Front Fork replacement parts for 2023 Yamaha YZ250X

OEM Parts Yamaha 2023 Yamaha YZ250X Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	DAMPER ASSEMBLY (L) Part #: BRY-23102-00-00 Required per assembly: 1 $1,164.22 $1,073.38 - + Add to cart
2	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 $649.99 $638.80 - + Add to cart
3	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.49 $4.10 - + Add to cart
4	INNER TUBE COMP.2 Part #: BCR-23120-00-00 Required per assembly: 1 $349.99 $343.96 - + Add to cart
5	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 $30.98 $20.32 - + Add to cart
6	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 $28.98 $20.64 - + Add to cart
7	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 $15.49 $10.07 - + Add to cart
8	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 $24.98 $20.38 - + Add to cart
9	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
10	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 $19.48 $15.74 - + Add to cart
11	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 $24.98 $18.93 - + Add to cart
12	CYLINDER, COMP, FRONT, FORK Part #: BRY-23170-00-00 Required per assembly: 1 $349.99 $343.96 - + Add to cart
13	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $3.75 $3.14 - + Add to cart
14	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 $80.98 $67.44 - + Add to cart
15	VALVE COMP. Part #: BRY-2316A-00-00 Required per assembly: 1 $199.99 $184.21 - + Add to cart
16	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $8.49 $6.61 - + Add to cart
17	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
18	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
19	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.00 $4.16 - + Add to cart
20	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 $25.98 $19.70 - + Add to cart
21	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 $4.29 $2.69 - + Add to cart
22	SPRING, FRONT, FORK, (K=4.3) Part #: B3J-23141-30-00 Required per assembly: 1 $120.98 $103.42 - + Add to cart
23	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 $78.98 $65.77 - + Add to cart
24	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
25	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.09 $3.18 - + Add to cart
26	DAMPER ASSEMBLY (R) Part #: BRY-23103-00-00 Required per assembly: 1 $1,164.22 $1,073.38 - + Add to cart
27	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 $649.99 $638.80 - + Add to cart
28	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.49 $4.10 - + Add to cart
29	INNER TUBE COMP.1 Part #: BCR-23110-00-00 Required per assembly: 1 $349.99 $343.96 - + Add to cart
30	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 $30.98 $20.32 - + Add to cart
31	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 $28.98 $20.64 - + Add to cart
32	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 $15.49 $10.07 - + Add to cart
33	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 $24.98 $20.38 - + Add to cart
34	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
35	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 $19.48 $15.74 - + Add to cart
36	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 $24.98 $18.93 - + Add to cart
37	CYLINDER, COMP, FRONT, FORK Part #: BRY-23170-00-00 Required per assembly: 1 $349.99 $343.96 - + Add to cart
38	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $3.75 $3.14 - + Add to cart
39	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 $80.98 $67.44 - + Add to cart
40	VALVE COMP. Part #: BRY-2316A-00-00 Required per assembly: 1 $199.99 $184.21 - + Add to cart
41	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $8.49 $6.61 - + Add to cart
42	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
43	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
44	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.00 $4.16 - + Add to cart
45	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 $25.98 $19.70 - + Add to cart
46	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 $4.29 $2.69 - + Add to cart
47	SPRING, FRONT, FORK, (K=4.3) Part #: B3J-23141-30-00 Required per assembly: 1 $120.98 $103.42 - + Add to cart
48	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 $78.98 $65.77 - + Add to cart
49	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
50	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.09 $3.18 - + Add to cart
51	UNDER BRACKET COMP. Part #: 1SS-23340-10-00 Required per assembly: 1 $711.40 $652.73 - + Add to cart
52	BEARING (4SR) Part #: 93332-00081-00 Required per assembly: 1 $63.99 - + Add to cart
53	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08035-00 Required per assembly: 8 $2.85 $2.42 - + Add to cart
54	GUIDE, CABLE Part #: BF1-23389-00-00 Required per assembly: 1 $8.49 $6.34 - + Add to cart
55	BOLT, FLANGE, DEEP, RECESS Part #: 95E32-06016-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
56	COLLAR Part #: 90387-06104-00 Required per assembly: 1 $1.60 $1.30 - + Add to cart
57	PROTECTOR 2 Part #: 17D-2315J-J0-00 Required per assembly: 1 $17.48 $16.41 - + Add to cart
58	PROTECTOR 1 Part #: 17D-2315H-J0-00 Required per assembly: 1 $17.48 $16.41 - + Add to cart
59	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.15 $3.43 - + Add to cart
60	CLAMP Part #: 17D-23466-00-00 Required per assembly: 1 $18.98 $15.74 - + Add to cart
61	CLAMP Part #: 17D-23467-00-00 Required per assembly: 1 $27.98 $21.55 - + Add to cart
62	BOLT, FLANGE Part #: 90105-06170-00 Required per assembly: 2 $5.49 $4.16 - + Add to cart
