OEM Parts Honda 2024 Honda CB650RAC Generator

2024 Honda CB650RAC - Generator

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
E 11
001

CLAMP, ALTERNATOR, CORD

Part #: 11333-MKY-D10 Required per assembly: 1
$2.30
$2.13
-
+
Add to cart
002

FLYWHEEL

Part #: 31110-MKY-D11 Required per assembly: 1
$205.02
$163.50
-
+
Add to cart
003

STATOR

Part #: 31120-MKY-E21 Required per assembly: 1
$246.24
$196.37
-
+
Add to cart
004

BOLT, FLANGE, (10MM)

Part #: 90023-MV9-670 Required per assembly: 1
$12.96
$10.82
-
+
Add to cart
005

WASHER (10.5X27)

Part #: 90406-MJE-D00 Required per assembly: 1
$4.32
-
+
Add to cart
006

BOLT, SOCKET, (6X16)

Part #: 96600-06016-00 Required per assembly: 1
$2.73
$2.54
-
+
Add to cart
007

BOLT, SOCKET, (6X35)

Part #: 96600-06035-00 Required per assembly: 4
$5.17
$4.70
-
+
Add to cart
