Rear Wheel replacement parts for 2024 Yamaha YXZ1000R SS

OEM Parts Yamaha 2024 Yamaha YXZ1000R SS Rear Wheel

REAR WHEEL Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WHEEL, CAST, 2 Part #: B5H-F533P-01-00 Required per assembly: 1 $280.04 - + Add to cart
2	TIRE (29X11.00R14 M918 8PR TL) Part #: 94111-14813-00 Required per assembly: 1 $461.16 - + Add to cart
3	VALVE, RIM, (TR413) Part #: 93900-00812-00 Required per assembly: 1 ~~$9.49~~ $7.36 - + Add to cart
4	HUB, FRONT Part #: B5H-F5111-02-00 Required per assembly: 1 ~~$142.99~~ $106.26 - + Add to cart
5	BOLT, SERRATION Part #: 90114-12005-00 Required per assembly: 4 ~~$3.20~~ $2.65 - + Add to cart
6	NUT, CROWN Part #: 90176-12801-00 Required per assembly: 4 ~~$3.54~~ $2.68 - + Add to cart
7	REAR DRIVE SHAFT A Part #: 2HC-2531H-13-00 Required per assembly: 1 $299.88 - + Add to cart
8	BALL JOINT SET Part #: 2HC-2530T-13-00 Required per assembly: 1 ~~$406.99~~ $398.71 - + Add to cart
9	DOUBLE OFF SET JOINT Part #: BG4-2530V-01-00 Required per assembly: 1 ~~$542.99~~ $530.03 - + Add to cart
10	BOOT SET (BALL JOINT) Part #: 2HC-2530X-13-00 Required per assembly: 1 ~~$53.99~~ $45.57 - + Add to cart
11	BOOT SET (DOUBLE OFFSET JOINT) Part #: 2HC-2530Y-01-00 Required per assembly: 1 ~~$58.99~~ $46.63 - + Add to cart
12	CLIP, SPRING Part #: 2HC-2536E-00-00 Required per assembly: 1 ~~$5.49~~ $4.49 - + Add to cart
13	RING 1 Part #: 16B-25185-00-00 Required per assembly: 1 ~~$5.49~~ $3.40 - + Add to cart
14	CLIP, SPRING Part #: 16B-2536E-00-00 Required per assembly: 1 ~~$5.49~~ $3.30 - + Add to cart
15	SNAP RING Part #: 2HC-2512J-00-00 Required per assembly: 1 ~~$4.95~~ $4.10 - + Add to cart
16	BAND Part #: 2HC-25719-00-00 Required per assembly: 1 ~~$7.49~~ $6.05 - + Add to cart
17	BAND Part #: 2HC-26293-00-00 Required per assembly: 1 ~~$10.99~~ $8.56 - + Add to cart
18	BAND Part #: 2HC-26397-12-00 Required per assembly: 1 ~~$5.99~~ $4.69 - + Add to cart
19	BOOT BAND (SMALL) Part #: 2HC-2512G-10-00 Required per assembly: 1 ~~$8.49~~ $7.00 - + Add to cart
20	SHAFT Part #: 2HC-259A2-00-00 Required per assembly: 1 ~~$117.98~~ $100.23 - + Add to cart
21	WASHER, PLATE Part #: 90201-25023-00 Required per assembly: 1 ~~$11.49~~ $9.15 - + Add to cart
22	NUT Part #: 90179-24006-00 Required per assembly: 1 ~~$15.49~~ $14.02 - + Add to cart
23	CAP, WHEEL Part #: 2HC-F512A-00-00 Required per assembly: 1 ~~$3.25~~ $2.83 - + Add to cart
24	REAR KNUCKLE ASSEMBLY Part #: B5H-F530F-00-00 Required per assembly: 1 ~~$222.99~~ $206.88 - + Add to cart
25	BEARING Part #: 93305-00603-00 Required per assembly: 1 ~~$139.99~~ $119.89 - + Add to cart
26	NIPPLE, GREASE(6A1) Part #: 93700-06M03-00 Required per assembly: 2 ~~$8.49~~ $8.30 - + Add to cart
27	BUSH, SOLID(2NL) Part #: 90381-17067-00 Required per assembly: 4 ~~$13.87~~ $12.61 - + Add to cart
28	CIRCLIP (70R) Part #: 93420-72065-00 Required per assembly: 1 ~~$8.99~~ $8.30 - + Add to cart
29	WASHER, PLATE Part #: 90201-30666-00 Required per assembly: 1 ~~$11.49~~ $9.18 - + Add to cart
30	COLLAR Part #: 90387-12060-00 Required per assembly: 1 ~~$31.98~~ $24.24 - + Add to cart
31	COLLAR Part #: 90387-12061-00 Required per assembly: 1 ~~$39.99~~ $31.31 - + Add to cart
32	COVER, THRUST, 1 Part #: 1XD-23517-01-00 Required per assembly: 4 ~~$10.99~~ $8.06 - + Add to cart
33	BOLT, FLANGE Part #: 90105-12066-00 Required per assembly: 1 ~~$13.49~~ $11.48 - + Add to cart
34	BOLT, FLANGE Part #: 90105-12097-00 Required per assembly: 1 ~~$19.48~~ $15.86 - + Add to cart
35	NUT, SELF-LOCKING Part #: 90185-12007-00 Required per assembly: 2 ~~$11.49~~ $8.77 - + Add to cart
36	RING, WHEEL, RR., 1 Part #: 2HC-F534C-00-00 Required per assembly: 1 ~~$11.49~~ $8.75 - + Add to cart
37	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06096-00 Required per assembly: 3 ~~$9.49~~ $6.15 - + Add to cart
38	PLATE, GUIDE, 1 Part #: 2HC-F2341-00-00 Required per assembly: 1 ~~$10.49~~ $7.05 - + Add to cart
39	BOLT, BUTTON, HEAD Part #: 92012-06012-00 Required per assembly: 2 ~~$4.70~~ $2.45 - + Add to cart
