Front Fork replacement parts for 2023 Yamaha Tenere 700

OEM Parts Yamaha 2023 Yamaha Tenere 700 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSY (R.H) Part #: BW3-23103-03-00 Required per assembly: 1 $790.32 $733.47 - + Add to cart
2	TUBE, OUTER, (L.H) Part #: BW3-23126-00-00 Required per assembly: 1 $622.99 $559.98 - + Add to cart
3	INNER TUBE COMP.2 Part #: BW3-23120-01-00 Required per assembly: 1 $393.99 $383.76 - + Add to cart
4	PISTON, FRONT, FORK Part #: 5EB-23171-00-00 Required per assembly: 1 $37.99 $28.40 - + Add to cart
5	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 $26.98 $19.81 - + Add to cart
6	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $10.99 $8.50 - + Add to cart
7	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 $28.98 $20.61 - + Add to cart
8	WASHER, OIL, SEAL Part #: 4V4-23146-L0-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
9	METAL, SLIDE, 1 Part #: 2CR-23125-00-00 Required per assembly: 1 $12.99 $9.39 - + Add to cart
10	CYLINDER, COMP., FRONT, FORK Part #: BW3-23170-01-00 Required per assembly: 1 $391.99 $385.23 - + Add to cart
11	VALVE ASSEMBLY Part #: BW3-2330H-01-00 Required per assembly: 1 $203.99 $190.56 - + Add to cart
12	O-RING Part #: 4DA-23147-L1-00 Required per assembly: 1 $7.49 $5.76 - + Add to cart
13	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $4.59 $3.81 - + Add to cart
14	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
15	GUIDE, SPRING Part #: 23P-23117-01-00 Required per assembly: 1 $38.99 $34.05 - + Add to cart
16	NUT Part #: 3XJ-23357-L0-00 Required per assembly: 1 $1.30 $0.97 - + Add to cart
17	SPRING, FRONT, FORK Part #: BW3-23141-00-00 Required per assembly: 1 $47.99 $39.77 - + Add to cart
18	GUIDE, SPRING Part #: BW3-23117-00-00 Required per assembly: 1 $11.49 $9.07 - + Add to cart
19	BOLT, CAP Part #: BW3-23111-01-00 Required per assembly: 1 $226.99 $204.15 - + Add to cart
20	O-RING Part #: 3XJ-23147-L1-00 Required per assembly: 1 $4.75 $3.90 - + Add to cart
21	BOLT, FLANGE Part #: 90105-08134-00 Required per assembly: 2 $8.49 $5.76 - + Add to cart
22	PLUG, HOLE Part #: 3JD-2312G-L1-00 Required per assembly: 1 $5.00 $3.93 - + Add to cart
23	FRONT FORK ASSY (L.H) Part #: BW3-23102-03-00 Required per assembly: 1 $754.28 $700.71 - + Add to cart
24	TUBE, OUTER, (L.H) Part #: BW3-23126-00-00 Required per assembly: 1 $622.99 $559.98 - + Add to cart
25	INNER TUBE COMP.1 Part #: BW3-23110-01-00 Required per assembly: 1 $393.99 $383.76 - + Add to cart
26	PISTON, FRONT, FORK Part #: 5EB-23171-00-00 Required per assembly: 1 $37.99 $28.40 - + Add to cart
27	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 $26.98 $19.81 - + Add to cart
28	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $10.99 $8.50 - + Add to cart
29	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 $28.98 $20.61 - + Add to cart
30	WASHER, OIL, SEAL Part #: 4V4-23146-L0-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
31	METAL, SLIDE, 1 Part #: 2CR-23125-00-00 Required per assembly: 1 $12.99 $9.39 - + Add to cart
32	CYLINDER, COMP., FRONT, FORK Part #: BW3-23170-01-00 Required per assembly: 1 $391.99 $385.23 - + Add to cart
33	VALVE ASSEMBLY Part #: BW3-2330H-01-00 Required per assembly: 1 $203.99 $190.56 - + Add to cart
34	O-RING Part #: 4DA-23147-L1-00 Required per assembly: 1 $7.49 $5.76 - + Add to cart
35	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $4.59 $3.81 - + Add to cart
36	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
37	GUIDE, SPRING Part #: 23P-23117-01-00 Required per assembly: 1 $38.99 $34.05 - + Add to cart
38	NUT Part #: 3XJ-23357-L0-00 Required per assembly: 1 $1.30 $0.97 - + Add to cart
39	SPRING, FRONT, FORK Part #: BW3-23141-00-00 Required per assembly: 1 $47.99 $39.77 - + Add to cart
40	GUIDE, SPRING Part #: BW3-23117-00-00 Required per assembly: 1 $11.49 $9.07 - + Add to cart
41	BOLT, CAP Part #: BW3-23111-01-00 Required per assembly: 1 $226.99 $204.15 - + Add to cart
42	O-RING Part #: 3XJ-23147-L1-00 Required per assembly: 1 $4.75 $3.90 - + Add to cart
43	PLUG, HOLE Part #: 3JD-2312G-L0-00 Required per assembly: 1 $7.49 $6.41 - + Add to cart
44	UNDER BRACKET COMP. Part #: BW3-23340-00-00 Required per assembly: 1 $601.99 $543.10 - + Add to cart
45	BRG, CYL-CAL, ROLLER, 131G, KY Part #: 93332-00008-00 Required per assembly: 1 $73.98 $60.74 - + Add to cart
46	BOLT, FLANGE Part #: 90105-08134-00 Required per assembly: 4 $8.49 $5.76 - + Add to cart
47	COVER, UNDER, 1 Part #: 4KM-23123-01-00 Required per assembly: 1 $15.49 $13.06 - + Add to cart
48	REFLECTOR ASSEMBLY Part #: 8GM-85110-00-00 Required per assembly: 2 $14.99 $11.82 - + Add to cart
49	NUT, CROWN Part #: 90176-05802-00 Required per assembly: 2 $0.32 $0.25 - + Add to cart
50	FORK SEALS KIT Part #: BAU-W003B-00-00 Required per assembly: 1 $71.25 $64.77 - + Add to cart
