Front Fork replacement parts for 2023 Yamaha YZ450FX

OEM Parts Yamaha 2023 Yamaha YZ450FX Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: BEX-23102-01-00 Required per assembly: 1 $1,159.20 - + Add to cart
2	TUBE, OUTER, (RIGHT) Part #: 33D-23136-00-00 Required per assembly: 1 $727.36 - + Add to cart
3	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
4	INNER TUBE COMP.2 Part #: B7R-23120-01-00 Required per assembly: 1 ~~$377.99~~ $366.38 - + Add to cart
5	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
6	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
7	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
8	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 ~~$24.98~~ $22.79 - + Add to cart
9	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
10	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 ~~$19.48~~ $18.90 - + Add to cart
11	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 ~~$24.98~~ $21.65 - + Add to cart
12	CYLINDER, COMP, FRONT, FORK Part #: B3J-23170-21-00 Required per assembly: 1 ~~$664.99~~ $648.55 - + Add to cart
13	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
14	SEAT, SPRING, UPPER Part #: BR9-23142-01-00 Required per assembly: 1 ~~$63.99~~ $51.51 - + Add to cart
15	VALVE COMP. Part #: BEX-2316A-01-00 Required per assembly: 1 ~~$346.99~~ $340.04 - + Add to cart
16	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $9.01 - + Add to cart
17	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
18	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.85 - + Add to cart
19	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
20	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
21	SPRING, FRONT, FORK, (K=4.6) Part #: BR9-23141-30-00 Required per assembly: 1 ~~$118.98~~ $115.80 - + Add to cart
22	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
23	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
24	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
25	FRONT FORK ASSEMBLY (R.H) Part #: BEX-23103-01-00 Required per assembly: 1 $1,159.20 - + Add to cart
26	TUBE, OUTER, (RIGHT) Part #: 33D-23136-00-00 Required per assembly: 1 $727.36 - + Add to cart
27	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
28	INNER TUBE COMP.1 Part #: B7R-23110-01-00 Required per assembly: 1 ~~$451.99~~ $403.91 - + Add to cart
29	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
30	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
31	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
32	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 ~~$24.98~~ $22.79 - + Add to cart
33	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
34	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 ~~$19.48~~ $18.90 - + Add to cart
35	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 ~~$24.98~~ $21.65 - + Add to cart
36	CYLINDER, COMP, FRONT, FORK Part #: B3J-23170-21-00 Required per assembly: 1 ~~$664.99~~ $648.55 - + Add to cart
37	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
38	SEAT, SPRING, UPPER Part #: BR9-23142-01-00 Required per assembly: 1 ~~$63.99~~ $51.51 - + Add to cart
39	VALVE COMP. Part #: BEX-2316A-01-00 Required per assembly: 1 ~~$346.99~~ $340.04 - + Add to cart
40	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $9.01 - + Add to cart
41	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
42	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.85 - + Add to cart
43	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
44	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
45	SPRING, FRONT, FORK, (K=4.6) Part #: BR9-23141-30-00 Required per assembly: 1 ~~$118.98~~ $115.80 - + Add to cart
46	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
47	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
48	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
49	UNDER BRACKET COMP. Part #: 33D-23340-20-00 Required per assembly: 1 $493.07 - + Add to cart
50	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08035-00 Required per assembly: 8 $3.48 - + Add to cart
51	PROTECTOR 2 Part #: 17D-2315J-J0-00 Required per assembly: 1 $19.50 - + Add to cart
52	PROTECTOR 1 Part #: 17D-2315H-J0-00 Required per assembly: 1 $19.50 - + Add to cart
53	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.87 - + Add to cart
54	CLAMP Part #: 17D-23466-00-00 Required per assembly: 1 ~~$18.98~~ $18.90 - + Add to cart
55	CLAMP Part #: 17D-23467-00-00 Required per assembly: 1 ~~$27.98~~ $23.64 - + Add to cart
56	BOLT, FLANGE Part #: 90105-06170-00 Required per assembly: 2 $5.85 - + Add to cart
