Front Fork replacement parts for 2024 Yamaha XSR900 CA

OEM Parts Yamaha 2024 Yamaha XSR900 CA Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (R.H) Part #: BEA-23103-02-00 Required per assembly: 1 ~~$955.99~~ $925.57 - + Add to cart
2	TUBE, OUTER, (L.H) Part #: B7N-23126-10-00 Required per assembly: 1 ~~$387.99~~ $375.58 - + Add to cart
3	INNER TUBE COMP2 Part #: BME-23120-00-00 Required per assembly: 1 ~~$377.99~~ $367.96 - + Add to cart
4	SEAL, DUST Part #: 4EB-23144-00-00 Required per assembly: 1 ~~$24.98~~ $21.82 - + Add to cart
5	RING, SNAP Part #: 26H-23156-00-00 Required per assembly: 1 $8.86 - + Add to cart
6	OIL SEAL Part #: 4EB-23145-01-00 Required per assembly: 1 ~~$31.98~~ $25.18 - + Add to cart
7	WASHER, OIL, SEAL Part #: 36Y-23146-10-00 Required per assembly: 1 ~~$30.98~~ $23.74 - + Add to cart
8	METAL, SLIDE, 1 Part #: 1RC-23125-00-00 Required per assembly: 1 ~~$16.48~~ $15.39 - + Add to cart
9	METAL, SLIDE Part #: 4FM-23171-40-00 Required per assembly: 1 ~~$25.98~~ $22.51 - + Add to cart
10	CYLINDER, COMP, FRONT, FORK Part #: BEA-23170-10-00 Required per assembly: 1 ~~$297.99~~ $292.39 - + Add to cart
11	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 ~~$17.98~~ $17.34 - + Add to cart
12	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $10.11 - + Add to cart
13	SPRING, FRONT, FORK Part #: BEA-23141-00-00 Required per assembly: 1 ~~$98.98~~ $89.63 - + Add to cart
14	WASHER Part #: 5VY-12277-00-00 Required per assembly: 1 ~~$14.49~~ $13.23 - + Add to cart
15	SPACER Part #: 5VY-23118-01-00 Required per assembly: 1 ~~$33.99~~ $28.91 - + Add to cart
16	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $8.63 - + Add to cart
17	BOLT, CAP Part #: BEA-23111-11-00 Required per assembly: 1 ~~$322.99~~ $316.79 - + Add to cart
18	O-RING Part #: 3XJ-23147-L2-00 Required per assembly: 1 $5.51 - + Add to cart
19	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 1 ~~$8.49~~ $5.15 - + Add to cart
20	FRONT FORK ASSEMBLY (L.H) Part #: BEA-23102-01-00 Required per assembly: 1 ~~$1,180.99~~ $1,102.59 - + Add to cart
21	TUBE, OUTER, (L.H) Part #: B7N-23126-10-00 Required per assembly: 1 ~~$387.99~~ $375.58 - + Add to cart
22	INNER TUBE COMP.1 Part #: B7N-23110-01-00 Required per assembly: 1 ~~$452.99~~ $437.56 - + Add to cart
23	SEAL, DUST Part #: 4EB-23144-00-00 Required per assembly: 1 ~~$24.98~~ $21.82 - + Add to cart
24	RING, SNAP Part #: 26H-23156-00-00 Required per assembly: 1 $8.86 - + Add to cart
25	OIL SEAL Part #: 4EB-23145-01-00 Required per assembly: 1 ~~$31.98~~ $25.18 - + Add to cart
26	WASHER, OIL, SEAL Part #: 36Y-23146-10-00 Required per assembly: 1 ~~$30.98~~ $23.74 - + Add to cart
27	METAL, SLIDE, 1 Part #: 1RC-23125-00-00 Required per assembly: 1 ~~$16.48~~ $15.39 - + Add to cart
28	METAL, SLIDE Part #: 4FM-23171-40-00 Required per assembly: 1 ~~$25.98~~ $22.51 - + Add to cart
29	CYLINDER, COMP, FRONT, FORK Part #: BEA-23170-00-00 Required per assembly: 1 ~~$297.99~~ $292.39 - + Add to cart
30	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 ~~$17.98~~ $17.34 - + Add to cart
31	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $10.11 - + Add to cart
32	SPRING, FRONT, FORK Part #: BEA-23141-00-00 Required per assembly: 1 ~~$98.98~~ $89.63 - + Add to cart
33	WASHER Part #: 5VY-12277-00-00 Required per assembly: 1 ~~$14.49~~ $13.23 - + Add to cart
34	SPACER Part #: 5VY-23118-01-00 Required per assembly: 1 ~~$33.99~~ $28.91 - + Add to cart
35	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $8.63 - + Add to cart
36	BOLT, CAP Part #: BEA-23111-01-00 Required per assembly: 1 ~~$322.99~~ $316.79 - + Add to cart
37	O-RING Part #: 3XJ-23147-L2-00 Required per assembly: 1 $5.51 - + Add to cart
38	UNDER BRACKET COMP. Part #: B7N-23340-00-00 Required per assembly: 1 ~~$398.99~~ $397.07 - + Add to cart
39	SEAL, STEERING Part #: 3FV-23462-00-00 Required per assembly: 1 ~~$26.98~~ $23.44 - + Add to cart
40	BEARING Part #: 93399-99957-00 Required per assembly: 1 ~~$76.98~~ $63.61 - + Add to cart
41	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08030-00 Required per assembly: 4 $3.25 - + Add to cart
42	COVER, UNDER, 1 Part #: 4KM-23123-01-00 Required per assembly: 1 $16.31 - + Add to cart
43	FORK SEALS KIT Part #: BEA-W003B-00-00 Required per assembly: 1 ~~$63.99~~ $55.78 - + Add to cart
