2024 Yamaha 252SD BXT1900BA F7F2 - Control Cable

CONTROL CABLE Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

REMOCON. LEVER ASSY.

Part #: F3F-6134A-11-00 Required per assembly: 1
$1,678.24
$1,525.67
2

GASKET

Part #: F3F-67564-00-00 Required per assembly: 1
$152.99
$131.51
3

LEVER ASSEMBLY

Part #: F3F-6151M-10-00 Required per assembly: 2
$680.23
$618.39
4

BOLT

Part #: F3F-61355-00-00 Required per assembly: 1
$16.98
$12.84
5

SCREW, FLAT, HEAD, TAPPING

Part #: F3F-67869-00-00 Required per assembly: 2
$10.99
$6.11
6

SCREW, PAN, HEAD

Part #: 90157-10S16-00 Required per assembly: 4
$4.99
$0.83
7

PLATE

Part #: F3F-U1348-00-00 Required per assembly: 2
$10.99
$6.11
8

SCREW, COUNTERSUNK

Part #: 90151-10S20-00 Required per assembly: 4
$0.45
$0.33
9

WASHER, #10, FLAT

Part #: 90201-10S00-00 Required per assembly: 4
$4.99
$0.56
10

NUT, SELF-LOCKING

Part #: 90185-10S00-00 Required per assembly: 4
$4.99
$0.98
11

CONTROL UNIT

Part #: F7F-68197-00-00 Required per assembly: 1
Not Available
12

MAT, WATER, LOCK

Part #: GJ3-U755J-00-00 Required per assembly: 2
$112.98
$86.17
13

EYE STRAP

Part #: F3F-U1543-00-00 Required per assembly: 4
$9.49
$7.11
14

SCREW, TAPPING

Part #: 90167-08SA8-00 Required per assembly: 8
$5.99
$1.06
15

CONTROL UNIT ASSY

Part #: F7F-83677-00-00 Required per assembly: 1
Not Available
