Pedal Wire replacement parts for 2023 Yamaha YXZ1000R SS XTR

OEM Parts Yamaha 2023 Yamaha YXZ1000R SS XTR Pedal Wire

PEDAL WIRE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BRACKET, PEDAL, SUPPORT Part #: B57-F2548-01-00 Required per assembly: 1 $67.41 - + Add to cart
2	BOLT, FLANGE, (JN5) Part #: 95817-08016-00 Required per assembly: 4 $5.49 $4.05 - + Add to cart
3	PEDAL, BRAKE Part #: 2HC-F7200-00-00 Required per assembly: 1 $22.98 $18.31 - + Add to cart
4	COLLAR Part #: 90387-10843-00 Required per assembly: 1 Not Available
5	BOLT, FLANGE Part #: 95817-10090-00 Required per assembly: 1 $10.49 $6.73 - + Add to cart
6	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 1 $2.70 $2.25 - + Add to cart
7	SPRING, TENSION Part #: 90506-23022-00 Required per assembly: 1 $5.99 $4.08 - + Add to cart
8	CLUTCH ACTUATOR ASSEMBLY Part #: B57-82460-03-00 Required per assembly: 1 $1,641.76 $1,492.51 - + Add to cart
9	BOLT, WASHER, BASED Part #: 90105-08211-00 Required per assembly: 2 $3.50 $2.28 - + Add to cart
10	ACCEL PEDAL ASSEMBLY Part #: 2HC-F7801-01-00 Required per assembly: 1 $19.98 $16.45 - + Add to cart
11	WASHER, PLATE Part #: 90201-15018-00 Required per assembly: 2 $8.49 $6.21 - + Add to cart
12	CIRCLIP, E-TYPE Part #: 93430-12008-00 Required per assembly: 1 $8.49 $5.15 - + Add to cart
13	SPRING, TENSION Part #: 90506-23022-00 Required per assembly: 1 $5.99 $4.08 - + Add to cart
14	WIRE, THROTTLE, 1 Part #: 2HC-26311-13-00 Required per assembly: 1 $71.98 $60.15 - + Add to cart
15	CLAMP Part #: 5B4-F1338-00-00 Required per assembly: 2 $3.60 $2.98 - + Add to cart
16	CLAMP Part #: 90464-12830-00 Required per assembly: 2 $1.49 $1.03 - + Add to cart
17	CLAMP Part #: 90464-48800-00 Required per assembly: 3 Note: Sold in multiples of 100 only $4.90 $3.46 - + Add to cart
18	HOSE, CLUTCH, 1 Part #: B57-26472-00-00 Required per assembly: 1 $73.98 $66.30 - + Add to cart
19	TANK, RESERVOIR Part #: 5JJ-25894-01-00 Required per assembly: 1 $41.99 $28.25 - + Add to cart
20	CAP, RESERVOIR Part #: 3XP-25852-50-00 Required per assembly: 1 Note: (USA) $24.98 $18.05 - + Add to cart
21	DIAPHRAGM, RESERVOIR Part #: 2VN-25854-00-00 Required per assembly: 1 $26.98 $19.28 - + Add to cart
22	BUSH, DIAPHRAGM Part #: 2VN-25855-00-00 Required per assembly: 1 $11.99 $9.39 - + Add to cart
23	BOLT, WITH, WASHER Part #: 90119-06137-00 Required per assembly: 1 $9.49 $6.12 - + Add to cart
24	HOSE, RESERVOIR Part #: B57-25895-00-00 Required per assembly: 1 $32.99 $27.16 - + Add to cart
25	CLIP, SCISSOR Part #: 90467-11044-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
26	BOLT, UNION Part #: 90401-10172-00 Required per assembly: 2 $6.49 $3.64 - + Add to cart
27	WASHER, PLATE Part #: 90201-10118-00 Required per assembly: 4 Note: Sold in multiples of 5 only $3.79 $2.84 - + Add to cart
28	PARKING LEVER ASSEMBLY Part #: BDW-F5690-00-00 Required per assembly: 1 $80.98 $72.77 - + Add to cart
29	SWITCH COMP. Part #: 5UG-H251S-00-00 Required per assembly: 1 Note: (YMUS) Not Available
30	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
31	WIRE, BRAKE, 1 Part #: 2HC-26341-01-00 Required per assembly: 1 $58.99 $48.61 - + Add to cart
