Control Cable replacement parts for 2024 Yamaha AR 190

OEM Parts Yamaha 2024 Yamaha AR 190 Control Cable

CONTROL CABLE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	REMOCON. LEVER ASSY. Part #: F4B-6134A-12-00 Required per assembly: 1 $1,376.49 $1,353.22 - + Add to cart
2	COVER Part #: 704-48119-50-00 Required per assembly: 1 $21.98 $21.15 - + Add to cart
3	PLUG Part #: 704-48167-20-00 Required per assembly: 1 $21.98 $20.40 - + Add to cart
4	CABLE, END, REMOTE, CONTROL, 2 Part #: 703-48345-01-00 Required per assembly: 2 $16.00 $13.80 - + Add to cart
5	NEUTRAL SWITCH ASSEMBLY Part #: F1C-6137A-10-00 Required per assembly: 1 $244.49 $240.39 - + Add to cart
6	CIRCLIP, E-TYPE Part #: 93430-06024-00 Required per assembly: 4 $4.04 $3.84 - + Add to cart
7	SCREW 1 Part #: EL8-48127-00-00 Required per assembly: 10 $6.49 $6.18 - + Add to cart
8	SCREW, 10-24, X, 1-1/2 Part #: 90157-10S24-00 Required per assembly: 4 $6.11 $1.51 - + Add to cart
9	PLATE Part #: F3M-U1348-00-00 Required per assembly: 2 $10.18 $5.82 - + Add to cart
10	SCREW, COUNTERSUNK Part #: 90151-10S28-00 Required per assembly: 4 $6.11 $1.59 - + Add to cart
11	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 4 $4.99 $0.56 - + Add to cart
12	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 4 $5.08 $1.06 - + Add to cart
13	CABLE, REVERSE Part #: F4A-6149C-11-00 Required per assembly: 1 $269.49 $266.10 - + Add to cart
14	BALL JOINT ASSEMBLY Part #: F2C-61460-00-00 Required per assembly: 1 $51.53 $46.84 - + Add to cart
15	PACKING C Part #: F1B-61438-00-00 Required per assembly: 1 $2.99 $2.72 - + Add to cart
16	NUT Part #: F1B-6151S-01-00 Required per assembly: 1 $14.49 $14.35 - + Add to cart
17	CABLE, THROTTLE Part #: F4A-U7252-00-00 Required per assembly: 1 $132.59 $98.25 - + Add to cart
18	SCREW, 1/4-20, X, 3 Part #: 90149-14SA7-00 Required per assembly: 2 $6.11 $1.97 - + Add to cart
19	WASHER, FENDER, (1/4", X, 1") Part #: 90209-14SA2-00 Required per assembly: 2 $2.02 $0.60 - + Add to cart
20	WASHER, 1/4", FL Part #: 90201-14S00-00 Required per assembly: 2 $7.12 $1.66 - + Add to cart
21	NUT, INSERT Part #: F3R-U373B-10-00 Required per assembly: 2 $9.16 $4.91 - + Add to cart
22	NUT, SELF-LOCKING Part #: 90185-14S00-00 Required per assembly: 2 $5.08 $0.68 - + Add to cart
