Seat Cushion replacement parts for 2023 Yamaha SX195

OEM Parts Yamaha 2023 Yamaha SX195 Seat Cushion

SEAT CUSHION Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BACK REST 3 Part #: F4V-U3796-00-00 Required per assembly: 1 ~~$383.50~~ $360.58 - + Add to cart
2	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 1 ~~$8.15~~ $3.84 - + Add to cart
3	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 1 ~~$6.11~~ $1.13 - + Add to cart
4	BACK REST 1 Part #: F4V-U3791-00-00 Required per assembly: 1 $779.42 - + Add to cart
5	BACK, REST, 4 Part #: F4V-U3798-00-00 Required per assembly: 1 ~~$845.57~~ $752.18 - + Add to cart
6	CUSHION 1 Part #: F4V-U371D-00-00 Required per assembly: 1 $420.64 - + Add to cart
7	CUSHION, FORE, 3 Part #: F4V-U35A3-00-00 Required per assembly: 1 ~~$436.55~~ $365.65 - + Add to cart
8	BACKREST, FRONT, PORT Part #: F4V-U35B1-00-00 Required per assembly: 1 ~~$316.19~~ $295.12 - + Add to cart
9	CUSHION, FORE, 1 Part #: F4V-U35A1-00-00 Required per assembly: 1 $394.72 - + Add to cart
10	BACKREST, FRONT, STBD Part #: F4V-U35B2-00-00 Required per assembly: 1 ~~$316.19~~ $295.12 - + Add to cart
11	CUSHION, SEAT, FRONT, RIGHT Part #: F4V-U35A2-00-00 Required per assembly: 1 $390.18 - + Add to cart
12	BACK REST 2 Part #: F4V-U3795-00-00 Required per assembly: 1 $829.39 - + Add to cart
13	CUSHION 2 Part #: F4V-U371E-00-00 Required per assembly: 1 ~~$565.07~~ $564.14 - + Add to cart
14	BACKREST 1 Part #: F4V-U3766-00-00 Required per assembly: 1 $314.74 - + Add to cart
15	WASHER, FENDER Part #: 90209-14SA3-00 Required per assembly: 1 ~~$6.11~~ $1.29 - + Add to cart
16	WASHER, 1/4", LOCK Part #: 90204-14S00-00 Required per assembly: 1 ~~$6.11~~ $1.13 - + Add to cart
17	NUT, 1/4-20 Part #: 90170-14S00-00 Required per assembly: 2 ~~$5.08~~ $0.60 - + Add to cart
18	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 12 ~~$5.08~~ $1.06 - + Add to cart
19	CUSHION, SEAT, REAR Part #: F4V-U3724-00-00 Required per assembly: 1 $340.44 - + Add to cart
20	WASHER, PLATE Part #: 90202-06SA3-00 Required per assembly: 4 ~~$0.10~~ $0.08 - + Add to cart
21	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 4 ~~$0.71~~ $0.60 - + Add to cart
22	PAD 2 Part #: F4V-U36A2-00-00 Required per assembly: 1 ~~$296.81~~ $278.49 - + Add to cart
23	PAD 1 Part #: F4V-U521C-00-00 Required per assembly: 1 $731.11 - + Add to cart
24	PAD 2 Part #: F4V-U521D-00-00 Required per assembly: 1 $724.70 - + Add to cart
25	BRACKET, SEAT Part #: F3F-U3714-21-00 Required per assembly: 3 ~~$32.63~~ $25.67 - + Add to cart
26	BRACKET, SEAT Part #: F3F-U3714-31-00 Required per assembly: 3 ~~$26.51~~ $20.40 - + Add to cart
27	SCREW, COUNTERSUNK Part #: 90151-10S16-00 Required per assembly: 12 ~~$6.11~~ $1.36 - + Add to cart
28	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 24 ~~$4.99~~ $0.56 - + Add to cart
29	WASHER, LOCK, (#10) Part #: 90204-10S00-00 Required per assembly: 12 ~~$7.12~~ $2.57 - + Add to cart
30	NUT Part #: 90170-10S00-00 Required per assembly: 12 ~~$6.11~~ $1.51 - + Add to cart
31	BACKREST, FORE, 3 Part #: F4V-U35B3-00-00 Required per assembly: 1 ~~$301.91~~ $289.51 - + Add to cart
32	CUSHION 5 Part #: F4V-U372F-00-00 Required per assembly: 1 $335.75 - + Add to cart
33	CUSHION 5 Part #: F4V-U372F-10-00 Required per assembly: 1 $312.12 - + Add to cart
