Frame replacement parts for 2024 Yamaha Wolverine X4 R Spec

OEM Parts Yamaha 2024 Yamaha Wolverine X4 R Spec Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: BAR-F1110-30-00 Required per assembly: 1 $8,103.26 - + Add to cart
2	ENGINE BRACKET COMP. Part #: BG4-21410-00-00 Required per assembly: 1 $80.98 $72.91 - + Add to cart
3	ENGINE BRACKET COMP. 2 Part #: BG4-21420-00-00 Required per assembly: 1 $80.98 $72.91 - + Add to cart
4	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-10025-00 Required per assembly: 4 $1.55 $1.27 - + Add to cart
5	BRACKET 5 Part #: BG4-F161F-00-00 Required per assembly: 1 $13.49 $9.65 - + Add to cart
6	BRACKET 3 Part #: BG4-F161A-00-00 Required per assembly: 1 $8.99 $7.30 - + Add to cart
7	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-12065-00 Required per assembly: 2 $3.95 $3.30 - + Add to cart
8	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-10016-00 Required per assembly: 4 $1.39 $1.15 - + Add to cart
9	BRACKET, ENGINE, 1 Part #: B4J-21490-10-00 Required per assembly: 2 Not Available
10	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-12065-00 Required per assembly: 2 $3.95 $3.30 - + Add to cart
11	NUT Part #: 90179-10033-00 Required per assembly: 2 Not Available
12	SUPPORT, ENGINE Part #: B4J-F1283-03-00 Required per assembly: 1 $23.98 $19.70 - + Add to cart
13	SUPT., ENGINE, 2 Part #: B4J-F1284-03-00 Required per assembly: 1 $26.98 $21.91 - + Add to cart
14	BOLT, FLANGE, DEEP, RECESS Part #: 95D37-10025-00 Required per assembly: 4 $2.50 $1.68 - + Add to cart
15	BRACKET 1 Part #: BG4-F172K-00-00 Required per assembly: 1 $4.95 $3.78 - + Add to cart
16	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 $5.49 $3.84 - + Add to cart
17	BRACKET 1 Part #: BG4-F172K-00-00 Required per assembly: 1 $4.95 $3.78 - + Add to cart
18	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 $5.49 $3.84 - + Add to cart
19	BRACKET 2 Part #: BFN-F1239-00-00 Required per assembly: 1 $18.48 $11.84 - + Add to cart
20	BOLT, FLANGE Part #: 95812-12020-00 Required per assembly: 2 $9.49 $6.12 - + Add to cart
21	BRACKET Part #: BFN-F1249-00-00 Required per assembly: 1 $5.49 $4.28 - + Add to cart
22	BOLT, FLANGE Part #: 95812-12020-00 Required per assembly: 2 $9.49 $6.12 - + Add to cart
23	STAY, SUPPORT, 1 Part #: BG4-F831T-00-00 Required per assembly: 1 $50.12 - + Add to cart
24	WASHER, PLATE Part #: 90201-12039-00 Required per assembly: 4 $3.99 $3.61 - + Add to cart
25	BOLT, FLANGE Part #: 90105-12121-00 Required per assembly: 4 $3.79 $2.57 - + Add to cart
26	BRKT., RR., AXLE Part #: BAR-F1981-00-00 Required per assembly: 1 $3.54 $2.93 - + Add to cart
27	BOLT, FLANGE Part #: 95812-12020-00 Required per assembly: 2 $9.49 $6.12 - + Add to cart
28	LUG, SEAT, RAIL, LH. Part #: BG4-F1143-10-00 Required per assembly: 1 $43.77 - + Add to cart
29	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $1.95 $1.47 - + Add to cart
30	MEMBER, SEAT, SUPPORT Part #: BG4-F255G-01-00 Required per assembly: 1 $36.99 $32.99 - + Add to cart
31	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $1.95 $1.47 - + Add to cart
32	BRACKET, LOCK, 2 Part #: BG4-F287M-00-00 Required per assembly: 1 $20.98 $15.98 - + Add to cart
33	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
34	STAY, MUFFLER, 2 Part #: BG4-F1446-11-00 Required per assembly: 1 $2.20 $1.83 - + Add to cart
35	PROTECTOR 1 Part #: BG4-F834V-00-00 Required per assembly: 1 $72.98 $65.48 - + Add to cart
36	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
37	COVER 3 Part #: 2MB-F198J-01-00 Required per assembly: 2 $8.49 $5.07 - + Add to cart
38	BOLT, SPECIAL, 1 Part #: JW1-K6179-01-00 Required per assembly: 2 $1.75 $1.21 - + Add to cart
39	BRACKET, FOOTREST, 3 Part #: BG4-F144H-00-00 Required per assembly: 2 $188.99 $142.48 - + Add to cart
40	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $1.95 $1.47 - + Add to cart
41	HOOK, SIDE, COVER, 3 Part #: BG4-F1333-00-00 Required per assembly: 1 $227.99 $187.62 - + Add to cart
42	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-06014-00 Required per assembly: 2 $0.28 $0.25 - + Add to cart
43	HOOK, SIDE, COVER, 4 Part #: BG4-F1334-00-00 Required per assembly: 1 $188.99 $142.10 - + Add to cart
44	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-06014-00 Required per assembly: 2 $0.28 $0.25 - + Add to cart
45	REINFORCEMENT, FRAME, 1 Part #: BG4-F1986-01-00 Required per assembly: 1 $1,114.00 - + Add to cart
46	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 3 $1.95 $1.47 - + Add to cart
47	MOLD, FUEL, TANK Part #: 31A-24188-01-00 Required per assembly: 1 $13.99 $11.60 - + Add to cart
48	POUCH Part #: 1P0-F8186-01-00 Required per assembly: 1 $2.89 $2.62 - + Add to cart
