OEM Parts Kawasaki 2024 Kawasaki KX250X Frame

2024 Kawasaki KX250X KX252-DRFNN - Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
32160

FRAME-COMP, RR

Part #: 32160-0976 Required per assembly: 1
$695.07
-
+
Add to cart
32160B

FRAME-COMP, MAIN

Part #: 32160-1933 Required per assembly: 1
$2,833.18
-
+
Add to cart
92002

BOLT, SOCKET, 8X20

Part #: 92150-1760 Required per assembly: 2
$6.74
$5.19
-
+
Add to cart
92015

NUT, POP, 6MM, L=15

Part #: 92015-1791 Required per assembly: 2
$4.82
$3.79
-
+
Add to cart
92015A

NUT, STEERING, STEM, 28MM

Part #: 92015-1861 Required per assembly: 1
$18.47
$15.42
-
+
Add to cart
92022

WASHER, 25X36X2.3

Part #: 92022-250 Required per assembly: 1
$5.14
$4.02
-
+
Add to cart
92066

PLUG

Part #: 92066-1547 Required per assembly: 1
$3.72
$2.89
-
+
Add to cart
92116

BEARING-ROLLER, HI-CAP32006JRRS

Part #: 92116-1069 Required per assembly: 1
$65.67
$60.90
-
+
Add to cart
92116A

BEARING-ROLLER, HI-CAP320/28JRR

Part #: 92116-1076 Required per assembly: 1
$52.63
$48.02
-
+
Add to cart
92154

BOLT, SOCKET, 8X28

Part #: 92154-2991 Required per assembly: 2
$7.65
$6.65
-
+
Add to cart
92161

DAMPER

Part #: 92161-2175 Required per assembly: 2
$10.02
$8.57
-
+
Add to cart
92210

NUT, 24MM

Part #: 92210-0066 Required per assembly: 1
$12.07
$10.23
-
+
Add to cart
92210A

NUT, LARGE, FLANGE, 6MM, L=16.5

Part #: 92210-1623 Required per assembly: 2
$3.05
$2.19
-
+
Add to cart
