Rear Axle & Wheel replacement parts for 2023 Yamaha YFZ50

OEM Parts Yamaha 2023 Yamaha YFZ50 Rear Axle & Wheel

REAR AXLE & WHEEL Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	TIRE Part #: BW4-F53P3-00-00 Required per assembly: 1 ~~$305.20~~ $288.45 - + Add to cart
2	AIR VALVE ASSEMBLY Part #: BD3-F5170-00-00 Required per assembly: 1 ~~$37.99~~ $29.26 - + Add to cart
3	TIRE Part #: BW4-F53P3-00-00 Required per assembly: 1 ~~$305.20~~ $288.45 - + Add to cart
4	AIR VALVE ASSEMBLY Part #: BD3-F5170-00-00 Required per assembly: 1 ~~$37.99~~ $29.26 - + Add to cart
5	REAR WHEEL COMP. Part #: BW4-F5390-00-00 Required per assembly: 2 ~~$172.99~~ $171.03 - + Add to cart
6	COLLAR, WHEEL Part #: BW4-F5377-00-00 Required per assembly: 2 ~~$135.99~~ $122.90 - + Add to cart
7	BOLT Part #: BD3-F4592-10-00 Required per assembly: 8 ~~$8.49~~ $5.82 - + Add to cart
8	WASHER 1 Part #: BW4-F2243-00-00 Required per assembly: 2 ~~$10.49~~ $8.50 - + Add to cart
9	NUT, AXLE Part #: BW4-F5382-00-00 Required per assembly: 2 ~~$8.49~~ $7.20 - + Add to cart
10	PIN Part #: BD3-F112N-10-00 Required per assembly: 2 ~~$2.79~~ $1.59 - + Add to cart
11	CAP, WHEEL Part #: BD3-F512A-00-00 Required per assembly: 2 ~~$12.49~~ $9.84 - + Add to cart
12	AXLE, WHEEL Part #: BW4-F5381-00-00 Required per assembly: 1 ~~$450.99~~ $448.56 - + Add to cart
13	SPROCKET, DRIVEN, (38T) Part #: BW4-F5438-10-00 Required per assembly: 1 ~~$96.98~~ $82.45 - + Add to cart
14	COLLAR, SPROCKET, AXLE Part #: BD3-F5386-10-00 Required per assembly: 1 ~~$130.99~~ $112.16 - + Add to cart
15	BOLT Part #: BW4-F3459-00-00 Required per assembly: 3 ~~$6.49~~ $5.10 - + Add to cart
16	WASHER, PLATE Part #: BD3-F2156-10-00 Required per assembly: 3 ~~$2.35~~ $1.97 - + Add to cart
17	NUT Part #: BD3-F1636-10-00 Required per assembly: 2 ~~$49.99~~ $42.06 - + Add to cart
18	WASHER 1 Part #: BD3-F3737-00-00 Required per assembly: 1 ~~$24.98~~ $19.32 - + Add to cart
19	CHAIN Part #: BW4-F53C0-10-00 Required per assembly: 1 ~~$47.99~~ $37.47 - + Add to cart
20	JOINT, CHAIN Part #: BW4-E6548-00-00 Required per assembly: 1 ~~$8.49~~ $4.66 - + Add to cart
