OEM Parts Honda 2024 Honda CT125A Switch - Cable - Mirror

2024 Honda CT125A TRAIL 125 - Switch - Cable - Mirror

SWITCH - CABLE - MIRROR Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 04
001

CABLE A, THROTTLE

Part #: 17910-K2E-J11 Required per assembly: 1
$13.00
-
+
Add to cart
002

CABLE B, THROTTLE

Part #: 17920-K2E-J11 Required per assembly: 1
$11.00
-
+
Add to cart
003

SWITCH ASSEMBLY, ENGINE STOP

Part #: 35130-K2E-T11 Required per assembly: 1
$49.67
$39.59
-
+
Add to cart
004

SWITCH, ASSEMBLY, DIMMER, &, HORN, &, TURN, SIGNAL

Part #: 35200-K2E-T01 Required per assembly: 1
$59.78
$52.36
-
+
Add to cart
005

GRIP, THROTTLE

Part #: 53140-K2E-T00 Required per assembly: 1
$12.77
-
+
Add to cart
006

GRIP, L., HANDLE

Part #: 53166-K2E-T00 Required per assembly: 1
$9.05
-
+
Add to cart
007

HOLDER, BACK, MIRROR

Part #: 53173-K2E-T00 Required per assembly: 1
$14.87
-
+
Add to cart
008

CAP, LOCK, NUT

Part #: 88119-KWW-640 Required per assembly: 2
$2.65
$2.22
-
+
Add to cart
009

MIRROR *NH303M*(MAT AXIS GRAY METALLIC)

Part #: 88210-K2E-T01ZA Required per assembly: 2
$18.55
$18.24
-
+
Add to cart
010

BOLT, FLANGE, (6X28)

Part #: 90013-GHB-680 Required per assembly: 1
$2.06
$1.37
-
+
Add to cart
011

BOLT, ADAPTER, (10MM)

Part #: 90101-KWW-640 Required per assembly: 2
$3.27
$3.07
-
+
Add to cart
012

NUT, HEX., (10MM)

Part #: 90301-KWW-640 Required per assembly: 2
$2.07
$1.50
-
+
Add to cart
013

BAND, WIRE

Part #: 90650-KW3-000 Required per assembly: 4
$6.50
-
+
Add to cart
014

SCREW-WASHER (5X20)

Part #: 93892-05020-07 Required per assembly: 4
$1.90
$1.20
-
+
Add to cart
