Frame replacement parts for 2024 Yamaha XSR700 CA

OEM Parts Yamaha 2024 Yamaha XSR700 CA Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: B2G-21110-11-00 Required per assembly: 1 $1,921.93 - + Add to cart
2	MOLE, SIDE, COVER, 1 Part #: 1FK-2171L-00-00 Required per assembly: 2 ~~$25.98~~ $23.08 - + Add to cart
3	REAR FRAME COMP. Part #: B34-F1190-00-00 Required per assembly: 1 ~~$675.99~~ $665.69 - + Add to cart
4	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-08111-00 Required per assembly: 4 $4.11 - + Add to cart
5	PLATE 1 Part #: 1WS-2191B-00-00 Required per assembly: 1 ~~$18.98~~ $18.24 - + Add to cart
6	BRACKET, SEAT Part #: BMC-21349-00-00 Required per assembly: 1 ~~$54.99~~ $47.49 - + Add to cart
7	DAMPER, LOCATING, 2 Part #: 3B4-24182-00-00 Required per assembly: 1 $4.25 - + Add to cart
8	BOLT, BUTTON, HEAD Part #: 92017-06014-00 Required per assembly: 4 ~~$4.59~~ $3.92 - + Add to cart
9	WASHER, PLATE Part #: 90201-07081-00 Required per assembly: 4 Note: (USA) ~~$11.49~~ $9.46 - + Add to cart
10	BOLT, FLANGE Part #: 90105-10219-00 Required per assembly: 1 ~~$8.49~~ $7.79 - + Add to cart
11	BOLT, FLANGE Part #: 90105-10349-00 Required per assembly: 1 ~~$16.48~~ $16.14 - + Add to cart
12	NUT Part #: 90179-10024-00 Required per assembly: 2 ~~$11.49~~ $11.46 - + Add to cart
13	WASHER, PLATE Part #: 90201-10035-00 Required per assembly: 2 $5.32 - + Add to cart
14	BOLT, FLANGE Part #: 90105-12092-00 Required per assembly: 2 ~~$15.49~~ $14.85 - + Add to cart
15	WASHER, PLATE Part #: 90201-13020-00 Required per assembly: 2 $4.25 - + Add to cart
16	STAY, ENGINE, 1 Part #: BAT-21315-00-00 Required per assembly: 1 ~~$18.48~~ $18.35 - + Add to cart
17	STAY, ENGINE, 2 Part #: BAT-21316-00-00 Required per assembly: 1 ~~$18.48~~ $18.35 - + Add to cart
18	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10044-00 Required per assembly: 2 ~~$6.49~~ $5.71 - + Add to cart
19	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-08111-00 Required per assembly: 4 $4.11 - + Add to cart
20	DAMPER, PLATE Part #: 90520-20003-00 Required per assembly: 1 ~~$9.49~~ $8.44 - + Add to cart
21	BRACKET, SEAT, FITTING Part #: BMC-21946-00-00 Required per assembly: 1 ~~$49.99~~ $43.41 - + Add to cart
22	BOLT, BUTTON, HEAD Part #: 92017-06014-00 Required per assembly: 4 ~~$4.59~~ $3.92 - + Add to cart
23	WASHER, PLATE Part #: 90201-07081-00 Required per assembly: 4 Note: (USA) ~~$11.49~~ $9.46 - + Add to cart
24	NUT, SPRING Part #: 90183-05X04-00 Required per assembly: 2 $8.46 - + Add to cart
25	BRACKET Part #: B34-21158-00-00 Required per assembly: 1 ~~$77.98~~ $70.35 - + Add to cart
26	GROMMET Part #: 90480-30167-00 Required per assembly: 2 $11.95 - + Add to cart
27	NUT, FLANGE, (7NB) Part #: 95780-06500-00 Required per assembly: 2 ~~$2.95~~ $2.71 - + Add to cart
28	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06122-00 Required per assembly: 1 ~~$6.49~~ $5.85 - + Add to cart
29	BRACKET 8 Part #: B2G-2161J-00-00 Required per assembly: 1 $16.59 - + Add to cart
30	BOLT, BUTTON, HEAD Part #: 92017-06010-00 Required per assembly: 1 ~~$5.49~~ $4.30 - + Add to cart
31	BRACKET 2 Part #: B34-2175U-00-00 Required per assembly: 1 $11.46 - + Add to cart
32	RIVET Part #: 90269-07077-00 Required per assembly: 1 ~~$9.49~~ $9.25 - + Add to cart
33	COVER 4 Part #: 1WS-2117R-00-00 Required per assembly: 1 $7.94 - + Add to cart
34	PLATE, DAMPER Part #: 1HX-27415-00-00 Required per assembly: 3 $8.59 - + Add to cart
35	COVER 5 Part #: 1WS-2117T-01-00 Required per assembly: 1 $6.47 - + Add to cart
36	PLATE, DAMPER Part #: 1HX-27415-00-00 Required per assembly: 2 $8.59 - + Add to cart
37	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 2 $2.13 - + Add to cart
38	COLLAR Part #: 90387-062M9-00 Required per assembly: 2 ~~$10.49~~ $8.86 - + Add to cart
39	GUIDE, CABLE Part #: 1XB-21288-00-00 Required per assembly: 1 $17.13 - + Add to cart
40	BOLT, FLANGE Part #: 95027-06010-00 Required per assembly: 1 ~~$3.54~~ $3.50 - + Add to cart
41	PROTECTOR, FUEL, TANK Part #: 3HA-24141-00-00 Required per assembly: 1 ~~$15.49~~ $14.08 - + Add to cart
42	STOPPER Part #: B2G-23376-00-00 Required per assembly: 1 ~~$18.98~~ $18.07 - + Add to cart
43	STOPPER Part #: B2G-23429-00-00 Required per assembly: 1 $15.64 - + Add to cart
44	HOLDER, RELAY Part #: BMC-81952-00-00 Required per assembly: 1 ~~$48.99~~ $42.49 - + Add to cart
45	NUT, SPRING Part #: 90183-05X04-00 Required per assembly: 2 $8.46 - + Add to cart
46	COLLAR Part #: 90387-1001B-00 Required per assembly: 1 Not Available
47	BOLT, WITH, WASHER Part #: 90119-06209-00 Required per assembly: 1 $7.42 - + Add to cart
48	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 1 $2.13 - + Add to cart
49	COLLAR Part #: 90387-06106-00 Required per assembly: 1 ~~$8.49~~ $7.38 - + Add to cart
50	RIVET Part #: 90269-06002-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
51	DAMPER, HEADLIGHT, STAY Part #: 5C7-84143-00-00 Required per assembly: 1 $2.09 - + Add to cart
52	SEAL Part #: B34-E4476-00-00 Required per assembly: 1 ~~$32.99~~ $27.10 - + Add to cart
53	BAND Part #: 1UA-82591-00-00 Required per assembly: 2 $5.71 - + Add to cart
