Front Knuckle - Driveshaft replacement parts for 2024 Honda SXS1000M3D

OEM Parts Honda 2024 Honda SXS1000M3D Front Knuckle - Driveshaft

FRONT KNUCKLE - DRIVESHAFT Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 16
001	BAND, SHAFT, BOOT Part #: 44327-TZ4-A01 Required per assembly: 2 Note: Area: A AC $6.01 - + Add to cart
001	BAND, SHAFT, BOOT Part #: 42215-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$6.22~~ $5.68 - + Add to cart
002	BAND, SHAFT, BOOT Part #: 42215-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$6.22~~ $5.68 - + Add to cart
002	BAND, DYNAMIC, DAMPER Part #: 44329-T7J-H01 Required per assembly: 2 Note: Area: A AC ~~$12.88~~ $11.89 - + Add to cart
003	BAND, A, OUTBOARD Part #: 42231-HL4-AK1 Required per assembly: 2 Note: Area: A AC ~~$10.36~~ $9.11 - + Add to cart
003	BAND, B, OUTBOARD Part #: 42216-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$7.65~~ $6.87 - + Add to cart
004	BAND, B, INBOARD Part #: 42226-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$7.53~~ $6.76 - + Add to cart
004	BAND, A, INBOARD Part #: 42234-HL4-AK1 Required per assembly: 2 Note: Area: A AC ~~$15.40~~ $13.04 - + Add to cart
005	RING, SNAP Part #: 42228-HL4-A01 Required per assembly: 2 Note: Area: A AC $3.54 - + Add to cart
006	JOINT, FR., INBOARD Part #: 44220-HL4-A01 Required per assembly: 2 Note: Area: A AC ~~$181.33~~ $150.63 - + Add to cart
007	JOINT, INBOARD Part #: 44220-HL4-F42 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$116.04~~ $96.34 - + Add to cart
008	BOOT, SET, FR., INBOARD Part #: 44230-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$63.25~~ $52.55 - + Add to cart
008	BOOT, SET, FR., INBOARD Part #: 44260-HL4-AK1 Required per assembly: 2 Note: Area: A AC ~~$71.15~~ $59.07 - + Add to cart
009	BOOT, SET, FR. Part #: 44240-HL4-AK1 Required per assembly: 2 Note: Area: A AC ~~$106.82~~ $89.15 - + Add to cart
009	BOOT, SET, FR. Part #: 44240-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$91.02~~ $75.60 - + Add to cart
010	SHAFT, SET, R., FR., DRIVE Part #: 44250-HL4-AQ1 Required per assembly: 1 Note: Area: 6A 6AC 7A 7AC ~~$200.65~~ $179.02 - + Add to cart
010	SHAFT, SET, FR., DRIVE Part #: 44250-HL4-AK1 Required per assembly: 1 Note: Area: A AC ~~$311.49~~ $254.63 - + Add to cart
011	SHAFT, SET, FR., DRIVE Part #: 44250-HL4-AK1 Required per assembly: 1 Note: Area: A AC ~~$311.49~~ $254.63 - + Add to cart
011	SHAFT, SET, L., FR., DRIVE Part #: 44350-HL4-AQ1 Required per assembly: 1 Note: Area: 6A 6AC 7A 7AC ~~$200.62~~ $179.00 - + Add to cart
012	RING, B, INBOARD, SNAP Part #: 90654-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$5.22~~ $4.85 - + Add to cart
012	SET-RING (26X1.8) Part #: 44319-SR1-003 Required per assembly: 2 Note: Area: A AC ~~$4.64~~ $4.22 - + Add to cart
013	CIRCLIP Part #: 44338-S0X-A01 Required per assembly: 2 Note: Area: A AC $5.92 - + Add to cart
014	COVER, R., FR., DISK Part #: 45255-HL4-AK0 Required per assembly: 1 ~~$6.05~~ $5.33 - + Add to cart
015	COVER, L., FR., DISK Part #: 45256-HL4-AK0 Required per assembly: 1 ~~$6.05~~ $5.33 - + Add to cart
016	KNUCKLE, ASSEMBLY, R., FR. Part #: 51200-HL4-AK0 Required per assembly: 1 ~~$133.82~~ $106.72 - + Add to cart
017	KNUCKLE, ASSEMBLY, L., FR. Part #: 51250-HL4-AK0 Required per assembly: 1 ~~$133.82~~ $109.39 - + Add to cart
018	GUARD, R., FR. Part #: 51325-HL4-A00 Required per assembly: 1 $3.32 - + Add to cart
019	GUARD, L., FR. Part #: 51326-HL4-A00 Required per assembly: 1 $3.32 - + Add to cart
020	BOLT, SHOULDER, (6X20), (5.0) Part #: 90109-HL6-A00 Required per assembly: 2 ~~$3.17~~ $3.00 - + Add to cart
021	BOLT, FLANGE, (6MM) Part #: 90111-KT1-780 Required per assembly: 4 ~~$15.46~~ $14.05 - + Add to cart
022	CIRCLIP (INNER) (75) Part #: 90651-HL3-A40 Required per assembly: 2 ~~$11.52~~ $11.31 - + Add to cart
023	RING, OUTBOARD, SNAP, (INBOARD) Part #: 90653-HL4-F41 Required per assembly: 2 Note: Area: 6A 6AC 7A 7AC ~~$5.42~~ $5.01 - + Add to cart
024	BEARING (40X74X36) Part #: 91054-HL3-A41 Required per assembly: 2 ~~$38.56~~ $33.68 - + Add to cart
