Seat Cushion replacement parts for 2024 Yamaha 220 FSH Sport

OEM Parts Yamaha 2024 Yamaha 220 FSH Sport Seat Cushion

SEAT CUSHION Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BACKREST, MAIN, 1 Part #: F6E-U35E1-00-00 Required per assembly: 1 ~~$339.64~~ $288.78 - + Add to cart
2	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 2 ~~$8.15~~ $5.43 - + Add to cart
3	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 5 ~~$6.11~~ $1.66 - + Add to cart
4	BACKREST, MAIN, 2 Part #: F6E-U35E2-00-00 Required per assembly: 1 Not Available
5	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 2 ~~$8.15~~ $5.43 - + Add to cart
6	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 5 ~~$6.11~~ $1.66 - + Add to cart
7	BACKREST, MAIN, 3 Part #: F6E-U35E3-00-00 Required per assembly: 1 ~~$309.05~~ $287.26 - + Add to cart
8	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 3 ~~$8.15~~ $5.43 - + Add to cart
9	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 8 ~~$6.11~~ $1.66 - + Add to cart
10	BACKREST, MAIN, 4 Part #: F6E-U35E4-00-00 Required per assembly: 1 Not Available
11	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 3 ~~$8.15~~ $5.43 - + Add to cart
12	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 8 ~~$6.11~~ $1.66 - + Add to cart
13	BACKREST, MAIN, 5 Part #: F6E-U35E5-00-00 Required per assembly: 1 ~~$346.79~~ $322.04 - + Add to cart
14	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 4 ~~$8.15~~ $5.43 - + Add to cart
15	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.66 - + Add to cart
16	BACKREST, MAIN, 6 Part #: F6E-U35E6-00-00 Required per assembly: 1 ~~$382.49~~ $368.16 - + Add to cart
17	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 4 ~~$8.15~~ $5.43 - + Add to cart
18	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 10 ~~$6.11~~ $1.66 - + Add to cart
19	CUSHION, SEAT, REAR, (BLACK, COAT, 2) Part #: F6H-U3724-00-00 Required per assembly: 1 ~~$366.17~~ $353.63 - + Add to cart
20	WASHER, FENDER Part #: 90209-14SA3-00 Required per assembly: 4 ~~$6.11~~ $1.87 - + Add to cart
21	WASHER, 1/4", LOCK Part #: 90204-14S00-00 Required per assembly: 4 ~~$6.11~~ $1.66 - + Add to cart
22	NUT, 1/4-20 Part #: 90170-14S00-00 Required per assembly: 4 ~~$5.08~~ $0.89 - + Add to cart
23	BACKREST 1 (BLACK COAT 2) Part #: F6H-U3766-00-00 Required per assembly: 1 ~~$427.37~~ $407.14 - + Add to cart
24	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 6 ~~$8.15~~ $5.43 - + Add to cart
25	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 14 ~~$6.11~~ $1.66 - + Add to cart
26	CUSHION 1 Part #: F6A-U371D-10-00 Required per assembly: 1 ~~$331.49~~ $321.92 - + Add to cart
27	CUSHION 2 Part #: F6A-U371E-10-00 Required per assembly: 1 ~~$308.02~~ $300.75 - + Add to cart
28	BACK REST 1 Part #: F6A-U3791-10-00 Required per assembly: 1 Not Available
29	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 4 $0.89 - + Add to cart
30	WASHER, FENDER, (1/4", X, 1") Part #: 90209-14SA2-00 Required per assembly: 4 ~~$2.02~~ $0.89 - + Add to cart
31	EYE STRAP Part #: F2D-U1543-00-00 Required per assembly: 1 ~~$20.39~~ $19.01 - + Add to cart
32	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 2 $0.89 - + Add to cart
33	BACK REST 2 Part #: F6A-U3795-10-00 Required per assembly: 1 Not Available
34	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 4 $0.89 - + Add to cart
35	WASHER, FENDER, (1/4", X, 1") Part #: 90209-14SA2-00 Required per assembly: 4 ~~$2.02~~ $0.89 - + Add to cart
36	EYE STRAP Part #: F2D-U1543-00-00 Required per assembly: 1 ~~$20.39~~ $19.01 - + Add to cart
37	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 2 $0.89 - + Add to cart
38	BASE, DRIVER, SEAT Part #: F6A-U3712-00-00 Required per assembly: 1 $1,507.95 - + Add to cart
39	SCREW 1/4-20X1 1/4 Part #: 90152-14S20-00 Required per assembly: 6 ~~$6.11~~ $2.20 - + Add to cart
40	WASHER Part #: 90209-14SA6-00 Required per assembly: 6 ~~$6.11~~ $2.31 - + Add to cart
41	CUSHION, PAD, 1 Part #: F6A-U142E-10-00 Required per assembly: 1 ~~$533.45~~ $485.90 - + Add to cart
42	WASHER, 1/4", LOCK Part #: 90204-14S00-00 Required per assembly: 5 ~~$6.11~~ $1.66 - + Add to cart
43	NUT, 1/4-20 Part #: 90170-14S00-00 Required per assembly: 5 ~~$5.08~~ $0.89 - + Add to cart
44	WASHER, FENDER Part #: 90209-14SA3-00 Required per assembly: 5 ~~$6.11~~ $1.87 - + Add to cart
45	BACK REST 3 Part #: F6A-U3796-10-00 Required per assembly: 1 $1,153.62 - + Add to cart
46	SCREW, COUNTERSUNK Part #: 90151-14S16-00 Required per assembly: 6 ~~$6.11~~ $2.31 - + Add to cart
47	WASHER, FENDER, (1/4", X, 1") Part #: 90209-14SA2-00 Required per assembly: 6 ~~$2.02~~ $0.89 - + Add to cart
48	NUT, SELF-LOCKING Part #: 90185-14S00-00 Required per assembly: 6 ~~$5.08~~ $1.00 - + Add to cart
49	PAD 1 Part #: F6A-U521C-10-00 Required per assembly: 1 Not Available
50	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 5 ~~$8.15~~ $5.43 - + Add to cart
51	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 12 ~~$6.11~~ $1.66 - + Add to cart
52	PAD 2 Part #: F6A-U521D-10-00 Required per assembly: 1 ~~$409.00~~ $392.75 - + Add to cart
53	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 5 ~~$8.15~~ $5.43 - + Add to cart
54	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 12 ~~$6.11~~ $1.66 - + Add to cart
