Drive Converter replacement parts for 2024 Kawasaki Mule PRO-FXT 1000 LE

OEM Parts Kawasaki 2024 Kawasaki Mule PRO FXT 1000 LE Drive Converter

Drive Converter Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

130	BOLT-FLANGED, 6X30 Part #: 130CA0630 Required per assembly: 8 Note: Sold in multiples of 5 only $2.57 $1.86 - + Add to cart
14092	COVER Part #: 14092-1201 Required per assembly: 1 $81.22 - + Add to cart
39152	WEIGHT-RAMP Part #: 39152-0107 Required per assembly: 4 $71.83 $66.36 - + Add to cart
49048	SHOE, T=7.2 Part #: 49048-1087 Required per assembly: 1 Note: (OPTION) $15.10 $12.51 - + Add to cart
49048A	SHOE, T=7.3 Part #: 49048-1088 Required per assembly: 1 Note: (OPTION) $11.54 - + Add to cart
49048B	SHOE, T=7.4 Part #: 49048-1089 Required per assembly: 1 $15.10 $12.51 - + Add to cart
49048C	SHOE, T=7.5 Part #: 49048-1090 Required per assembly: 8 Note: (OPTION) $15.10 $12.51 - + Add to cart
49048D	SHOE, T=7.6 Part #: 49048-1091 Required per assembly: 1 Note: (OPTION) $15.10 $12.51 - + Add to cart
49048E	SHOE, T=7.7 Part #: 49048-1092 Required per assembly: 1 Note: (OPTION) $15.10 $12.51 - + Add to cart
49048F	SHOE, T=7.8 Part #: 49048-1093 Required per assembly: 1 Note: (OPTION) $15.10 $12.51 - + Add to cart
49048G	SHOE, T=7.9 Part #: 49048-1094 Required per assembly: 1 Note: (OPTION) $15.10 $12.51 - + Add to cart
49048H	SHOE, T=8.0 Part #: 49048-1095 Required per assembly: 1 Note: (OPTION) $15.10 $12.51 - + Add to cart
49050	SPIDER Part #: 49050-0567 Required per assembly: 1 $187.29 $184.11 - + Add to cart
49093	CONVERTER-ASSY-DRIVE Part #: 49093-0114 Required per assembly: 1 $1,057.18 - + Add to cart
59302	SHEAVE-COMP Part #: 59302-0113 Required per assembly: 1 $792.28 - + Add to cart
59302A	SHEAVE-COMP, MOVABLE Part #: 59302-0119 Required per assembly: 1 $315.79 $313.46 - + Add to cart
92019	NUT, LOCK, 6MM Part #: 92019-008 Required per assembly: 8 $4.35 $3.28 - + Add to cart
92043	PIN Part #: 92043-0809 Required per assembly: 4 $16.40 $13.68 - + Add to cart
92043A	PIN, 6.2X8X14 Part #: 92043-1263 Required per assembly: 2 Note: Sold in multiples of 5 only $0.49 $0.48 - + Add to cart
92139	BUSHING Part #: 92139-1243 Required per assembly: 1 $8.14 $7.05 - + Add to cart
92139A	BUSHING Part #: 92139-1244 Required per assembly: 1 $13.13 $11.10 - + Add to cart
92139B	BUSHING, 9X11X19.75 Part #: 92139-1245 Required per assembly: 4 $7.76 $6.74 - + Add to cart
92145	SPRING Part #: 92145-2271 Required per assembly: 1 $44.91 $41.17 - + Add to cart
92154	BOLT-FLANGED, 12X171 Part #: 92154-4491 Required per assembly: 1 $7.49 $6.51 - + Add to cart
92200	WASHER, 13.4X25X1.6 Part #: 92200-0477 Required per assembly: 1 $3.82 $2.97 - + Add to cart
92210	NUT, LOCK Part #: 92210-1922 Required per assembly: 1 $32.98 $30.58 - + Add to cart
