Engine Hatch 2 replacement parts for 2024 Yamaha VX

OEM Parts Yamaha 2024 Yamaha VX Engine Hatch 2

ENGINE HATCH 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BOLT, WITH, WASHER Part #: 90119-06803-00 Required per assembly: 2 $8.99 $3.70 - + Add to cart
2	NUT Part #: F3X-U517E-00-00 Required per assembly: 2 $5.99 $1.29 - + Add to cart
3	HOOK, LID, LOCK Part #: F4P-U517F-00-00 Required per assembly: 1 $27.98 $19.64 - + Add to cart
4	CAP Part #: F4P-U5568-00-00 Required per assembly: 2 $6.99 $2.65 - + Add to cart
5	COVER, CENTER Part #: F4N-U5554-00-00 Required per assembly: 1 $158.83 - + Add to cart
6	PACKING 3 Part #: F1K-U266B-00-00 Required per assembly: 4 $5.99 $1.21 - + Add to cart
7	NUT Part #: F3X-U517E-00-00 Required per assembly: 2 $5.99 $1.29 - + Add to cart
8	PLATE, FIX Part #: F2X-U5175-00-00 Required per assembly: 2 $5.99 $1.89 - + Add to cart
9	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 2 Note: Sold in multiples of 5 only $5.49 $5.47 - + Add to cart
10	BOLT, WITH, WASHER Part #: 90119-06878-00 Required per assembly: 2 $8.99 $3.61 - + Add to cart
11	BOLT Part #: F4P-U1355-00-00 Required per assembly: 4 $4.99 $0.91 - + Add to cart
12	COVER METER Part #: F6G-U8262-00-00 Required per assembly: 1 $24.98 $18.13 - + Add to cart
13	SCREW Part #: F2S-U13C1-00-00 Required per assembly: 2 $6.99 $2.48 - + Add to cart
14	COVER, FRONT Part #: F4N-U513M-00-00 Required per assembly: 1 $22.98 $15.10 - + Add to cart
15	GLOVE BOX HATCH ASSEMBLY Part #: F4N-U1708-01-00 Required per assembly: 1 $155.99 $117.91 - + Add to cart
16	SEAL Part #: F3X-U2723-00-00 Required per assembly: 1 $6.99 $2.27 - + Add to cart
17	NUT Part #: F3X-U517E-00-00 Required per assembly: 8 $5.99 $1.29 - + Add to cart
18	INNER, CASE Part #: F4N-U591L-00-00 Required per assembly: 1 $51.99 $39.28 - + Add to cart
19	BRACKET Part #: F2C-U826C-00-00 Required per assembly: 4 $8.99 $3.99 - + Add to cart
20	RIVET 1 Part #: F4P-U516R-01-00 Required per assembly: 8 $10.99 $5.13 - + Add to cart
21	BOLT, WITH, WASHER Part #: 90119-08828-00 Required per assembly: 4 $6.99 $2.42 - + Add to cart
22	PACKING CASE Part #: F4N-U519D-02-00 Required per assembly: 1 $57.99 $43.82 - + Add to cart
23	GLOVE BOX COVER ASSEMBLY Part #: F4N-U4705-01-00 Required per assembly: 1 $57.99 $43.82 - + Add to cart
24	LOCK Part #: F4N-U2875-00-00 Required per assembly: 1 $6.99 $4.16 - + Add to cart
25	HOOK A Part #: F1K-U5772-04-00 Required per assembly: 2 $11.99 $5.97 - + Add to cart
26	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 2 Note: Sold in multiples of 5 only $5.49 $5.47 - + Add to cart
27	MAT 2 Part #: F1K-U759C-00-00 Required per assembly: 2 $5.99 $1.81 - + Add to cart
28	BOX, FIRE, EXTINGUISHER Part #: F2X-U5983-00-00 Required per assembly: 1 $12.16 - + Add to cart
29	RIVET, BLIND Part #: 90267-48802-00 Required per assembly: 2 $6.99 $2.08 - + Add to cart
30	BAND, 1 Part #: F2P-U828K-00-00 Required per assembly: 1 $12.99 $6.18 - + Add to cart
31	RFM., DASH, BOARD, 1 Part #: F4N-U974A-00-00 Required per assembly: 1 $17.98 $12.08 - + Add to cart
32	SCREW Part #: F3X-U7823-12-00 Required per assembly: 2 $5.99 $1.32 - + Add to cart
33	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 2 $5.99 $1.44 - + Add to cart
34	RFM., DASH, BOARD, 2 Part #: F4N-U974B-00-00 Required per assembly: 1 $17.98 $12.08 - + Add to cart
35	SCREW Part #: F3X-U7823-12-00 Required per assembly: 2 $5.99 $1.32 - + Add to cart
36	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 2 $5.99 $1.44 - + Add to cart
