Crankshaft & Piston replacement parts for 2024 Yamaha 275SE

OEM Parts Yamaha 2024 Yamaha 275SE Crankshaft & Piston

CRANKSHAFT & PISTON Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CRANKSHAFT Part #: 6LE-11411-00-00 Required per assembly: 1 ~~$2,696.48~~ $2,665.52 - + Add to cart
2	PLANE, BEARING, CRANKSHAFT, 1 Part #: 6LE-11416-00-00 Required per assembly: 10 ~~$15.99~~ $15.86 - + Add to cart
2	PLANE, BEARING, CRANKSHAFT, 1 Part #: 6LE-11416-10-00 Required per assembly: 10 ~~$23.27~~ $21.15 - + Add to cart
2	PLANE, BEARING, CRANKSHAFT, 1 Part #: 6LE-11416-20-00 Required per assembly: 10 ~~$19.11~~ $17.37 - + Add to cart
2	PLANE, BEARING, CRANKSHAFT, 1 Part #: 6LE-11416-30-00 Required per assembly: 10 ~~$15.99~~ $15.86 - + Add to cart
2	PLANE, BEARING, CRANKSHAFT, 1 Part #: 6LE-11416-40-00 Required per assembly: 10 ~~$23.27~~ $21.15 - + Add to cart
3	PISTON (STD) Part #: 6ET-11631-01-B0 Required per assembly: 4 ~~$136.49~~ $134.54 - + Add to cart
4	PISTON RING SET (STD) Part #: 6S5-11603-01-00 Required per assembly: 4 ~~$74.98~~ $74.07 - + Add to cart
5	CIRCLIP Part #: 93450-22174-00 Required per assembly: 4 ~~$0.30~~ $0.28 - + Add to cart
6	PIN, PISTON Part #: 6ET-11633-00-00 Required per assembly: 4 ~~$39.88~~ $36.26 - + Add to cart
7	CIRCLIP Part #: 93450-22174-00 Required per assembly: 4 ~~$0.30~~ $0.28 - + Add to cart
8	CONNECTING ROD ASSEMBLY Part #: 6S5-11650-10-00 Required per assembly: 4 ~~$226.99~~ $223.76 - + Add to cart
9	BOLT, CONNECTING, ROD Part #: 6S5-11654-10-00 Required per assembly: 2 ~~$7.99~~ $7.24 - + Add to cart
10	PLANE, BEARING, CONNECTING, ROD Part #: 6LE-11656-00-00 Required per assembly: 8 ~~$22.98~~ $22.66 - + Add to cart
10	PLANE, BEARING, CONNECTING, ROD Part #: 6LE-11656-10-00 Required per assembly: 8 ~~$20.77~~ $18.88 - + Add to cart
10	PLANE, BEARING, CONNECTING, ROD Part #: 6LE-11656-20-00 Required per assembly: 8 ~~$17.48~~ $17.37 - + Add to cart
10	PLANE, BEARING, CONNECTING, ROD Part #: 6LE-11656-30-00 Required per assembly: 8 ~~$17.48~~ $17.37 - + Add to cart
11	SHAFT, TRANSFER Part #: 6S5-17572-01-00 Required per assembly: 1 ~~$310.49~~ $305.41 - + Add to cart
12	WASHER Part #: 6S5-12289-00-00 Required per assembly: 1 ~~$31.98~~ $31.72 - + Add to cart
13	FLANGE, COUPLING Part #: 6S5-45813-01-00 Required per assembly: 1 ~~$120.98~~ $119.42 - + Add to cart
14	HOLDER 2 Part #: 6S5-17525-01-00 Required per assembly: 1 ~~$84.81~~ $77.10 - + Add to cart
15	NUT, SPECIAL Part #: 6S5-11459-01-00 Required per assembly: 1 ~~$41.55~~ $37.77 - + Add to cart
16	GEAR UNIT ASSEMBLY Part #: 6ET-17800-10-00 Required per assembly: 1 ~~$665.49~~ $654.68 - + Add to cart
17	BOLT Part #: 6S5-17031-00-00 Required per assembly: 1 ~~$39.88~~ $36.26 - + Add to cart
18	DRIVE GEAR & COLLAR SET (18T) Part #: 6S5-W1783-20-00 Required per assembly: 1 ~~$518.49~~ $511.04 - + Add to cart
19	WASHER, THRUST Part #: 6S5-17529-00-00 Required per assembly: 1 ~~$14.49~~ $14.35 - + Add to cart
20	WASHER, PLATE Part #: 90201-13013-00 Required per assembly: 1 ~~$9.49~~ $6.17 - + Add to cart
21	CIRCLIP Part #: 99009-24700-00 Required per assembly: 2 ~~$1.49~~ $1.36 - + Add to cart
22	COLLAR, GEAR Part #: 6S5-17585-10-00 Required per assembly: 1 ~~$80.48~~ $80.12 - + Add to cart
23	SHAFT, MIDDLE, DRIVEN Part #: 6S5-17553-00-00 Required per assembly: 1 ~~$31.98~~ $31.72 - + Add to cart
