Piston Rebuilt Kit replacement parts for 2024 Yamaha YZ125 50th

OEM Parts Yamaha 2024 Yamaha YZ125 50th Piston Rebuilt Kit

PISTON REBUILT KIT Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PISTON REBUILT KIT Part #: B4X-WB033-00-A0 Required per assembly: 1 $201.99 $189.17 - + Add to cart
1	PISTON REBUILT KIT Part #: B4X-WB033-00-B0 Required per assembly: 1 $203.99 $190.86 - + Add to cart
1	PISTON REBUILT KIT Part #: B4X-WB033-00-C0 Required per assembly: 1 $209.99 $196.17 - + Add to cart
1	PISTON REBUILT KIT Part #: B4X-WB033-00-D0 Required per assembly: 1 $201.99 $189.17 - + Add to cart
2	PISTON (STD) Part #: B4X-11631-00-A0 Required per assembly: 1 $129.99 $114.50 - + Add to cart
2	PISTON (STD) Part #: B4X-11631-00-B0 Required per assembly: 1 $129.99 $114.50 - + Add to cart
2	PISTON (STD) Part #: B4X-11631-00-C0 Required per assembly: 1 $129.99 $114.50 - + Add to cart
2	PISTON (STD) Part #: B4X-11631-00-D0 Required per assembly: 1 $129.99 $114.50 - + Add to cart
3	PIN, PISTON Part #: B4X-11633-00-00 Required per assembly: 1 $34.99 $24.81 - + Add to cart
4	RING, PISTON Part #: 5NY-11611-00-00 Required per assembly: 1 Note: (5NY1) $28.98 $20.68 - + Add to cart
5	BEARING Part #: 93310-21510-00 Required per assembly: 1 Note: (5MV1) $36.99 $27.40 - + Add to cart
6	CIRCLIP, INNER Part #: 93450-16068-00 Required per assembly: 2 $8.49 $5.88 - + Add to cart
7	O-RING Part #: 93210-90785-00 Required per assembly: 1 $12.49 $9.01 - + Add to cart
8	O-RING Part #: 93210-63442-00 Required per assembly: 1 $8.49 $5.67 - + Add to cart
9	GASKET, CYLINDER Part #: B4X-11351-00-00 Required per assembly: 1 $23.98 $18.22 - + Add to cart
10	GASKET Part #: 1C3-11354-00-00 Required per assembly: 1 $5.99 $4.31 - + Add to cart
11	GASKET Part #: B4X-11993-00-00 Required per assembly: 1 $6.49 $4.63 - + Add to cart
12	WASHER, PLATE Part #: 90201-080L8-00 Required per assembly: 5 $3.64 $2.75 - + Add to cart
13	O-RING (1LX) Part #: 93210-42728-00 Required per assembly: 2 $18.48 $14.73 - + Add to cart
