Front Fork replacement parts for 2024 Yamaha WR450F

OEM Parts Yamaha 2024 Yamaha WR450F Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSY (L.H) Part #: BNK-23102-00-00 Required per assembly: 1 $1,099.99 $935.96 - + Add to cart
2	TUBE, OUTER, (RIGHT) Part #: 33D-23136-00-00 Required per assembly: 1 $832.41 $756.74 - + Add to cart
3	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.49 $4.10 - + Add to cart
4	INNER TUBE COMP2 Part #: BNK-23120-00-00 Required per assembly: 1 $384.99 $378.36 - + Add to cart
5	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 $30.98 $20.32 - + Add to cart
6	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 $28.98 $20.64 - + Add to cart
7	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 $15.49 $10.07 - + Add to cart
8	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 $24.98 $20.38 - + Add to cart
9	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
10	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 $19.48 $15.74 - + Add to cart
11	SEAL, DUST Part #: BHR-23144-00-00 Required per assembly: 1 $24.98 $18.98 - + Add to cart
12	CYLINDER, COMP, FRONT, FORK Part #: BNK-23170-00-00 Required per assembly: 1 $384.99 $378.36 - + Add to cart
13	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $3.75 $3.14 - + Add to cart
14	SEAT, SPRING, UPPER Part #: BR9-23142-01-00 Required per assembly: 1 $63.99 $51.51 - + Add to cart
15	VALVE COMP Part #: BNK-2316A-00-00 Required per assembly: 1 $219.99 $216.20 - + Add to cart
16	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $8.49 $6.61 - + Add to cart
17	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
18	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.00 $4.16 - + Add to cart
19	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 $25.98 $19.70 - + Add to cart
20	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 $4.29 $2.69 - + Add to cart
21	SPRING, FRONT, FORK, (K=4.8) Part #: BR9-23141-50-00 Required per assembly: 1 $137.50 $125.00 - + Add to cart
22	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 $78.98 $65.77 - + Add to cart
23	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
24	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.09 $3.18 - + Add to cart
25	CAP Part #: BHR-2319W-00-00 Required per assembly: 1 $11.49 $10.22 - + Add to cart
26	SCREW Part #: 1MC-23119-10-00 Required per assembly: 1 $2.60 $1.27 - + Add to cart
27	FRONT FORK ASSY (R.H) Part #: BNK-23103-00-00 Required per assembly: 1 $1,099.99 $935.96 - + Add to cart
28	TUBE, OUTER, (RIGHT) Part #: 33D-23136-00-00 Required per assembly: 1 $832.41 $756.74 - + Add to cart
29	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.49 $4.10 - + Add to cart
30	INNER TUBE COMP1 Part #: BNK-23110-00-00 Required per assembly: 1 $384.99 $378.36 - + Add to cart
31	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 $30.98 $20.32 - + Add to cart
32	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 $28.98 $20.64 - + Add to cart
33	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 $15.49 $10.07 - + Add to cart
34	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 $24.98 $20.38 - + Add to cart
35	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
36	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 $19.48 $15.74 - + Add to cart
37	SEAL, DUST Part #: BHR-23144-00-00 Required per assembly: 1 $24.98 $18.98 - + Add to cart
38	CYLINDER, COMP, FRONT, FORK Part #: BNK-23170-00-00 Required per assembly: 1 $384.99 $378.36 - + Add to cart
39	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $3.75 $3.14 - + Add to cart
40	SEAT, SPRING, UPPER Part #: BR9-23142-01-00 Required per assembly: 1 $63.99 $51.51 - + Add to cart
41	VALVE COMP Part #: BNK-2316A-00-00 Required per assembly: 1 $219.99 $216.20 - + Add to cart
42	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $8.49 $6.61 - + Add to cart
43	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
44	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.00 $4.16 - + Add to cart
45	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 $25.98 $19.70 - + Add to cart
46	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 $4.29 $2.69 - + Add to cart
47	SPRING, FRONT, FORK, (K=4.8) Part #: BR9-23141-50-00 Required per assembly: 1 $137.50 $125.00 - + Add to cart
48	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 $78.98 $65.77 - + Add to cart
49	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
50	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.09 $3.18 - + Add to cart
51	CAP Part #: BHR-2319W-00-00 Required per assembly: 1 $11.49 $10.22 - + Add to cart
52	SCREW Part #: 1MC-23119-10-00 Required per assembly: 1 $2.60 $1.27 - + Add to cart
53	UNDER BRACKET COMP. Part #: B7R-23340-00-00 Required per assembly: 1 $628.99 $589.18 - + Add to cart
54	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08035-00 Required per assembly: 4 $2.85 $2.42 - + Add to cart
55	PROTECTOR 2 Part #: 17D-2315J-J0-00 Required per assembly: 1 $17.48 $16.41 - + Add to cart
56	PROTECTOR 1 Part #: B7R-2315H-20-00 Required per assembly: 1 $34.99 $33.66 - + Add to cart
57	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.15 $3.43 - + Add to cart
58	CLAMP Part #: B7R-23466-00-00 Required per assembly: 1 $29.98 $22.77 - + Add to cart
59	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-05028-00 Required per assembly: 2 $9.49 $6.17 - + Add to cart
60	BRACKET 1 Part #: B7R-83955-00-00 Required per assembly: 1 $58.99 $49.25 - + Add to cart
61	PIN, DOWEL Part #: 93603-07073-00 Required per assembly: 2 $9.49 $5.74 - + Add to cart
62	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08045-00 Required per assembly: 2 $2.70 $2.25 - + Add to cart
63	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08035-00 Required per assembly: 2 $2.85 $2.42 - + Add to cart
