Front Fork replacement parts for 2023 Yamaha TT-R230 CA

OEM Parts Yamaha 2023 Yamaha TT R230 CA Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	DAMPER ASSY. (L) Part #: 1C6-F3102-02-00 Required per assembly: 1 ~~$269.99~~ $224.14 - + Add to cart
2	TUBE, OUTER, (LEFT) Part #: 1C6-F3126-00-00 Required per assembly: 1 ~~$99.98~~ $82.46 - + Add to cart
3	INNER TUBE COMP 1 Part #: 1C6-F3110-00-00 Required per assembly: 1 Not Available
4	SPRING Part #: 1C6-F3351-00-00 Required per assembly: 1 $60.32 - + Add to cart
5	PISTON, FRONT, FORK Part #: 1C6-F3171-00-00 Required per assembly: 1 ~~$56.99~~ $49.94 - + Add to cart
6	SEAL, DUST Part #: 1KH-23144-00-00 Required per assembly: 1 ~~$33.99~~ $25.41 - + Add to cart
7	OIL SEAL Part #: 1KH-23145-00-00 Required per assembly: 1 ~~$31.98~~ $23.48 - + Add to cart
8	RING, SNAP Part #: 34X-23156-00-00 Required per assembly: 1 $10.47 - + Add to cart
9	SEAL, SPACER Part #: 1KH-23147-00-00 Required per assembly: 1 ~~$28.98~~ $24.26 - + Add to cart
10	METAL, SLIDE, 1 Part #: 34X-23125-00-00 Required per assembly: 1 ~~$30.98~~ $23.11 - + Add to cart
11	RING, PISTON Part #: 34X-23157-00-00 Required per assembly: 1 ~~$24.98~~ $21.75 - + Add to cart
12	SPRING, REBOUND Part #: 34X-23151-00-00 Required per assembly: 1 $8.71 - + Add to cart
13	METAL, SLIDE, 2 Part #: 34X-23135-00-00 Required per assembly: 1 ~~$24.98~~ $22.31 - + Add to cart
14	SPACER, OIL, LOCK Part #: 4AN-F3166-00-00 Required per assembly: 1 ~~$10.49~~ $6.18 - + Add to cart
15	BOLT, HEXAGON, SOCKET, HEAD Part #: 3M7-23181-00-00 Required per assembly: 1 $10.25 - + Add to cart
16	CAP, FRONT, FORK Part #: 35E-23168-00-00 Required per assembly: 1 $17.17 - + Add to cart
17	CIRCLIP Part #: 35E-23183-00-00 Required per assembly: 1 $6.55 - + Add to cart
18	BOLT, CAP Part #: 35E-23111-00-00 Required per assembly: 1 ~~$26.98~~ $23.30 - + Add to cart
19	GASKET Part #: 58W-F3114-00-00 Required per assembly: 1 ~~$7.49~~ $5.75 - + Add to cart
20	BAND Part #: 4AN-F3192-10-00 Required per assembly: 1 $2.24 - + Add to cart
21	BOOT Part #: 1C6-23191-02-00 Required per assembly: 1 ~~$108.98~~ $82.60 - + Add to cart
22	BAND Part #: 4AN-F3192-00-00 Required per assembly: 1 ~~$12.99~~ $11.55 - + Add to cart
23	DAMPER ASSY. (R) Part #: 1C6-F3103-02-00 Required per assembly: 1 ~~$269.99~~ $223.87 - + Add to cart
24	TUBE, OUTER, (RIGHT) Part #: 1C6-F3136-00-00 Required per assembly: 1 ~~$99.98~~ $82.60 - + Add to cart
25	INNER TUBE COMP 1 Part #: 1C6-F3110-00-00 Required per assembly: 1 Not Available
26	SPRING Part #: 1C6-F3351-00-00 Required per assembly: 1 $60.32 - + Add to cart
27	PISTON, FRONT, FORK Part #: 1C6-F3171-00-00 Required per assembly: 1 ~~$56.99~~ $49.94 - + Add to cart
28	SEAL, DUST Part #: 1KH-23144-00-00 Required per assembly: 1 ~~$33.99~~ $25.41 - + Add to cart
29	OIL SEAL Part #: 1KH-23145-00-00 Required per assembly: 1 ~~$31.98~~ $23.48 - + Add to cart
30	RING, SNAP Part #: 34X-23156-00-00 Required per assembly: 1 $10.47 - + Add to cart
31	SEAL, SPACER Part #: 1KH-23147-00-00 Required per assembly: 1 ~~$28.98~~ $24.26 - + Add to cart
32	METAL, SLIDE, 1 Part #: 34X-23125-00-00 Required per assembly: 1 ~~$30.98~~ $23.11 - + Add to cart
33	RING, PISTON Part #: 34X-23157-00-00 Required per assembly: 1 ~~$24.98~~ $21.75 - + Add to cart
34	SPRING, REBOUND Part #: 34X-23151-00-00 Required per assembly: 1 $8.71 - + Add to cart
35	METAL, SLIDE, 2 Part #: 34X-23135-00-00 Required per assembly: 1 ~~$24.98~~ $22.31 - + Add to cart
36	SPACER, OIL, LOCK Part #: 4AN-F3166-00-00 Required per assembly: 1 ~~$10.49~~ $6.18 - + Add to cart
37	BOLT, HEXAGON, SOCKET, HEAD Part #: 3M7-23181-00-00 Required per assembly: 1 $10.25 - + Add to cart
38	CAP, FRONT, FORK Part #: 35E-23168-00-00 Required per assembly: 1 $17.17 - + Add to cart
39	CIRCLIP Part #: 35E-23183-00-00 Required per assembly: 1 $6.55 - + Add to cart
40	BOLT, CAP Part #: 35E-23111-00-00 Required per assembly: 1 ~~$26.98~~ $23.30 - + Add to cart
41	GASKET Part #: 58W-F3114-00-00 Required per assembly: 1 ~~$7.49~~ $5.75 - + Add to cart
42	BAND Part #: 4AN-F3192-10-00 Required per assembly: 1 $2.24 - + Add to cart
43	BOOT Part #: 1C6-23191-02-00 Required per assembly: 1 ~~$108.98~~ $82.60 - + Add to cart
44	BAND Part #: 4AN-F3192-00-00 Required per assembly: 1 ~~$12.99~~ $11.55 - + Add to cart
45	UNDER BRACKET COMP. Part #: 1C6-F3340-00-00 Required per assembly: 1 ~~$221.99~~ $184.42 - + Add to cart
46	BOLT, FLANGE Part #: 95817-08035-00 Required per assembly: 4 ~~$10.49~~ $8.93 - + Add to cart
47	GUIDE, CABLE Part #: 1C6-F331E-00-00 Required per assembly: 1 ~~$5.49~~ $5.35 - + Add to cart
48	GUIDE, CABLE Part #: 1C6-F3389-00-00 Required per assembly: 1 ~~$3.50~~ $2.69 - + Add to cart
49	BOLT, FLANGE Part #: 95817-06014-00 Required per assembly: 1 $3.03 - + Add to cart
