Electrical 4 replacement parts for 2024 Yamaha FX Cruiser SVHO with Audio

OEM Parts Yamaha 2024 Yamaha FX Cruiser SVHO with Audio Electrical 4

ELECTRICAL 4 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SPEAKER ASSEMBLY 1 Part #: F5G-U8102-00-00 Required per assembly: 1 $646.97 $603.15 - + Add to cart
2	PACKING, HOSE, 2 Part #: GJ1-U7578-12-00 Required per assembly: 1 $3.04 $1.29 - + Add to cart
3	CLAMP Part #: 90464-32801-00 Required per assembly: 1 Note: Sold in multiples of 5 only $6.11 $1.36 - + Add to cart
4	BOLT Part #: F3X-U13B4-00-00 Required per assembly: 2 $6.11 $1.13 - + Add to cart
5	PACKING Part #: F5G-U143K-00-00 Required per assembly: 2 $10.18 $5.67 - + Add to cart
6	COLLAR Part #: F5G-U0229-00-00 Required per assembly: 2 $7.12 $3.18 - + Add to cart
7	SPEAKER ASSEMBLY 2 Part #: F5G-U8103-00-00 Required per assembly: 1 $1,081.06 $997.78 - + Add to cart
8	PACKING, HOSE, 2 Part #: GJ1-U7578-12-00 Required per assembly: 1 $3.04 $1.29 - + Add to cart
9	CLAMP Part #: 90464-32801-00 Required per assembly: 1 Note: Sold in multiples of 5 only $6.11 $1.36 - + Add to cart
10	BOLT Part #: F3X-U13B4-00-00 Required per assembly: 2 $6.11 $1.13 - + Add to cart
11	PACKING Part #: F5G-U143K-00-00 Required per assembly: 2 $10.18 $5.67 - + Add to cart
12	COLLAR Part #: F5G-U0229-00-00 Required per assembly: 2 $7.12 $3.18 - + Add to cart
13	CONTROLLER, AUDIO Part #: F5G-U81AJ-01-00 Required per assembly: 1 $118.31 $92.22 - + Add to cart
14	WIRE, HARNESS Part #: F5G-U8275-01-00 Required per assembly: 1 $210.11 $181.41 - + Add to cart
15	BRACKET, SPEAKER, 1 Part #: F5G-UE6GA-01-00 Required per assembly: 1 $37.72 $29.45 - + Add to cart
16	BOLT Part #: F3X-U13B4-00-00 Required per assembly: 2 $6.11 $1.13 - + Add to cart
17	BRACKET Part #: F5G-U0392-00-00 Required per assembly: 1 $17.32 $13.59 - + Add to cart
18	BOLT, WITH, WASHER Part #: 90119-06878-00 Required per assembly: 1 $9.16 $3.78 - + Add to cart
19	BRACKET, SPEAKER, 1 Part #: F5G-UE6GA-11-00 Required per assembly: 1 $37.72 $29.45 - + Add to cart
20	BOLT Part #: F3X-U13B4-00-00 Required per assembly: 2 $6.11 $1.13 - + Add to cart
21	BRACKET Part #: F5G-U0392-10-00 Required per assembly: 1 $17.32 $13.59 - + Add to cart
22	BOLT, WITH, WASHER Part #: 90119-06878-00 Required per assembly: 1 $9.16 $3.78 - + Add to cart
