Windshield replacement parts for 2023 Yamaha YZF-R3 ABS

OEM Parts Yamaha 2023 Yamaha YZF R3 ABS Windshield

WINDSHIELD Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WINDSHIELD Part #: BS7-F8381-00-00 Required per assembly: 1 $56.12 - + Add to cart
2	NUT, SPEC'L, SHAPE Part #: 90179-05523-00 Required per assembly: 4 Note: Sold in multiples of 5 only $7.49 $5.59 - + Add to cart
3	BODY, FRONT, UPPER, 1 Part #: BS7-F835G-00-00 Required per assembly: 1 $109.39 - + Add to cart
4	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 4 $2.60 $1.95 - + Add to cart
5	GROMMET Part #: 90480-13014-00 Required per assembly: 1 $9.49 $6.73 - + Add to cart
6	DAMPER, PLATE Part #: 90520-07808-00 Required per assembly: 2 $0.40 $0.36 - + Add to cart
7	BODY, COWLING Part #: BS7-F8351-00-P9 Required per assembly: 1 $56.96 - + Add to cart
8	SCREW, ROUND, HEAD Part #: 90150-05023-00 Required per assembly: 4 $3.29 $2.74 - + Add to cart
9	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 4 $5.59 $4.65 - + Add to cart
10	DAMPER, PLATE Part #: 90520-07808-00 Required per assembly: 2 $0.40 $0.36 - + Add to cart
11	SEAL (31B1) Part #: 31B-F8307-00-00 Required per assembly: 6 $2.35 $2.19 - + Add to cart
12	SEAL 2 Part #: 1WD-F414E-00-00 Required per assembly: 4 $3.50 $2.43 - + Add to cart
13	TRIM Part #: 1WD-F8376-00-00 Required per assembly: 4 $3.50 $2.43 - + Add to cart
14	WASHER, PLATE Part #: 90202-05088-00 Required per assembly: 4 $7.99 $7.56 - + Add to cart
15	PANEL, INNER, 4 Part #: BS7-F836N-00-00 Required per assembly: 1 $23.89 - + Add to cart
16	RIVET Part #: 90269-06816-00 Required per assembly: 3 $1.70 $1.41 - + Add to cart
17	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05003-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
18	DAMPER, LEG, SHIELD Part #: BS7-F8327-00-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
19	PANEL, INNER, 5 Part #: BS7-F836R-00-00 Required per assembly: 1 $21.60 - + Add to cart
20	RIVET Part #: 90269-06816-00 Required per assembly: 3 $1.70 $1.41 - + Add to cart
21	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05003-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
22	DAMPER, LEG, SHIELD Part #: BS7-F8327-00-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
23	STAY 1 Part #: BS7-F8356-00-00 Required per assembly: 1 $54.22 - + Add to cart
24	BOLT, FLANGE Part #: 95817-08035-00 Required per assembly: 2 $10.49 $6.55 - + Add to cart
25	REAR VIEW MIRROR ASSEMBLY (LEFT) Part #: BS7-F6280-00-00 Required per assembly: 1 $69.29 - + Add to cart
26	REAR VIEW MIRROR ASSEMBLY (RIGHT) Part #: BS7-F6290-00-00 Required per assembly: 1 $107.77 - + Add to cart
27	PLATE, RUBBER, 1, (BK61) Part #: BK6-F8483-00-00 Required per assembly: 2 $1.33 $1.21 - + Add to cart
28	PLATE, RUBBER, 2 Part #: BS7-F8484-00-00 Required per assembly: 1 $14.49 $13.77 - + Add to cart
29	PLATE, RUBBER, 3 Part #: BS7-F8485-00-00 Required per assembly: 1 $6.49 $5.32 - + Add to cart
30	BOLT, HEXAGON, SOCKET, HEAD, (1VJ) Part #: 90110-06138-00 Required per assembly: 4 $6.49 $3.75 - + Add to cart
31	COLLAR Part #: 90387-06131-00 Required per assembly: 4 $8.49 $6.12 - + Add to cart
32	CAP, BOLT Part #: 20P-F3469-00-00 Required per assembly: 4 $3.39 $2.57 - + Add to cart
33	GRAPHIC 1 Part #: B5L-F8391-40-00 Required per assembly: 1 $4.29 $4.05 - + Add to cart
34	GRAPHIC 2 Part #: B5L-F8392-40-00 Required per assembly: 1 $4.29 $4.05 - + Add to cart
35	GRAPHIC 3 Part #: B5L-F8393-50-00 Required per assembly: 1 $1.20 $1.09 - + Add to cart
36	LABEL, NOTICE, WINDSHIELD, 1 Part #: 1WD-F815K-10-00 Required per assembly: 1 $1.35 $1.03 - + Add to cart
