Front Fork replacement parts for 2024 Yamaha MT-03

OEM Parts Yamaha 2024 Yamaha MT 03 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY Part #: B9T-F3100-10-00 Required per assembly: 1 ~~$957.99~~ $921.81 - + Add to cart
2	FRONT FORK ASSEMBLY (RH) Part #: B9T-F3103-10-00 Required per assembly: 1 ~~$396.99~~ $393.96 - + Add to cart
3	INNER TUBE COMP.2 Part #: B9T-F3120-10-00 Required per assembly: 1 $229.08 - + Add to cart
4	ROD COMP. (BK61) Part #: BK6-F330G-00-00 Required per assembly: 1 ~~$30.98~~ $25.95 - + Add to cart
5	SPRING, SHOCK, ABSORBER, 2, (BK61 Part #: 3AH-22222-00-00 Required per assembly: 1 $6.71 - + Add to cart
6	SPRING, FRONT, FORK Part #: B9T-F3141-00-00 Required per assembly: 1 ~~$29.98~~ $25.83 - + Add to cart
7	CAP (BK61) Part #: BK6-F319U-00-00 Required per assembly: 1 Not Available
8	SEAL, DUST Part #: B48-F3144-00-00 Required per assembly: 1 ~~$30.98~~ $27.88 - + Add to cart
9	RING, SNAP Part #: 3R4-23153-00-00 Required per assembly: 1 $10.25 - + Add to cart
10	OIL SEAL (BK61) Part #: BK6-F3145-00-00 Required per assembly: 1 $10.38 - + Add to cart
11	WASHER, SPRING, UPPER Part #: 31A-23149-31-00 Required per assembly: 1 $9.89 - + Add to cart
12	METAL, SLIDE, 1 Part #: 31A-23125-31-00 Required per assembly: 1 ~~$38.99~~ $30.66 - + Add to cart
13	PISTON, FRONT, FORK, (BK61) Part #: BK6-F3171-00-00 Required per assembly: 1 ~~$11.49~~ $11.02 - + Add to cart
14	TUBE, OUTER, (L.H) Part #: B9T-F3126-00-00 Required per assembly: 1 ~~$185.99~~ $179.97 - + Add to cart
15	BUMP, STOP, (BK61) Part #: BK6-F332K-00-00 Required per assembly: 1 $9.33 - + Add to cart
16	NUT, SPECIAL, (BK61) Part #: BK6-F3393-00-00 Required per assembly: 1 ~~$8.49~~ $8.38 - + Add to cart
17	BOLT, CAP Part #: BS7-F3111-00-00 Required per assembly: 1 ~~$47.99~~ $41.66 - + Add to cart
18	O-RING Part #: 4V4-23188-L1-00 Required per assembly: 1 $6.55 - + Add to cart
19	FRONT FORK ASSEMBLY (LH) Part #: B9T-F3102-00-00 Required per assembly: 1 ~~$443.99~~ $437.42 - + Add to cart
20	INNER TUBE COMP.1 Part #: BS7-F3110-00-00 Required per assembly: 1 $177.73 - + Add to cart
21	SEAL, DUST Part #: B48-F3144-00-00 Required per assembly: 1 ~~$30.98~~ $27.88 - + Add to cart
22	RING, SNAP Part #: 3R4-23153-00-00 Required per assembly: 1 $10.25 - + Add to cart
23	OIL SEAL (BK61) Part #: BK6-F3145-00-00 Required per assembly: 1 $10.38 - + Add to cart
24	WASHER, SPRING, UPPER Part #: 31A-23149-31-00 Required per assembly: 1 $9.89 - + Add to cart
25	METAL, SLIDE, 1 Part #: 31A-23125-31-00 Required per assembly: 1 ~~$38.99~~ $30.66 - + Add to cart
26	PISTON, FRONT, FORK, (BK61) Part #: BK6-F3171-00-00 Required per assembly: 1 ~~$11.49~~ $11.02 - + Add to cart
27	TUBE, OUTER, (L.H) Part #: B9T-F3126-00-00 Required per assembly: 1 ~~$185.99~~ $179.97 - + Add to cart
28	CYLINDER, COMP, FRONT, FORK Part #: B9T-F3170-00-00 Required per assembly: 1 ~~$188.99~~ $170.86 - + Add to cart
29	GASKET Part #: 2BU-F3158-00-00 Required per assembly: 1 $5.16 - + Add to cart
30	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $10.11 - + Add to cart
31	SPRING, FRONT, FORK Part #: B9T-F3141-00-00 Required per assembly: 1 ~~$29.98~~ $25.83 - + Add to cart
32	GUIDE, SPRING, (BK61) Part #: BK6-F3117-00-00 Required per assembly: 1 $6.67 - + Add to cart
33	SPACER Part #: BS7-F3118-00-00 Required per assembly: 1 $7.46 - + Add to cart
34	NUT (BK61) Part #: BK6-F3357-00-00 Required per assembly: 1 $3.40 - + Add to cart
35	BOLT, CAP Part #: BS7-F3111-00-00 Required per assembly: 1 ~~$47.99~~ $41.66 - + Add to cart
36	O-RING Part #: 4V4-23188-L1-00 Required per assembly: 1 $6.55 - + Add to cart
37	UNDER BRACKET ASSEMBLY Part #: BS7-F334M-00-00 Required per assembly: 1 $208.48 - + Add to cart
38	UNDER BRACKET COMP. Part #: BS7-F3340-00-00 Required per assembly: 1 $185.68 - + Add to cart
39	SEAL, STEERING Part #: 3FV-23462-00-00 Required per assembly: 1 ~~$26.98~~ $23.44 - + Add to cart
40	BEARING, SPECIAL Part #: 93399-99932-00 Required per assembly: 1 ~~$69.98~~ $55.57 - + Add to cart
41	BOLT, HEXAGON, SOCKET, HEAD Part #: 91317-10040-00 Required per assembly: 2 $5.43 - + Add to cart
