Middle Drive Gear replacement parts for 2023 Yamaha YXZ1000R SS

OEM Parts Yamaha 2023 Yamaha YXZ1000R SS Middle Drive Gear

MIDDLE DRIVE GEAR Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SHAFT Part #: 2HC-17523-00-00 Required per assembly: 1 ~~$215.99~~ $193.99 - + Add to cart
2	HOLDER Part #: 2HC-17524-00-00 Required per assembly: 1 ~~$51.99~~ $44.11 - + Add to cart
3	SPRING, DAMPER Part #: 2HC-17528-00-00 Required per assembly: 1 ~~$44.99~~ $35.37 - + Add to cart
4	CAM, DRIVEN Part #: 2S3-17527-00-00 Required per assembly: 1 ~~$143.99~~ $124.07 - + Add to cart
5	GEAR, MIDDLE, DRIVEN Part #: B5H-17583-00-00 Required per assembly: 1 ~~$194.99~~ $186.91 - + Add to cart
6	WASHER, PLATE Part #: 90201-27014-00 Required per assembly: 1 ~~$36.99~~ $28.97 - + Add to cart
7	WASHER, THRUST Part #: 23P-17529-00-00 Required per assembly: 2 ~~$33.99~~ $22.76 - + Add to cart
8	BEARING (5X5) Part #: 93306-20627-00 Required per assembly: 1 ~~$82.98~~ $66.75 - + Add to cart
9	OIL SEAL Part #: 93105-45018-00 Required per assembly: 1 ~~$10.49~~ $8.39 - + Add to cart
10	BEARING Part #: 93306-37218-00 Required per assembly: 1 ~~$39.99~~ $31.93 - + Add to cart
11	COUPLING Part #: 2HC-17832-00-00 Required per assembly: 1 ~~$76.98~~ $64.15 - + Add to cart
12	WASHER, PLATE Part #: 90201-165H4-00 Required per assembly: 1 ~~$10.49~~ $7.58 - + Add to cart
13	NUT Part #: 90179-16004-00 Required per assembly: 1 ~~$17.48~~ $13.46 - + Add to cart
14	HOUSING, BEARING Part #: 2HC-17521-00-00 Required per assembly: 1 ~~$74.98~~ $61.57 - + Add to cart
15	BEARING Part #: 93306-00519-00 Required per assembly: 1 ~~$39.99~~ $31.56 - + Add to cart
16	CIRCLIP Part #: 99009-47500-00 Required per assembly: 1 ~~$10.49~~ $7.53 - + Add to cart
17	SHAFT ASSEMBLY 1 Part #: 2HC-46380-00-00 Required per assembly: 1 $639.81 - + Add to cart
18	OIL, SEAL, SD-TYPE Part #: 93102-34095-00 Required per assembly: 1 ~~$25.98~~ $19.99 - + Add to cart
19	YOKE, JOINT, 2 Part #: 2HC-17576-00-00 Required per assembly: 1 ~~$119.98~~ $101.53 - + Add to cart
20	WASHER, PLATE Part #: 90201-165H4-00 Required per assembly: 1 ~~$10.49~~ $7.58 - + Add to cart
21	NUT Part #: 90179-16004-00 Required per assembly: 1 ~~$17.48~~ $13.46 - + Add to cart
22	BOLT, FLANGE Part #: 95022-06030-00 Required per assembly: 5 ~~$1.80~~ $1.38 - + Add to cart
23	BOLT, WASHER, BASED, (4EB) Part #: 90105-06791-00 Required per assembly: 2 ~~$2.79~~ $2.36 - + Add to cart
24	GASKET Part #: 2HC-17818-00-00 Required per assembly: 1 ~~$7.49~~ $5.59 - + Add to cart
25	CROSS JOINT COMP. 2 Part #: 2HC-46107-00-00 Required per assembly: 1 ~~$220.99~~ $199.30 - + Add to cart
26	BEARING Part #: 93399-99948-00 Required per assembly: 2 ~~$60.99~~ $47.95 - + Add to cart
27	CIRCLIP, OUTER Part #: 93440-20088-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
28	SPIDER Part #: 5GT-46187-00-00 Required per assembly: 1 ~~$117.98~~ $98.05 - + Add to cart
29	BEARING Part #: 93399-99948-00 Required per assembly: 2 ~~$60.99~~ $47.95 - + Add to cart
30	CIRCLIP, OUTER Part #: 93440-20088-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
