Exhaust 2 replacement parts for 2024 Yamaha FX HO with Audio

OEM Parts Yamaha 2024 Yamaha FX HO with Audio Exhaust 2

EXHAUST 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	HOSE Part #: F3X-U1273-00-00 Required per assembly: 1 $16.30 $11.32 - + Add to cart
2	TUBE (L200) Part #: 90447-22801-00 Required per assembly: 1 Note: (L200) $2.99 $1.06 - + Add to cart
3	TUBE (L485) Part #: 90447-19801-00 Required per assembly: 1 Note: (L485) $8.15 $3.55 - + Add to cart
4	HOSE 2 Part #: 6S5-1243E-01-00 Required per assembly: 1 $24.93 $22.66 - + Add to cart
5	TUBE Part #: F2T-U773D-00-00 Required per assembly: 1 $6.11 $1.36 - + Add to cart
6	CLIP Part #: 90467-200A3-00 Required per assembly: 1 $7.99 $7.24 - + Add to cart
7	JOINT, HOSE, 3 Part #: 6BH-12584-00-00 Required per assembly: 1 $5.99 $5.44 - + Add to cart
8	HOSE (L400) Part #: 90445-18012-00 Required per assembly: 1 Note: (L400) $24.98 $24.92 - + Add to cart
9	HOSE, WITH, SPRING Part #: 90447-19005-00 Required per assembly: 1 Note: (L260) $3.99 $3.61 - + Add to cart
10	CLIP Part #: 90467-160A0-00 Required per assembly: 2 $3.99 $3.61 - + Add to cart
11	CLAMP Part #: 90464-35132-00 Required per assembly: 1 $10.49 $6.74 - + Add to cart
12	HOSE 6 Part #: 6S5-12589-01-00 Required per assembly: 1 $25.98 $18.49 - + Add to cart
13	CLIP Part #: 90467-200A3-00 Required per assembly: 2 $7.99 $7.24 - + Add to cart
14	HOSE 5 Part #: 6LE-1244H-00-00 Required per assembly: 1 $34.89 $31.72 - + Add to cart
15	CLIP Part #: 90467-141A3-00 Required per assembly: 2 $2.99 $2.72 - + Add to cart
16	HOSE 5 Part #: 6CS-12588-00-00 Required per assembly: 1 $27.98 $27.94 - + Add to cart
17	TUBE (L760) Part #: 90447-19018-00 Required per assembly: 1 Note: (L760) $9.49 $9.06 - + Add to cart
18	CLIP Part #: 90467-160A0-00 Required per assembly: 1 $3.99 $3.61 - + Add to cart
19	HOSE (L100) Part #: 90445-16027-00 Required per assembly: 1 $7.49 $5.94 - + Add to cart
20	CLIP Part #: 90467-141A3-00 Required per assembly: 2 $2.99 $2.72 - + Add to cart
21	HOSE 1 Part #: 6LE-12576-00-00 Required per assembly: 1 $45.99 $45.33 - + Add to cart
22	CLIP Part #: 90467-160A0-00 Required per assembly: 2 $3.99 $3.61 - + Add to cart
23	COVER 1 Part #: 6LE-1246A-00-00 Required per assembly: 1 $34.99 $34.75 - + Add to cart
24	BOLT, FLANGE Part #: 90105-06035-00 Required per assembly: 2 $2.49 $2.27 - + Add to cart
25	O-RING Part #: 93210-30M31-00 Required per assembly: 1 Note: FOR PREV. MODEL (~ 94) $11.49 $11.32 - + Add to cart
26	WAVERUNNER / JET BOAT CONDUCTION WATER FLUSH FITTING Part #: 67X-E2590-00-00 Required per assembly: 1 $8.15 $6.33 - + Add to cart
27	NUT Part #: EU0-61652-00-00 Required per assembly: 1 $19.98 $13.18 - + Add to cart
28	PACKING Part #: F2S-U7525-01-00 Required per assembly: 1 $1.01 $0.91 - + Add to cart
29	JOINT, HOSE, 1 Part #: 60E-12581-00-00 Required per assembly: 1 $17.45 $15.86 - + Add to cart
30	JOINT ASSEMBLY Part #: 64T-12580-00-00 Required per assembly: 1 $114.48 $113.37 - + Add to cart
31	CLIP Part #: 90467-150A5-00 Required per assembly: 1 $2.99 $2.72 - + Add to cart
32	CAP, 1 Part #: 6EY-84385-00-00 Required per assembly: 1 $15.78 $14.35 - + Add to cart
33	CLIP Part #: 90467-200A3-00 Required per assembly: 1 $7.99 $7.24 - + Add to cart
34	CLIP Part #: 90467-200A3-00 Required per assembly: 1 $7.99 $7.24 - + Add to cart
