assembly: 1 ~~$363.11~~ $352.16 - + Add to cart
28	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 1 ~~$0.71~~ $0.60 - + Add to cart
29	WASHER, PLATE Part #: 90202-06SA3-00 Required per assembly: 1 ~~$0.10~~ $0.08 - + Add to cart
30	BRACKET, SEAT Part #: F3F-U3714-21-00 Required per assembly: 1 ~~$32.63~~ $25.67 - + Add to cart
31	BRACKET, SEAT Part #: F3F-U3714-31-00 Required per assembly: 1 ~~$26.51~~ $20.40 - + Add to cart
32	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 16 ~~$4.99~~ $0.56 - + Add to cart
33	WASHER, LOCK, (#10) Part #: 90204-10S00-00 Required per assembly: 16 ~~$7.12~~ $2.57 - + Add to cart
34	NUT Part #: 90170-10S00-00 Required per assembly: 16 ~~$6.11~~ $1.51 - + Add to cart
35	SCREW, COUNTERSUNK Part #: 90151-10S24-00 Required per assembly: 16 Not Available
36	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 16 ~~$4.99~~ $0.56 - + Add to cart
37	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 4 ~~$5.08~~ $1.06 - + Add to cart
38	CUSHION, MAIN, 5, (DARK, PURPLISH, BLUE, COAT, 8) Part #: F6D-U35C5-20-00 Required per assembly: 1 ~~$400.85~~ $388.45 - + Add to cart
38	CUSHION, MAIN, 5, (WHITE, COAT, 5) Part #: F6D-U35C5-30-00 Required per assembly: 1 ~~$400.85~~ $388.45 - + Add to cart
39	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 4 ~~$8.15~~ $3.84 - + Add to cart
40	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.13 - + Add to cart
41	CUSHION, MAIN, 6, (DARK, PURPLISH, BLUE, COAT, 8) Part #: F6D-U35C6-20-00 Required per assembly: 1 ~~$400.85~~ $388.45 - + Add to cart
41	CUSHION, MAIN, 6, (WHITE, COAT, 5) Part #: F6D-U35C6-30-00 Required per assembly: 1 $623.45 - + Add to cart
42	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 4 ~~$8.15~~ $3.84 - + Add to cart
43	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.13 - + Add to cart
44	BACK REST 1 (WHITE COAT 5) Part #: F6D-U3791-20-00 Required per assembly: 1 ~~$610.38~~ $604.89 - + Add to cart
44	BACK REST 1 (BLACK COAT 2) Part #: F6D-U3791-30-00 Required per assembly: 1 ~~$577.11~~ $574.65 - + Add to cart
45	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 7 ~~$8.15~~ $3.84 - + Add to cart
46	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 16 ~~$6.11~~ $1.13 - + Add to cart
47	TAPPING SCREW Part #: 90169-08SA9-00 Required per assembly: 1 ~~$0.26~~ $0.23 - + Add to cart
48	BACKREST, MAIN, 2, (WHITE, COAT, 5) Part #: F6D-U35E2-20-00 Required per assembly: 1 ~~$577.11~~ $574.65 - + Add to cart
48	BACKREST, MAIN, 2, (BLACK, COAT, 2) Part #: F6D-U35E2-30-00 Required per assembly: 1 Not Available
49	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 7 ~~$8.15~~ $3.84 - + Add to cart
50	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 16 ~~$6.11~~ $1.13 - + Add to cart
51	TAPPING SCREW Part #: 90169-08SA9-00 Required per assembly: 1 ~~$0.26~~ $0.23 - + Add to cart
52	CUSHION 1 (WHITE COAT 5) Part #: F6D-U828B-20-00 Required per assembly: 1 $278.30 - + Add to cart
52	CUSHION 1 (BLACK COAT 2) Part #: F6D-U828B-30-00 Required per assembly: 1 ~~$268.25~~ $243.30 - + Add to cart
53	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 2 ~~$0.71~~ $0.60 - + Add to cart
54	WASHER, PLATE Part #: 90202-06SA3-00 Required per assembly: 2 ~~$0.10~~ $0.08 - + Add to cart
55	HOLDER Part #: F4Y-U724H-00-00 Required per assembly: 1 ~~$80.56~~ $63.49 - + Add to cart
56	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.13 - + Add to cart
57	CUSHION 2 (WHITE COAT 5) Part #: F6D-U828C-20-00 Required per assembly: 1 ~~$268.25~~ $243.30 - + Add to cart
57	CUSHION 2 (BLACK COAT 2) Part #: F6D-U828C-30-00 Required per assembly: 1 ~~$268.25~~ $243.30 - + Add to cart
58	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 2 ~~$0.71~~ $0.60 - + Add to cart
59	WASHER, PLATE Part #: 90202-06SA3-00 Required per assembly: 2 ~~$0.10~~ $0.08 - + Add to cart
60	HOLDER Part #: F4Y-U724H-00-00 Required per assembly: 1 ~~$80.56~~ $63.49 - + Add to cart
61	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.13 - + Add to cart
62	BACK REST 6 (WHITE COAT 5) Part #: F6D-U379A-20-00 Required per assembly: 1 $1,610.78 - + Add to cart
62	BACK REST 6 (BLACK COAT 2) Part #: F6D-U379A-30-00 Required per assembly: 1 $1,710.78 - + Add to cart
63	BACKREST, MAIN, 5, (WHITE, COAT, 5) Part #: F6D-U35E5-20-00 Required per assembly: 1 Not Available
63	BACKREST, MAIN, 5, (BLACK, COAT, 2) Part #: F6D-U35E5-30-00 Required per assembly: 1 Not Available
64	PAD 13 (WHITE COAT 5) Part #: F6D-U36B4-20-00 Required per assembly: 1 Not Available
64	PAD 13 (BLACK COAT 2) Part #: F6D-U36B4-30-00 Required per assembly: 1 Not Available
65	BACK REST 6 (WHITE COAT 5) Part #: F6D-U36B8-20-00 Required per assembly: 1 Not Available
65	BACK REST 6 (BLACK COAT 2) Part #: F6D-U36B8-30-00 Required per assembly: 1 ~~$275.38~~ $250.86 - + Add to cart
66	PAD 15 (WHITE COAT 5) Part #: F6D-U36B6-20-00 Required per assembly: 1 Not Available
66	PAD 15 (BLACK COAT 2) Part #: F6D-U36B6-30-00 Required per assembly: 1 Not Available
67	BACKREST AFT 1 (WHITE COAT 5) Part #: F6D-U35L1-20-00 Required per assembly: 1 Not Available
67	BACKREST AFT 1 (BLACK COAT 2) Part #: F6D-U35L1-30-00 Required per assembly: 1 ~~$364.13~~ $355.18 - + Add to cart
68	BACK REST 7 (WHITE COAT 5) Part #: F6D-U379B-20-00 Required per assembly: 1 Not Available
68	BACK REST 7 (BLACK COAT 2) Part #: F6D-U379B-30-00 Required per assembly: 1 $1,710.78 - + Add to cart
69	BACKREST, MAIN, 6, (BLACK, COAT, 2) Part #: F6D-U35E6-30-00 Required per assembly: 1 Not Available
69	BACKREST, MAIN, 6 Part #: F6D-U35E6-20-00 Required per assembly: 1 ~~$738.44~~ $721.31 - + Add to cart
70	PAD 13 (WHITE COAT 5) Part #: F6D-U36B4-20-00 Required per assembly: 1 Not Available
70	PAD 13 (BLACK COAT 2) Part #: F6D-U36B4-30-00 Required per assembly: 1 Not Available
71	BACK REST 7 Part #: F6D-U36B7-20-00 Required per assembly: 1 ~~$275.38~~ $250.86 - + Add to cart
71	BACK REST 7 (BLACK COAT 2) Part #: F6D-U36B7-30-00 Required per assembly: 1 Not Available
72	PAD 15 (WHITE COAT 5) Part #: F6D-U36B6-20-00 Required per assembly: 1 Not Available
72	PAD 15 (BLACK COAT 2) Part #: F6D-U36B6-30-00 Required per assembly: 1 Not Available
73	BACKREST AFT 2 (WHITE COAT 5) Part #: F6D-U35L2-20-00 Required per assembly: 1 Not Available
73	BACKREST AFT 2 (BLACK COAT 2) Part #: F6D-U35L2-30-00 Required per assembly: 1 Not Available
