Winch replacement parts for 2024 Yamaha Grizzly EPS Hunting

OEM Parts Yamaha 2024 Yamaha Grizzly EPS Hunting Winch

WINCH Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WINCH Part #: BFE-F845V-00-00 Required per assembly: 1 $589.99 $549.53 - + Add to cart
2	BRACKET 1 Part #: BFE-F8426-00-00 Required per assembly: 1 $71.98 $51.17 - + Add to cart
3	HOOK Part #: BFE-F8488-00-00 Required per assembly: 1 $57.99 $41.63 - + Add to cart
4	ROLLER Part #: BFE-F178G-00-00 Required per assembly: 1 $79.98 $70.62 - + Add to cart
5	LABEL 2 Part #: BAS-F8459-00-00 Required per assembly: 1 $5.49 $4.46 - + Add to cart
6	CONTACTOR Part #: BAS-H232W-00-00 Required per assembly: 1 $186.99 $145.12 - + Add to cart
7	WIRE HARNESS Part #: BFE-82105-00-00 Required per assembly: 1 $14.49 $11.58 - + Add to cart
8	SWITCH ASSEMBLY Part #: BFE-H259E-02-00 Required per assembly: 1 $57.99 $54.58 - + Add to cart
9	BRACKET, SWITCH Part #: BFE-F1453-00-00 Required per assembly: 1 $9.49 $6.18 - + Add to cart
10	BOLT, FLANGE Part #: 95027-06035-00 Required per assembly: 1 $2.39 $1.81 - + Add to cart
11	COLLAR Part #: 90387-06113-00 Required per assembly: 1 $12.49 $10.33 - + Add to cart
12	BOLT, WITH, WASHER Part #: 90119-06240-00 Required per assembly: 2 $3.85 $2.90 - + Add to cart
13	NUT, FLANGE, (7NB) Part #: 95780-06500-00 Required per assembly: 6 $2.95 $1.87 - + Add to cart
14	BOLT, FLANGE Part #: 95812-10016-00 Required per assembly: 2 $10.49 $8.10 - + Add to cart
15	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
16	NUT, FLANGE, (8AB) Part #: 95707-10500-00 Required per assembly: 2 $2.14 $1.63 - + Add to cart
17	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-10020-00 Required per assembly: 2 $8.49 $5.16 - + Add to cart
18	WASHER, PLATE Part #: 90201-10033-00 Required per assembly: 2 $9.49 $6.15 - + Add to cart
19	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-08020-00 Required per assembly: 4 $0.60 $0.45 - + Add to cart
20	SCREW, SPECIAL Part #: BFE-F8382-00-00 Required per assembly: 2 $0.35 $0.25 - + Add to cart
21	BAG INNER 1 Part #: B4F-F8479-00-00 Required per assembly: 1 $0.40 $0.31 - + Add to cart
22	CLAMP Part #: 90464-40825-00 Required per assembly: 2 $3.04 $1.72 - + Add to cart
23	WIRE, SUB, LEAD Part #: BFE-H2309-00-00 Required per assembly: 1 $55.99 $40.42 - + Add to cart
24	WIRE, LEAD, 3 Part #: BFE-H2149-00-00 Required per assembly: 1 $19.48 $13.94 - + Add to cart
25	WIRE, LEAD, 4 Part #: BFE-H2148-00-00 Required per assembly: 1 $22.98 $15.53 - + Add to cart
26	PROTECTOR Part #: BAS-F3472-00-00 Required per assembly: 4 $5.99 $4.22 - + Add to cart
