Engine Hatch replacement parts for 2024 Yamaha Super Jet

OEM Parts Yamaha 2024 Yamaha Super Jet Engine Hatch

ENGINE HATCH Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ENGINE ROOM HATCH ASSEMBLY Part #: F4R-6517A-00-P0 Required per assembly: 1 $2,312.35 - + Add to cart
2	HATCH, ENGINE, ROOM, 1 Part #: F4R-65161-00-P0 Required per assembly: 1 $495.24 - + Add to cart
3	LID, ENGINE, HATCH Part #: F4R-65171-00-P0 Required per assembly: 1 $491.24 - + Add to cart
4	FLOTATION, HATCH, 1 Part #: F4R-6514G-00-00 Required per assembly: 1 Not Available
5	FLOTATION, HATCH, 2 Part #: F4R-6514H-00-00 Required per assembly: 1 Not Available
6	PACKING Part #: F4R-62664-01-00 Required per assembly: 1 $167.99 $130.12 - + Add to cart
7	SCREW, TAPPING Part #: 97780-50016-00 Required per assembly: 12 $2.45 $1.63 - + Add to cart
8	NUT, SPRING Part #: 90183-051A5-00 Required per assembly: 2 $9.99 $9.81 - + Add to cart
9	BOLT, WITH, WASHER Part #: 97595-05516-00 Required per assembly: 2 $1.55 $1.30 - + Add to cart
10	STOPPER, HATCH, 2 Part #: F4R-65136-00-00 Required per assembly: 2 $17.45 $15.86 - + Add to cart
11	PLATE, HATCH, STOPPER Part #: F4R-65137-00-00 Required per assembly: 2 $13.29 $12.08 - + Add to cart
12	BOLT, WITH, WASHER Part #: 90119-06281-00 Required per assembly: 4 $2.99 $2.27 - + Add to cart
13	NUT, SPRING Part #: 90183-06902-00 Required per assembly: 2 $12.49 $8.98 - + Add to cart
14	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06041-00 Required per assembly: 4 $9.49 $6.17 - + Add to cart
15	CLAMP Part #: GM6-64256-00-00 Required per assembly: 2 $8.99 $8.30 - + Add to cart
16	RIVET, BLIND Part #: 90267-48941-00 Required per assembly: 6 $0.99 $0.91 - + Add to cart
17	PAD, HATCH, 1 Part #: F4R-6517M-00-00 Required per assembly: 2 $5.49 $4.97 - + Add to cart
18	STOPPER, MAIN, STAND Part #: 4N0-27114-00-00 Required per assembly: 2 $7.99 $5.67 - + Add to cart
19	TRIM 1 Part #: GM6-6516C-00-00 Required per assembly: 1 $3.99 $3.61 - + Add to cart
20	STOPPER Part #: F4R-65157-00-00 Required per assembly: 1 $6.99 $6.35 - + Add to cart
21	PLATE Part #: F4R-65193-00-00 Required per assembly: 1 $7.99 $7.24 - + Add to cart
22	BRACKET Part #: F4R-65372-00-00 Required per assembly: 1 $47.49 $46.84 - + Add to cart
23	PLATE, FIX Part #: F4R-65175-00-00 Required per assembly: 2 $5.99 $5.44 - + Add to cart
24	ENGINE HATCH COVER COMP. Part #: F4R-6516M-00-00 Required per assembly: 1 $36.49 $36.26 - + Add to cart
25	PAD, HATCH, 1 Part #: F4R-6517M-00-00 Required per assembly: 1 $5.49 $4.97 - + Add to cart
26	SCREW, TAPPING Part #: 90149-05937-00 Required per assembly: 6 $5.99 $1.67 - + Add to cart
27	COVER Part #: F4R-6516W-00-00 Required per assembly: 1 $3.99 $3.61 - + Add to cart
28	BAND, BOARDING, LADDER Part #: F4R-65191-00-00 Required per assembly: 1 $19.94 $18.13 - + Add to cart
29	DAMPER, POLE Part #: F4R-6514B-00-00 Required per assembly: 1 $57.99 $57.44 - + Add to cart
30	HATCH LOCK ASSEMBLY 2 Part #: F4R-62840-01-00 Required per assembly: 1 $175.99 $173.85 - + Add to cart
31	PACKING, HATCH, LOCK Part #: EW2-62846-00-00 Required per assembly: 1 $5.99 $5.44 - + Add to cart
32	PACKING, HATCH, LOCK Part #: F4R-6284E-00-00 Required per assembly: 1 Not Available
33	NUT, SELF-LOCKING Part #: 95720-05300-00 Required per assembly: 4 $1.49 $1.36 - + Add to cart
34	HOOK C Part #: F4R-6756C-00-00 Required per assembly: 2 $9.99 $9.06 - + Add to cart
35	RIVET, BLIND, (EW3) Part #: 90267-48930-00 Required per assembly: 4 $2.49 $2.27 - + Add to cart
36	PROTECTOR 1 Part #: F4R-6514M-00-00 Required per assembly: 2 $5.99 $5.44 - + Add to cart
37	SCREW, SPECIAL, SHAPE Part #: 90149-05960-00 Required per assembly: 4 Note: Sold in multiples of 5 only $4.50 $2.83 - + Add to cart
38	WASHER, PLAIN Part #: 92990-05200-00 Required per assembly: 4 Note: Sold in multiples of 5 only $5.49 $4.97 - + Add to cart
39	NUT, SELF-LOCKING Part #: 95720-05300-00 Required per assembly: 4 $1.49 $1.36 - + Add to cart
